- Page 1 D E’ LO N G HI C OO KIN G INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS D EGH SL 6 0 D EGH SL 7 5 D EGH SL 9 0 GAS COOKTOPS distributed by DeLonghi Australia Pty Ltd DeLonghi New Zealand Ltd...
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not touch the appliance with wet or damp hands (or feet). • Do not use the appliance whilst in barefoot. • If you should decide not to use this appliance any longer (or decide to substitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous...
-
Page 5: This Appliance
• CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. • WARNING: Danger of fire: do not store items on the cooking surfaces. • WARNING: If the hob is cracked or otherwise damaged by falling objects etc., disconnect the appliance from the electrical power supply to avoid the possibility of electric shock and call Customer Service. -
Page 6: Installation
INSTALLATION CAUTION: ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. ■ This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, - Gas Installations and ony other relevant statutory regulations. - Page 7 3. The wire which is coloured brown must be connected to the terminal marked “L” (Live) or “A” (Active) or coloured Red. ■ A suitable isolating switch providing full disconnection from the mains power supply (under overvoltage category III conditions) shall be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations.
- Page 8 Clearance protection barrier Door Space for Figure 2b Figure 2c connections Measures (mm) Description (minimum) (minimum) Model DEGHSL60 49 (*) 60 (**) 200 (***) Model DEGHSL75 49 (*) 60 (**) 200 (***) Model DEGHSL90 49 (*) 60 (**) 200 (***)
- Page 9 From top of countertop (**) Between the back edge of the cut-out and the back of the countertop. (***) From the side edge of the cut-out to any vertical combustible surface. If this distance is less than 200 mm, the surface shall be protected (in accordance with AS/NZS5601) to a height of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area.
- Page 10 Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40mm thick. Models DEGHSL60, DEGHSL75 (fig. 3a): The kit includes two “F” type brackets (for the front of the cooktop), two “R” type brackets (for the rear of the cooktop) and four self- threading screws “S”.
-
Page 11: Gas Supply
For Natural Gas the gas supply must be regulated to obtain a pressure of 1 kPa: – with the two semi-rapid (SR) burners Gasket operating at the maximum - model DEGHSL60 only; Brass conical adaptor Test – with the triple-ring (TR) burner (Thread tight: use point... - Page 12 Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. Where the appliance data plate cannot be easily read with the appliance in the...
- Page 13 0.66 (x2) 11.40 Only for the models DEGHSL75, DEGHSL90 Only for the model DEGHSL60 Only for the model DEGHSL75 Only for the model DEGHSL90 (Note: Gas type sticker and data plate are attached to the underside of the base of the appliance.)
- Page 14 Figure 5a The burners are designed so that regulation of primary air is not required. Triple-ring compact burner (only for the model DEGHSL60) Figure 5b Dual burner (only for the model DEGHSL90) Triple-ring burner (only for the model DEGHSL75) Injector for...
- Page 15 MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position.
- Page 16 Before using for the first time, clean the cooktop with warm soapy water. ■ DO NOT MODIFY THIS APPLIANCE. ■ IMPORTANT NOTE: THIS APPLIANCE SHALL NOT BE USED AS A SPACE HEATER, ESPECIALLY IF INSTALLED IN MARINE CRAFT OR CARAVANS. Mode l: DEGHSL60 Figure 7a M odel: DEGHSL75 Figure 7b 10 13...
-
Page 17: Gas Burners
Mo de l: DEGHSL90 Figure 7c 15 14 8 9 10 11 GAS BURNERS Auxiliary (A) Semi-rapid (SR) Semi-rapid (SR) Rapid (R) Triple-ring compact (TRC) Triple-ring (TR) Dual (DB) (*) IMPORTANT: The Dual burner (model DEGHSL90 only) is controlled by two separate knobs;... -
Page 18: Using Gas Burners
■ If after relighting the burner, the flame is still abnormal, turn the burner off and contact our Customer Service Centre to obtain the nearest authorized Delonghi Service Agent. ■ In the case of a mains failure light the burner with a match or lighted taper. - Page 19 LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE In order to light the burner, you must: Turn the knob (figs. 8a - 8b) in anti-clockwise direction up to the maximum aperture (symbol “ ” ), push in and hold the knob; this will light the gas. If there is no mains electrical supply, bring a lighted match close to the burner.
- Page 20 DUAL BURNER OPERATION/CONTROL KNOBS MODEL DEGHSL90 ONLY IMPORTANT: After using the dual burner check both the control knobs are in the closed “ ” position. Figure 9...
- Page 21 6 cm 14 cm Semi-rapid 16 cm 24 cm Rapid (models DEGHSL75, DEGHSL90) 24 cm 26 cm Triple-ring compact (model DEGHSL60) 26 cm 28 cm Triple-ring (model DEGHSL75) 26 cm 28 cm Dual (inner crown only) (model DEGHSL90) (*) 20 cm...
- Page 22 SMALL PAN ADAPTER - MODEL DEGHSL90 ONLY This adapter is to be placed: ■ on top of the Dual burner (used with the inner crown only) when using small diameter pans, in order to prevent them from tipping over. IMPORTANT: To avoid any burner malfunction: ■...
- Page 23 To use the WOK, you must place the wok stand in the CORRECT position as shown. IMPORTANT: The special grille for wok pans MUST BE PLACED ONLY over the pan-rest for the triple-ring compact, triple ring or Dual burner (depending on models). Model: DEGHSL60 (with triple-ring compact burner) WRONG CORRECT Figure 12a...
- Page 24 Model: DEGHSL75 (with triple-ring burner) WRONG CORRECT Figure 13a Figure 13b Model: DEGHSL90 (with dual burner) WRONG CORRECT Figure 14a Figure 14b...
-
Page 25: Cleaning And Maintenance
CLEANING and MAINTENANCE GENERAL ADVICE ■ Before you begin cleaning, you must ensure that the appliance is switched off and disconnected from the electrical power supply. ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. Under no circumstances should any external covers be removed for servicing or ■... - Page 26 They shall be level and the flame spreader must not rotate. CORRECT REPLACEMENT OF THE TRIPLE-RING COMPACT (model DEGHSL60 only), TRIPLE-RING (model DEGHSL75 only) AND DUAL BURNER (model DEGHSL90 only) It is very important to check that the burner flame spreader “F1”, “F2” or “F3” and the caps “A”, “B”...
- Page 27 TRIPLE-RING COMPACT BURNER TRIPLE-RING BURNER (Model: DEGHSL60) (Model:DEGHSL75) Figure 15c Figure 15d DUAL BURNER (Model: DEGHSL90) Figure 15e Figure 15f Figure 15g...
-
Page 28: Pan Supports
The raised portion of the pan supports shall NOT face the sides of the cooktop (fig. 16b). Auxiliary, Semi-rapid & Triple-ring compact Triple-ring burner (model Rapid burner (Rapid for burner (model DEGHSL75 only) & models DEGHSL75 & DEGHSL60 only) Dual burner (model DEGHSL90 only) DEGHSL90 only) Figure 16a Figure 16b... -
Page 29: Service And Maintenance
SERVICE AND MAINTENANCE If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised Delonghi Service Agent: ■ Burner is reassembled and located correctly. - Page 32 .au ww w.de lo nghi.co .nz...
