Connect the Power Source
The Aurora Universal System comes without holes for electrical connections to the enclosure.
1. Drill a hole in the enclosure to string the power supply wire. The power connection
point in the Aurora Universal in at the lower left of the enclosure. This may also
require conduit to house the wire if required for your installation.
Power
Supply
Block
2. Make sure power is OFF to the power wires coming into the Aurora Universal
enclosure. Attach incoming power wire to the power connector on the DIN Rail of the
Aurora Universal (connectors farthest to the left).
3. Make sure the circuit breaker switch on the DIN Rail power connector block is OFF.
Connect the power supply wire to 120, 208, or 240VAC.
Connect Instruments
If you have no meter in the Aurora Universal, skip this section. Instruments are attached to Aurora
Universal only if you have a revenue grade meter with your system (Aurora Revenue Grade). The
Aurora Universal System comes without holes for electrical connections to the enclosure.
1. Use the same hole/conduit drilled for the power source, or drill a second hole if
appropriate for your installation. The instrument connection points in the Aurora
Universal are at the lower portion of the enclosure. This may also require conduit to
house the wires if required for your installation.
Circuit Breaker
Recommended Area for Drilling Holes
