B U I L T - I N
DEGCT424F..
Model
• USERS OPERATING INSTRUCTIONS
• INSTALLATION ADVICE
IMPORTANT - PLEASE READ AND FOLLOW
Before beginning, please read these instructions completely and carefully.
Do not remove permanently affixed labels, warnings, or plates from the product. This
may void the warranty.
Please observe all local and national codes and ordinances.
Please ensure that this product is properly grounded.
The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
The electrical plug should always be accessible
Installation must conform with local codes or in the absence of codes, the National Fuel
Gas Code ANSIZ223.1 - Iatest edition. Electrical installation must be in accordance with the
National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes. IN CANADA:
Installation must be in accordance with the current CAN/CGA-B149.1 National Gas
Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian
Electrical Codes Part 1 and/or local codes.
Installation of any gas-fired equipment should be made by a Iicensed plumber. A manual
gas shut-off valve must be installed in the gas supply line ahead of the appliance in the gas
stream for safety and ease of service.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT
FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• lmmediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• lf you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
G A S
C O O K T O P
with safety valve device

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEGCT424FSS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DeLonghi DEGCT424FSS

  • Page 1 B U I L T - I N DEGCT424F.. Model • USERS OPERATING INSTRUCTIONS • INSTALLATION ADVICE IMPORTANT - PLEASE READ AND FOLLOW Before beginning, please read these instructions completely and carefully. Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty.
  • Page 2 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. Please preserve this booklet carefully.
  • Page 3: Important Precautions And Recommendations

    USER INSTRUCTIONS IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the appliance, check to ensure that it is not damaged. If you have any doubts, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries.
  • Page 4: Control Panel Description

    Fig. 1.1 features COOKING POINTS 1. Auxiliary burner (AUX) - 3.500 BTU/hr 2. Semirapid burner (SR) - 6.000 BTU/hr 3. Triple ring burner (TC) - 11.500 BTU/hr CONTROL PANEL DESCRIPTION 4. Auxiliary burner (AUX) control knob (1) 5. Right semirapid burner (SR) control knob (2) 6.
  • Page 5: Using The Gas Cooktop

    using the gas cooktop GAS BURNERS Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1) which control the valves. Turning the knob so that the indicator line points to the symbols printed on the panel achieves the following functions: = closed valve = maximum rate...
  • Page 6: Cleaning And Maintenance

    Do not use steam jet cleaners because the humidity could infiltrate into the appliance making it dangerous. cleaning and maintenance GENERAL RECOMANDATION Before you begin cleaning you must ensure that the hob is switched off. It is advisable to clean when the appliance is cold. All enamelled surfaces have to be washed with soapy water or some other non- abrasive product with a sponge and are to be dried preferably with a soft cloth.
  • Page 7: Correct Replacement Of The Burners

    CORRECT REPLACEMENT OF THE BURNERS It is very important to check that the burner flame spreader “F” and the cap “C” have been correctly positioned (see figs. 3.1 and 3.2 ). Failure to do so can cause serious problems. In appliances with electric ignition, check that the electrode “S”...
  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE HAS TO BE INSTALLED BY A QUALIFIED INSTALLER. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer, service agent, or the gas supplier. TOOLS NEEDED FOR INSTALLATION Screwdriver Wrench T-handle wrench...
  • Page 9: General Information

    GENERAL INFORMATION 1. Installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1-Latest Edition. 2. Installation in manufactured (mobile) home: installation must conform with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)] or, when such standard is not applicable, the Standard for Manufactured Home...
  • Page 10: Cooktop Dimensions

    installation to the cabinet COOKTOP DIMENSIONS 22” 53/64 (580 mm) (CUT-OUT) min 4" Fig. 4.1b 22” 1/64 (102 mm) (560 mm) from cut-out BOX DIMENSIONS Fig. 4.1c Fig. 4.1a min 20" (CUT-OUT) (508 mm) 22” 1/64 from cut-out (560 mm) Fig.
  • Page 11: Proximity To Side Cabinets

    PROXIMITY TO SIDE CABINETS 1. The cooktop may be installed directly to existing base cabinets. 24" (610 mm) minimum deep countertop is required. Cooktop dimensions: - width = 22” (580 mm); 53/64 - depth = 19” (500 mm). 11/16 Cut-out dimensions: - width = 22”...
  • Page 12: Gas Connection

    Explosion Hazard Use a new CSA or UL approved gas supply line. Install a shut-off valve. Securely tighten all gas connec- tions. If connected to LP, have a quali- fied person make sure gas pres- sure does not exceed 14" water column.
  • Page 13 PRESSURE REGULATOR INSTALLATION STEP 1 The elbow connection can be turned in the direction required after the manifold female pipe fitting has been slackened by using a wrench. Then tighten the elbow-manifold female pipe fitting connection by using a wrench before proceeding with gas connection. When tightening keep the elbow connection firm i.e.
  • Page 14 GAS CONNECTION SPECIFICATION Elbow connection 1/2” G cylindrical (ISO 228-1) male Gasket Extension Extension pipe female pipe female pipe fitting pipe fitting Extension pipe male pipe fitting Gasket 3/8” NPT (conical) male Pressure regulator Gasket Manifold female pipe fitting 1/2” G cylindrical (ISO 228-1) female To cooktop Extension...
  • Page 15: Flexible Connections

    b) Any conversion required must be performed by your dealer or a qualified licensed plumber or gas service company. Please provide the service person with this manual before work is started on the cooktop. (Gas conversions are the responsibility of the dealer or end user.) c) This cooktop can be used with NATURAL or LP/PROPANE gas.
  • Page 16: Leak Testing

    4. Rigid Pipe Connections: If rigid pipe is used as a gas supply line, a combination of pipe fittings must be used to obtain an in-line connection to the cooktop. All strains must be removed from the supply and fuel lines so cooktop will be level and in line. •...
  • Page 17: Injectors Table

    OPERATIONS TO BE PERFORMED WHEN SUBSTITUTING THE INJECTORS Remove the gratings, the burner covers and the knobs; Using a wrench substitute the nozzle injectors “J” (figs. 5.6a - 5.6b) with those most suitable for the kind of gas for which it is to be used. The burner are conceived in such a way so as not to require the regulation of the primary air.
  • Page 18: Electrical Connection

    WARNING Electrical Shock Hazard Plug into a grounded 3-prong outlet. Do not remove ground prong. Do not use an adapter. Failure to follow these instructions can result in death, fire, or electrical shock. electrical connection If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.
  • Page 19: Wiring Diagram Key

    WIRING DIAGRAM Wiring diagram key Ignition coil Ignition switches group Terminal block Igniter Fig. 6.2...
  • Page 20 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
