- Page 1 D E’ LO N GH I C O OKI N G INSTALLATION and SERVICE INSTRUC TIONS USE and CARE INSTRUC TIONS P VC 61 SK CERAMIC COOKTOP distributed by ELBA Appliances Australia (a Division of Fisher&Paykel Australia)
-
Page 3: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 4: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 5 • Do not operate your appliance by means of an external timer or separate remote-control system. • Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply. • Do not use a steam cleaner because the moisture can get into the appliance therefore making it unsafe.
- Page 6 WARNING: During use the appliance and its accessible parts • become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on – the hob. To avoid burns and scalds, young children should be kept –...
- Page 7 If the appliance is not fitted with a supply cord and a plug, or with • other means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under overvoltage category III conditions, means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
- Page 9 Advice for the installer...
-
Page 10: Installation
INSTALLATION IMPORTANT: • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have. -
Page 11: Standard Installation
STANDARD INSTALLATION Fig. 1.1a FLUSH INSTALLATION (MODELS WITHOUT METAL TRIM/S ONLY) If you wish to install the hob flush with the work surface, it is neccessary to execute/carry out a miling in the hole of the cut-out as indicated in fig. 1.1b. Fig. - Page 12 FITTING REQUIREMENTS This cooktop can be built into a working surface from 20 mm thick and 600 mm deep. In order to install the ceramic hob into the kitchen fixture, a hole with the dimensions shown in figures 1.1a and 1.1b has to be made, keeping in consideration the following: •...
- Page 13 FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 20 mm thick. Before you install the cooktop, make sure that the work surface is square and level, and no structural members interfere with space requirements previously indicated.
-
Page 14: Electrical Section
ELECTRICAL SECTION IMPORTANT: Installation must be carried out according to the manufacturer’s instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains. - Page 15 CONNECTION OF THE POWER SUPPLY CABLE Important! This cooktop must be connected to the electricity supply only by an authorised person. To connect the feeder cable to the hob it is necessary to carry out the following operations: Unhook the terminal board cover “A” by inserting a screwdriver into the two hooks “B” •...
- Page 16 Fig. 2.1 Fig. 2.2 220 - 240 V ac (V 2 ac) 380 - 415 V 2N ac 380 - 415 V 3N ac 220 - 240 V~ 380 - 415 V 2N~ 380 - 415 V 3N~ N (L...
- Page 17 MODELS SUPPLIED WITH POWER CORD 5x1,5 mm ALREADY FITTED TO THE APPLIANCE The cooktop is supplied with a power cord already fitted to the appliance and it is • suitable for a single-phase type electrical connection (fig. 2.3). For the two-phase type electrical connection (fig. 2.4): •...
- Page 18 “220-240 V ac (V 2 ac)” “380-415 V 2N ac” “380-415 V 3N ac” connection connection connection Green - Yellow Green - Yellow Green - Yellow Blue and Grey Blue and Grey Blue Black and Brown Black Black Brown Brown Grey 220-240 V ac 220-240 V ac (V 2 ac)
-
Page 19: Electric Diagram
ELECTRIC DIAGRAM... - Page 21 User guide...
-
Page 22: Features And Technical Data
FEATURES AND TECHNICAL DATA Fig. 1.1... -
Page 23: Cooking Zones
Electrical insulation Class I COOKING ZONES ‘Hi-light’ cooking zone Ø 140 mm - 1200 W ‘Hi-light’ cooking zone Ø 180 mm - 1800 W Double ‘Hi-light’ cooking zone Ø 180/120 mm - 1700/700 W CONTROLS DESCRIPTION Front right cooking zone control knob Front left cooking zone control knob Rear left cooking zone control knob Rear right cooking zone control knob... - Page 24 HOW TO USE THE HOB The ceramic surface of the hob allows a fast transmission of heat in the vertical direction, from the heating elements underneath the ceramic glass to the pans set on it. The heat does not spread in a horizontal direction, so that the glass stays “cool” at only a few centimeters from the cooking plate.
- Page 25 By switching on the second element (fig. 2.3), the surface area of the double zone can • be extended. To turn on both zones, turn the control knob fully clockwise to the position Note: if you leave the knob at the position , the full double element will remain at the highest heat setting.
-
Page 26: Cooking Hints
COOKING HINTS Cooking zone Knob knob TYPE OF COOKING setting setting Switched OFF melting operations (butter, chocolate). To maintain food hot and to heat small quantities of liquid (sauces, eggs). To heat bigger quantities; to whip creams and sauces (vegetables, fruits, soups). Slow boiling, i.e.: boiled meats, spaghetti,... -
Page 27: Residual Heat Indicators
RESIDUAL HEAT INDICATORS The hob also features 4 warning lamps which are wired to the corresponding plate. When the temperature of a cooking plate is over 60°C, the relevant warning lamp is also litup to warn of heat on the surface of the hob. These lamps also stay on after the cooking plates have been switched off to shown that the hob surface is still hot. -
Page 28: Safety Hints
SAFETY HINTS Before you switch the hob on, make sure you • DISTORTED know which control operates the required PANBASE cooking zone. It is advisable to put the pan WRONG on the hotplate before switching on and to take it away after switching off. You should use pots and pans with flat bases •... -
Page 29: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off • and disconnected from the electrical power supply. • It is advisable to clean when the appliance is cold. • Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the surfaces. •... -
Page 30: Cleaning The Ceramic Hob
CLEANING THE CERAMIC HOB • Remove spillages and other types of incrustations. • Dust or food particles can be removed with a damp cloth. • If you use a detergent, please make sure that it is not abrasive or scouring. Abrasive or scouring powders can damage the glass surface of the hob. -
Page 31: Service And Maintenance
SERVICE AND MAINTENANCE Servicing the appliance: Service may be obtained by contacting our Customer Service Centre to locate the nearest Authorised ELBA APPLIANCES Service Agent shared services with Fisher and Paykel Australia PTY LTD (ELBA Appliances AUS, a division of F&P AUS PTY LTD).: Servicing shall be carried out only by authorized personnel. - Page 32 Descri pt ion s an d illu st ra tion s in this book l et ar e given as simpl y indicati ve. T he m an uf a ct u r er re s erv es t he right , c onsidering the charact erist ics of t he models d escr ib ed h e re , at any time and wit ho ut notice, t o make even tual nece ssary modifi cat io ns f or t h e ir c o ns truc t ion or f or c om mercial ne eds.
