- Page 1 D E’ LO N G HI C OO KIN G INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS D E 302 IB - 1 INDUCTION BUILT-IN COOKTOPS distributed by DeLonghi Australia Pty Ltd DeLonghi New Zealand Ltd...
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 ■ If you should decide not to use this appliance any longer (or decide to substitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous parts be made harmless, especially in relation to children who could play with unused appliances.
- Page 5 ■ Do not scratch the hob with sharp objects. Don’t use the hob as a work surface. ■ WARNING: If the hob is cracked or otherwise damaged by falling objects etc., disconnect the appliance from the electrical power supply to avoid the possibility of electric shock and call Customer Service.
-
Page 6: Installation
■ Do not seal the cooktop into the benchtop with silicone or glue; this makes future servicing difficult. Delonghi will not cover the costs of removing the cooktop, or of damage caused by this removal. ■ The walls surrounding the cooktop must be made of heat-resistant material. - Page 7 Figure 2 Figure 1 from the top of 68 mm countertop to bottom of cooktop (1) at least 50 mm between the 60 mm minimum between the side back side of the cut-out and of the cut-out and the side wall the back of the countertop.
- Page 8 FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40 mm thick. The kit includes four “F” brackets and four self-threading screws “S” (fig. 6). ■...
-
Page 9: Electrical Requirements
ELECTRICAL REQUIREMENTS ■ The appliance must be connected to the mains checking that the voltage corresponds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate. ■ A suitable isolating switch providing full disconnection from the mains power supply shall be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations. - Page 10 FEEDER CABLE SECTION This hob must be connected to electrical supply using V105 insulated cable. 220-240 V ac 3 x 2,5 mm (*) Connection with wall box connection If the supply cord (not supplied with the appliance) is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
-
Page 11: Electric Diagrams
ELECTRIC DIAGRAMS Figure 10 ID200 ID160 ELECTRIC DIAGRAM KEY ID160 Induction zone, Ø 160 mm ID200 Induction zone, Ø 200 mm User interface Lin-Bus Main supply (L, N) Terminal block... -
Page 12: Features And Technical Data
USE AND CARE FEATURES AND TECHNICAL DATA Figure 11 1. Induction cooking zone Ø 160 mm Normal Power: 1200 W Booster Power: 1400 W 2. Induction cooking zone Ø 200 mm Normal Power: 2300 W Booster Power: 3000 W 3. Touch controls Note: The Nominal and Booster Power may change depending on the size and material of the pan set on the cooking zone. -
Page 13: Touch Controls
Figure 12 TOUCH CONTROLS ON/OFF key Rear cooking zone display Front cooking zone display Front cooking zone selector key Rear cooking zone selector key Automatic cooking (timer) display Increasing key (power or timer) Decreasing key (power or timer) Notes: ■ Each selection (by touching one of the keys) is indicated by an acoustic signal (beep). -
Page 14: How To Use The Cooking Hob
HOW TO USE THE COOKING HOB The ceramic hob is fitted with induction cooking zones. These zones, shown by painted disks on the ceramic surface, are controlled by a touch control system. In the front central area of the hob, the displays of the touch control system indicate: Figure 13 = Cooking zone Off (not activated) - Page 15 REMAINING HEAT INDICATORS When the temperature of a cooking zone is still hot, the relevant remaining heat indicator lights up on the display to alert you of the hot surface. Avoid touching the hob surface over the cooking area. Please pay special attention to children.
- Page 16 HOW TO SWITCH ON/OFF THE COOKTOP Switching ON Figure 14 Touch the key until the touch control system is lit (fig. 14). The displays of the cooking zones read “ ”. Notes: ■ If the safety Child Lock protection is active, the cooktop can be used only after having deactivated this protection (see chapter CHILD LOCK SAFETY).
-
Page 17: Booster Function
BOOSTER FUNCTION This function allows the cooking zone to operate at the “Booster” maximum power (above the nominal power) for maximum 5 minutes; it could be used, for example, to rapidly heat up large amount of water. – The “Booster” function is always limited to a maximum of 5 minutes. To activate the “Booster”... -
Page 18: Operation Time Limit
OPERATION TIME LIMIT OF POWER LEVEL OF OPERATION THE COOKING ZONES COOKING ZONES TIME LIMIT Each cooking zone is automatically 480 minutes switched Off after a maximum preset time if no operation is performed. maximum preset time limit 360 minutes depends on the set power level, as illustrated in this schedule. - Page 19 COOKING COOKING COOKING ZONE ZONE ZONE POWER Ø 160 mm Ø 200 mm LEVEL (Watt power) (Watt power) 1470 1200 2300 1400 3000 EXAMPLES OF COOKING POWER SETTING Cooking zone not operating Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand Simmering Rice, pudding, sugar syrup Defrosting...
- Page 20 PROGRAM AUTOMATIC Figure 18 SWITCHING OFF OF A COOKING ZONE This function permits to set a timer from “ ” to “ ” minutes for automatic turning Off the cooking zone/s. With the cooktop switched On: ■ Select the cooking zone and set the desired power level.
- Page 21 CHILD LOCK SAFETY When not using the induction hob, set the Child Lock safety to prevent children from accidentally switching On the cooking zones. ■ Ensure all cooking zones are switched Off. ■ If the cooktop is switched off, touch the key until the touch control system is lit.
-
Page 22: Thermal Protections
MAXIMUM USABLE POWER FOR THE COOKING ZONES The power board manages a maximum total power of 3700 W. Should the cooking zones require more than 3700 W, the last selected power level has priority and the power of the other cooking zone is automatically reduced to the remaining power available. - Page 23 ERROR CODES ON THE DISPLAYS OF THE COOKING ZONES Error code Example What to do Switch Off the cooktop and disconnect it from the mains. Wait for about 1 minute, then Erxx reconnect the cooktop and turn on or Ex (not E2 or the cooking zones.
- Page 24 ADVICE FOR SAFE USE OF THE HOB Figure 23 ■ Before switching on make sure that you have the correct cooking zone for the hotplate chosen. It is advisable to put the pan on the hotplate before switching on and to take it away after switching off.
-
Page 25: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off ■ and disconnected from the electrical power supply. ■ It is advisable to clean when the appliance is cold. ■ Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the surfaces. ■... -
Page 26: Service And Maintenance
SERVICE AND MAINTENANCE Servicing the appliance: Service may be obtained by contacting our Customer Service Centre to locate the nearest Authorised Delonghi Service Agent: Servicing shall be carried out only by authorized personnel. The appliance shall not be modified. - Page 28 .au ww w.de lo nghi.co .nz...
