Use and care instructions

Advertisement

LCH
ceramic
COOKTOPS
INSTALLATION and SERVICE INSTRUCTIONS
USE and CARE INSTRUCTIONS
distributed by
DèLonghi
Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ceramic COOKTOPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DeLonghi ceramic COOKTOPS

  • Page 1 ceramic COOKTOPS INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS distributed by DèLonghi Pty Ltd...
  • Page 2: Installation

    Use and Care INSTALLATION CAUTION: In order to avoid a hazard this appliance must be installed according to these instructions for installation. WARNING: This appliance is to be installed only by an authorised person. This appliance must be used only for the task it has explicitly been designed for, that is for cooking foodstuffs.
  • Page 3 Figure 1 5 7 5 5 0 5 CLEARANCES: Installation clearances and protection of combustible surfaces shall comply with page 4. Figure 2...
  • Page 4 Use and Care Use and Care The installation shall comply with the dimensions in Figures 1 and 2, bearing in mind that: A minimum clearance of 40 mm has to be kept between the bottom of the cooking hob and the top af an appliance or a thermal barrier (see next page).
  • Page 5 THERMAL BARRIER INSTALLATION : WARNING: If the hob is installed over drawers or cupboards, a thermal protection barrier must be fitted at least 40 mm beneath the base of the hob (see Figure 3). Note: Above not applicable if hob is mounted directly above an oven. For access to the hob for servicing or installation, ensure that the barrier can be removed from beneath by the use of a tool.
  • Page 6 INSTALLATION : Apply the adhesive seal around the edge of the hob ensuring that the ends do not overlap or leave a space (Figure 4). Slot in the cooking hob into the cut out of the workbench and locate it correctly.
  • Page 7: Electrical Requirements

    ELECTRICAL REQUIREMENTS : WARNING : THIS APPLIANCE MUST BE EARTHED. In order to avoid a hazard this appliance must be installed according to these instructions for installation. CAUTION : Ensure that the power outlet is properly earthed before connecting the appliance.
  • Page 8: Electric Diagram

    ELECTRIC DIAGRAM P3 P2 P3 P2 P3 P2 ELECTRIC DIAGRAM KEY F1\F4 Electric plates changers Electric plate 1900W-3C-230V Electric plate 1200W-3C-230V Electric plate 1700W-3C-230V Electric plate 1200W-3C-230V Pilot lamp Terminal block Residual heat lamps...
  • Page 9: Use And Care

    Use and Care USE and CARE CAUTION : This appliance must be used for the task it has explicitly been designed for, that is for cooking foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. The appliance is not intended for use by young children or infirm persons without supervision.
  • Page 10 TRIPLE CIRCUIT HOTPLATES: Each hotplate is comprised of three elements which can be controlled either separately or together using the 7 position switches. The three elements can be seen in the figure 8. The temperature control knobs must be turned anti clockwise. When a plate is on, the light next to the control knob will be lit.
  • Page 11: Safety Hints

    Use and Care SAFETY HINTS : Never put cooking foil or plastic materials on the ceramic surface when the hob is hot. Make sure that the hob is clean before you use it. Remember that the plates will remain hot for approximately half an hour after the plate has been switched off.
  • Page 12: Cooking Hints

    COOKING HINTS : Switch Position Type of Cooking Switched off 1 - 2 For melting (butter, chocolate) - Keeping food warm To keep food hot to heat small quantities of liquid (sauces, etc.) To heat larger quantities e.g. Soups, Sauces, Vegetables 3 - 4 Slow boiling e.g.
  • Page 13 COOKWARE : It is very important that the pans used on the hobs are made of a suitable material and have the correct base as follows: The base should be flat and smooth. Any rough part on the pan base could scratch the hob surface. Choose pans which are the same size as the hotplates and with bases that are as non reflective as possible eg.
  • Page 14: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Before you begin cleaning you must ensure that the hob is switched off. With a damp cloth remove any dust, food particles or spillages. Spillages must be cleaned away immediately. This is essential in the case of sugar mixtures. Make sure that all traces of cleaner are removed with a soft cloth.
  • Page 15 NOTES:...
  • Page 16 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs.
