INSTALLATION and SERVICE INSTRUCTIONS
USE and CARE INSTRUCTIONS
COOKTOP
LGHW60
LGHS60
DGHS60
distributed by
DèLonghi
Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LGHW60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DeLonghi LGHW60

  • Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS COOKTOP LGHW60 LGHS60 DGHS60 distributed by DèLonghi Pty Ltd...
  • Page 2: Product Label

    Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
  • Page 3: Important Precautions And Recommendations

    IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL APPLIANCES Use of any electrical appliance implies the necessity to follow a series of fundamental rules. In particular: Never touch the appliance with wet hands or feet; do not operate the appliance barefooted; do not allow children or other incapable people to use the appliance without supervision.
  • Page 4: Installation

    INSTALLATION CAUTION: This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, AS5601 / AG 601 - Gas Installations and ony other relevant statutory regulations. This appliance shall only be serviced by authorized personnel. This appliance is to be installed only by an authorised person.
  • Page 5 This cooktop has been designed and constructed in accordance with the following codes and specifications: AGA101 (AS 4551) Approval Requirements for Domestic Gas cooking appliances AS/NZS 3350-1 General Requirements for Domestic electrical appliances AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances AS/NSZ 1044 Electromagnetic Compatibility Requirements.
  • Page 6 The installation shall comply with the dimensions in Figures 1 and 2, bearing in mind that: A minimum clearance of 20 mm has to be kept between the bottom of the cooking hob and the top of an appliance or a shelf. To ensure this clearance mount the spacers, supplied with the appliance, as shown in the figure below.
  • Page 7 INSTALLATION (Refer to Figure 4) 1. Spread out the gasket “C” over the workbench at the edge of the cut out tak- ing care to overlap the gasket at the corners. 2. Slot in the cooking hob into the cut out of the workbench and locate it cor- rectly.
  • Page 8: Gas Supply

    GAS SUPPLY: This appliance is suitable for use with Natural Gas or Propane gas. (Check the “gas type” sticker attached to the appliance). For Natural Gas the gas supply must be regulated to obtain a pressure of 1 kPa with the two semi-rapid (SR) burners operating.
  • Page 9 Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. 7. Where the appliance data plate cannot be easily read with the appliance in the...
  • Page 10: Replacing The Injectors

    CONVERSION PROCEDURE (to convert to LPG Propane) REPLACING THE INJECTORS The conversion procedure must be carried out only by an authorised person. This appliance is suitable for use with Natural gas or Propane gas (check the “gas type” sticker attached to the appliance). The nominal gas consumption and injector size details are provided in table at page 9.
  • Page 11 MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position.
  • Page 12: Electrical Requirements

    ELECTRICAL REQUIREMENTS: WARNING: THIS APPLIANCE MUST BE EARTHED. CAUTION: Ensure that the power outlet is properly earthed before connecting the appliance. Disconnect power before servicing the appliance. The appliance is provided with a standard 240VAC three pin plug and power cable (3 x 0.75 mm The wires in the power cable are coloured in accordance with the following code: Green/Yellow = Earth, Blue = Neutral, Brown = Active.
  • Page 13: Use And Care

    USE and CARE CAUTION: This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be con- sidered as inappropriate and therefore dangerous. Do not use this appliance as a space heater.
  • Page 14: Gas Burners

    GAS HOB Figure 11a Figure 11b mod. LGHW60 mod. DGHS60 mod. LGHS60 The electric ignition is incorporated in The hob is fitted with a safety cut-out the knobs device This appliance is class 3 The electric ignition is incorporated in...
  • Page 15 If after relighting the burner, the flame is still abnormal, turn the burner off and contact our Customer Service Centre to obtain the nearest authorized Delonghi Service Agent. In the case of a mains failure light the burner with a match or lighted taper.
  • Page 16 If after relighting the burner, the flame is still abnormal, turn the burner off and contact our Customer Service Centre to obtain the nearest authorized Delonghi Service Agent. Lighting the burners WITH ELECTRIC IGNITION (fitted with safety cut-off valve) mod.
  • Page 17 COOKING HINTS FOR GAS HOBS The burner must be chosen according to the diameter of the pans and energy required. For optimum efficiency use a wok or pan no smaller than 230mm diameter. Figure 12 do not use pans with concave or convex bases Burners Pan diameter Auxiliary...
  • Page 18 The flat-bottomed pans are to be placed directly onto the pan-support. To use the WOK, you must place the wok stand in the CORRECT position as shown in fig. 14a - 14b. mod. LGHW60 - LGHS60 Figure 14a WRONG CORRECT mod.
  • Page 19: Cleaning And Maintenance

    GAS TAPS Regular lubrication of the gas taps must only be performed by Authorized person. If the gas taps are not working properly, call our Customer Service Centre to obtain the nearest Authorized Delonghi Service Agent.
  • Page 20 CORRECT POSITIONING OF THE BURNERS It is very important to check that spreader F and cap C of the burner (see Figure 15) are perfectly in place because if they move out of place serious problems could arise. Make sure that electrode "S" (Fig. 15) is kept clean so that the sparks always strike. TRIPLE-RING BURNER The triple ring burner must be correctly positioned (see fig.
  • Page 21: Service And Maintenance

    Note that a bi-annual inspection of the appliance by an authorized service agent or your locate gas utility will ensure many years of trouble free operation of your appliance. Servicing the appliance: Service may be obtained by contacting our Customer Service Centre to locate the nearest Authorised Delonghi Service Agent:...
  • Page 23 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs.
  • Page 24 cod. 1102597 ß1...
