INSTRUCTIONS AND ADVICE FOR THE
USE, INSTALLATION AND MAINTENANCE
Dear Customer,
Thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the very
highest quality materials, will meet your requirements in the best possible way. This
appliance is easy to use. It is, however, important to thoroughly read the instructions in this
handbook in order to obtain the best results.
These instructions are only valid for the countries of destination, the identification
symbols of which are indicated on the cover of the instruction manual and on the
appliance itself.
The manufacturer shall not be held responsible for any damages to persons or
property caused by incorrect installation or use of the appliance.
This cooktop has been designed and constructed in accordance with the following codes
and specifications:
AGA101 (AS 4551) Approval Requirements for Domestic Gas cooking appliances.
AS/NZS 3350-1
AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances.
AS/NSZ 1044
MOD.: DGHS70
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due
to printing or transcription errors; the designs in the figures are purely indicative. The
Manufacturer also reserves the right to make any modifications to the products as may be
considered necessary or useful, also in the interests of the user, without jeopardizing the
main functional and safety features of the products themselves.
OF MIXED AND GAS FUELLED
BUILT-IN HOT PLATES
General Requirements for Domestic electrical appliances.
Electromagnetic Compatibility Requirements.
COD. 01050AU (b) – 03.04.2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGHS70 and is the answer not in the manual?

Questions and answers

Related Manuals for DeLonghi DGHS70

Summary of Contents for DeLonghi DGHS70

  • Page 1 AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances. AS/NSZ 1044 Electromagnetic Compatibility Requirements. MOD.: DGHS70 The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors; the designs in the figures are purely indicative. The...
  • Page 2 DESCRIPTION OF THE HOT PLATES TYPES: PCFZ 60 V4 - PCFZ 60 N4 TYPES: PCFZ 70 V5 - PCFZ 70 N5 DGHS70 Propane Gas 1 Ultra rapid burner of MJ/h 11.9 11.9 2 Rapid gas burner of MJ/h 10.4 10.8...
  • Page 3 1) BURNERS A diagram is screen-printed above each knob on the front panel. This diagram indicates to which burner the knob in question corresponds. After having opened the gas mains or gas bottle tap, light the burners as described below: Manual ignition Push and turn the knob corresponding to the required burner in an anticlockwise direction until it reaches the full on position (large flame fig.
  • Page 4 Where the appliance is installed in marine craft or in caravans, it shall not be used as a space heater. If the built-in hot plate has a lid, any spilt food should be immediately removed from this before it is opened. If the appliance has a glass lid, this could shatter when the hot plate becomes hot.
  • Page 5 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig.
  • Page 6 2) HOW TO USE THE ELECTRIC PLATES Mixed hot plates may be equipped with a normal or rapid electric plates. There are controlled by switches with various positions (see fig. 6) and is switched on by turning the knob to the required setting. A diagram is screen-printed above each knob on the front panel.
  • Page 7 WARNINGS: When the plate is switched on for the first time, or if it has remained unused for a long period, it should be dried for 30 minutes on switch position n° 1. This will eliminate any moisture that may have been absorbed by the insulating material. To correctly use the appliance, remember: To place a pan on the plate before switching this on.

  • Page 8: Care & Maintainence

    CLEANING IMPORTANT: Always disconnect the appliance from the gas and electricity mains before carrying out any cleaning operation. 3) HOT PLATE Periodically wash the hot plate, the enamelled stell pan support, the enamelled burner caps “C” and the burner heads “T” (see fig. 8) with lukewarm soapy water. Following this, all parts should be thoroughly rinsed and dried.

  • Page 9: Installation

    INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER CAUTION: This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, AS5601 / AG 601 – Gas Installations and ony other relevant statutory regulations. This appliance shall only be serviced by authorized personnel.
  • Page 10 INSTALLATION 4) INSTALLING THE HOT PLATE Check that the appliance is in a good condition after having removed the outer packaging and internal wrappings from around the various loose parts. In case of doubt, do not use the appliance and contact qualified personnel. Never leave the packaging materials (cardboard, bags, polystyrene foam, nails, etc.) within children’s reach since they could become potential sources of danger.
  • Page 11 INSTALLATION FIG. 9 FIG. 10 FIG. 11 FIG. 12...

  • Page 12: Gas Connection

    Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. 7. Where the appliance data plate cannot be easily read with the appliance in the installed...
  • Page 13 INSTALLATION 7) ELECTRICAL CONNECTION The appliance is supplied with a 1800 mm long flexible supply lead. The point of attachment for this lead is located at the rear and on the underside of the appliance 380 mm from the right hand side. The voltage and power consumption are detailed on the underside of the appliance.
  • Page 14 ADJUSTMENTS Always disconnect the appliance from the electricity main before making any adjustments. All seals must be replaced by the technician at the end of any adjustments or regulations. Our burners do not require primary air adjustment. a) Data Label The Data Label is located on the underside of the hotplate.

  • Page 15: Conversion Procedure

    CONVERSION PROCEDURE 9) Propane Gas to Natural Gas conversion procedure Appliance models: Gas stainless steel hotplate models: 4 Burners 2 Burners 1 Burner 1. Remove each burner cap and burner skirt. 2. Remove the Propane Gas main injector with a 7 mm/VF tube spanner and replace with the appropriate size Natural Gas injector for each burner.
  • Page 16 CONVERSION PROCEDURE 10) Natural Gas to Propane Gas conversion procedure Appliance models: Gas stainless steel hotplate models: 4 Burners 2 Burners 1 Burner 1. Remove each burner cap and burner skirt. 2. Remove the Natural Gas main injector with a 7 mm/VF tube spanner and replace with the appropriate size Propane Gas main injector for each burner.
  • Page 17 CONVERSION PROCEDURE BURNER ARRANGEMENT ON THE HOT PLATE TABLE BURNERS NORMAL INJECTOR NOMINAL PRESSURE DIAMETER HEAT INPUT (MJ/h) N° DESCRIPTION (kPa) (1/100 mm) MAX. PROPANE 2.75 11.9 ULTRA RAPID NATURAL 1.00 11.9 PROPANE 2.75 10.8 RAPID NATURAL 1.00 10.4 PROPANE 2.75 SEMIRAPID NATURAL...

  • Page 18: Components Replacement

    SERVICING WARNING: Servicing should be carried out only by an Authorized person/Service agent. 11) COMPONENTS REPLACEMENT NOTE: BEFORE ANY MAINTENANCE REQUIRING REPLACEMENT OF A COMPONENT IS UNDERTAKEN ENSURE THAT THE ELECTRICAL LEAD HAS BEEN ISOLATED AND REMOVED FROM THE POWER POINT. To replace the components fit inside the hob is necessary to take off the pan supports and the burners from the upper part of the working table, then unscrew the burner fixing screws “V”...
  • Page 19 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY Gas hot plate H05 RR - F Section 3 X 0.75 mm Mixed plate with H05 RR - F Section 3 X 1 mm electrical plate ATTENTION!!! If the power supply cable is replaced, the installe should leave the ground wire...

  • Page 20: Service And Maintenance

    SERVICE AND MAINTENANCE If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised Delonghi Service Agent: Burner is reassembled and located correctly.
