- Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS DEH60S DEH60W ELECTRIC COOKTOPS distributed by DèLonghi Pty Ltd...
-
Page 2: Installation
INSTALLATION CAUTION: ■ In order to avoid a hazard this appliance must be installed accord- ing to these instructions for installation. WARNING: ■ This appliance is to be installed only by an authorised person. ■ This appliance must be used only for the task it has explicitly been designed for, that is for cooking foodstuffs. - Page 3 This cooktop has been designed and constructed in accordance with the following codes and specifications: AS/NZS 60335-1 General Requirements for Domestic electrical appliances AS/NZS 60335-2-6 Particular Requirements for Domestic electrical cooking appliances AS/NSZ 1044 Electromagnetic Compatibility Requirements. Figure 1 CLEARANCES: Installation clearances and protection of combustible surfaces shall comply with page 4.
- Page 4 The installation shall comply with the dimensions in Figures 1 and 2, bearing in mind that: ■ A minimum clearance of 30 mm has to be kept between the bottom of the cooking hob and the top of an appliance or a thermal barrier (see next page).
- Page 5 THERMAL BARRIER INSTALLATION: Warning: ■ If the hob is installed over drawers or cupboards, a thermal protec- tion barrier must be fitted at least 30 mm beneath the base of the hob (see Figure 3). Note: 1. Above not applicable if hob is mounted directly above an oven 2.
- Page 6 INSTALLATION 1. Spread out the gasket “C” over the workbench at the edge of the cut out taking care to overlap the gasket at the corners. 2. Slot in the cooking hob into the cut out of the workbench and locate it correctly.
-
Page 7: Electrical Requirements
ELECTRICAL REQUIREMENTS Warning: ■ THIS APPLIANCE MUST BE EARTHED. ■ In order to avoid a hazard this appliance must be installed according to these instructions for installation. Caution: ■ If the supply cord is damaged it must be replaced by the manufactur- er or it’... - Page 8 FEEDER CABLE CONNECTION To connect the feeder cable to the cooking hobs with electrical plates or to replace, if necessary, some electrical part, it is necessary to: ■ Upturn the hob ■ Unscrew screws “A” and remove protection “B” (fig. 5) ■...
- Page 9 FEEDER SPECIAL CABLE SECTION Type “HO5V2V2-F” Figure 6 resistance to temperatures of 90°C 220-240 V ~ 50 Hz 3 x 2,50 mm 220-240 V 50 Hz 380-416 V 3N ~ 50 Hz 5 x 1,50 mm 3 4 5 380-416 V 2N ~ 50 Hz 4 x 1,50 mm 220-240 V 3 ~ 50 Hz 4 x 2,50 mm...
-
Page 10: Electric Diagram
ELECTRIC DIAGRAM Figure 8 ELECTRIC DIAGRAM KEY F1/2/3/4 Electric plate commutators Line pilot lamp Electric plate 2000W -230V Electric plate 1500W-230V Electric plate 1500W-230V Electric plate 1000W-230V Terminal block Earth connection... -
Page 11: Control Panel
USE and CARE CAUTION: ■ This appliance must be used only for the task it has explicitly been designed for, that is for cooking foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. ■ Do NOT place combustible materials or products on this appliance at any time. - Page 12 ■ Important: Before using the hob for the first time, it is necessary to burn off the appliance to dry off the plates and remove any protective coatings that may still be on the plates. To do this, boil a saucepan of water on each plate for about 10 minutes.
-
Page 13: Cooking Hints
COOKING HINTS: ■ Be careful not to place any wet or steamed up lids on an unused hotplate, as this will lead to rust. ■ Pans should have a thick flat base to be effective. Check the base of the pan with a ruler. -
Page 14: Cleaning And Maintenance
All the enamelled parts must be washed only with a sponge with soapy water or other non-abrasive products. ■ Dry carefully. Stainless steel hob - mod. DEH60S ■ Clean with special products which are available on the market. ■ Dry preferably with a microfibre or soft cloth. -
Page 15: Troubleshooting
TROUBLESHOOTING: If you acquire a problem with your hob, check the following points before calling an engineer. 1. The power is switched on. 2. The controls are switched on. 3. Both the fuse and the mains fuse are intact. Servicing the appliance: Service may be obtained from your local Authorised Service Centre. - Page 16 cod. 1103193 - ß1...
