- Page 1 DE ’ L O N G H I C OO KING INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS N S L 460 X N S L 590 D X GAS COOKTOPS distributed by ELBA Appliances Australia (a Division of Fisher&Paykel Australia)
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 ■ CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations. ■ Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply. ■...
- Page 5 To avoid burns and scalds, young children should be kept away. – ■ Make sure that electrical cables connecting other appliances in the proximity of the cooktop cannot come into contact with the hob. ■ WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.
-
Page 6: Installation
INSTALLATION CAUTION: ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. ■ This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, - Gas Installations and ony other relevant statutory regulations. - Page 7 3. The wire which is coloured brown must be connected to the terminal marked “L” (Live) or “A” (Active) or coloured Red. ■ A suitable isolating switch providing full disconnection from the mains power supply (under overvoltage category III conditions) shall be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations.
- Page 8 Thermal Clearance protection barrier Door Space for Figure 2b Figure 2c connections Measures (mm) Description (minimum) (minimum) Model NSL 460 X 49 (*) 60 (**) 200 (***) Model NSL 590D X 49 (*) 60 (**) 200 (***)
- Page 9 From top of countertop (**) Between the back edge of the cut-out and the back of the countertop. (***) From the side edge of the cut-out to any vertical combustible surface. If this distance is less than 200 mm, the surface shall be protected (in accordance with AS/NZS5601.1) to a height of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area.
- Page 10 30 to 40mm thick. Model NSL 460 X (fig. 3a): The kit includes two “F” type brackets (for the front of the cooktop), two “R” type brackets (for the rear of the cooktop) and four self-threading screws “S”.
-
Page 11: Gas Supply
1 kPa: – with the two semi-rapid (SR) burners Gasket operating at the maximum - model NSL 460 X only; – with the dual (DB) burner operating Brass conical adaptor Test (Thread tight: use... - Page 12 The operation of the appliance MUST be tested before leaving. Adjust the test point pressure or supply pressure to the value which is appropriate for the gas type. Turn on the appliance gas controls and light each burner. Check for a well defined blue flame without any yellow tipping.
- Page 13 0.66 (x2) 11.40 Only for the model NSL 590D X Only for the model NSL 460 X Only for the model NSL 590D X (Note: Gas type sticker and data plate are attached to the underside of the base of the appliance.)
- Page 14 The burners are designed so that regulation of primary air is not required. Figure 5a Double-ring compact burner (only for the model NSL 460 X) Figure 5b Dual burner (only for the model NSL 590D X) Injector for...
- Page 15 MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position.
- Page 16 USE and CARE CAUTION: ■ This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. Do not use this appliance as a space heater. ■...
-
Page 17: Gas Burners
GAS BURNERS Auxiliary (A) Semirapid (SR) Semirapid (SR) Rapid (R) Double-ring compact (DRC) Dual (DB) (*) IMPORTANT: The Dual burner is controlled by two separate knobs; one knob for the inner crown only and one knob for the outer crown only. The inner and outer crown can be used together or separately. -
Page 18: Using Gas Burners
USING GAS BURNERS ■ Check that the electricity is switched on to allow spark ignition. ■ ” (burner off). Make sure that all controls are turned to “ ■ The gas flow to the burner is controlled by a tap incorporating a safety cut-off valve. If the burner flame should go out for some reason, the safety valve will automatically stop the gas flow. - Page 19 LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE In order to light the burner, you must: Turn the knob (figs. 8a - 8b) in anti-clockwise direction up to the maximum aperture (symbol “ ” ), push in and hold the knob; this will light the gas. If there is no mains electrical supply, bring a lighted match close to the burner.
- Page 20 DUAL BURNER OPERATION / CONTROL KNOBS MODEL NSL 590D X ONLY IMPORTANT: After using the dual burner check both the control ” (off) position. knobs are in the closed “ Figure 9...
- Page 21 Semi-rapid 16 cm 24 cm Rapid (model NSL 590D X) 24 cm 26 cm Double-ring compact (model NSL 460 X) 26 cm 28 cm Dual (inner crown only) (model NSL 590D X) (*) 20 cm 24 cm Dual (outer crown only) (model NSL 590D X)
- Page 22 SMALL PAN ADAPTER - MODEL NSL 590D X ONLY This adapter is to be placed: ■ on top of the Dual burner (used with the inner crown only) when using small diameter pans, in order to prevent them from tipping over. IMPORTANT: To avoid any burner malfunction: this adapter MUST be placed correctly (figs.
- Page 23 To use the WOK, you must place the wok stand in the CORRECT position as shown. IMPORTANT: The special grille for wok pans MUST BE PLACED ONLY over the pan-rest for the double-ring compact or Dual burner (depending on models). Model: NSL 460 X (with double-ring compact burner) CORRECT WRONG Figure 13a...
- Page 24 Model: NSL 590D X (with dual burner) CORRECT WRONG Figure 14a Figure 14b...
-
Page 25: Cleaning And Maintenance
CLEANING and MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off ■ and disconnected from the electrical power supply. ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. ■... - Page 26 They shall be level and the flame spreader must not rotate. CORRECT REPLACEMENT OF THE DOUBLE-RING COMPACT (model NSL 460 X only) AND DUAL BURNER (model NSL 590D X only) It is very important to check that the burner flame spreader “F1” or “F2” and the caps “A”, “B”...
- Page 27 DOUBLE-RING COMPACT BURNER (Model: NSL 460 X) Figure 15c DUAL BURNER (Model: NSL 590D X) Figure 15f Figure 15d Figure 15e...
-
Page 28: Pan Supports
This is a natural phenomenon and does not prevent the parts from working properly. Auxiliary, Semi-rapid Double-ring Dual burner & Rapid burner compact burner (model (Rapid for model (model NSL 590D X NSL 590D X only) NSL 460 X only) only) Figure 16a Figure 16b... -
Page 29: Service And Maintenance
SERVICE AND MAINTENANCE If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised ELBA APPLIANCES Service Agent shared services with Fisher and Paykel Australia PTY LTD (ELBA Appliances AUS, a division of F&P AUS PTY LTD). - Page 32 Descri pt i ons an d ill ustrati ons in this booklet a re giv en as simpl y ind icat ive. T h e ma nuf a ct ur er r es erv es the right, consider ing t he cha ract eri stics o f t he models described here, at any time and without notice, to make eventual necessary mo d ifi cat i on s f or the ir constr ucti on or for com merc ial n eeds.
