D E’ LO N G HI C OO KIN G INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS D EI ND6 03 D EI ND6 04 D EI ND8 04 INDUCTION BUILT-IN COOKTOPS distributed by DeLonghi Australia Pty Ltd DeLonghi New Zealand Ltd...
Dear Customer, Thank you for having purchased and given your preferen- ce to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the fea- tures offered by your appliance.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL APPLIANCES Use of any electrical appliance implies the necessity to follow a se- ries of fundamental rules. In particular: ■ Never touch the appliance with wet hands or feet. ■ Do not operate the appliance barefooted. ■...
Page 4
■ WARNING: Accessible parts will become hot when in use. To avoid burns and scalds, young children should be kept away. ■ Young children should be supervised to ensure that they do not play with the appliance. ■ Children, or persons with a disability which limits their ability to use the appliance, should have a responsible person to instruct them in its use.
Page 5
OTHER IMPORTANT PRECAUTIONS AND RECOMMENDATIONS ■ Do not place or leave empty pans on the glass ceramic hob. ■ Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. ■...
■ Do not seal the cooktop into the benchtop with silicone or glue; this makes futu- re servicing difficult. Delonghi will not cover the costs of removing the cooktop, or of damage caused by this removal. The walls surrounding the cooktop must be made of heat-resistant material.
Page 7
Figure 1 Mod. DEIND603 Mod. DEIND604 Mod. DEIND804 from the top of 58 mm countertop to bottom of cooktop (1) at least 50 mm between the back side of the cut-out and the back of the countertop.
Page 8
Figure 2 70 mm minimum between the side of the cut-out and the side wall Figure 3 Figure 4 min 5 mm min 5 mm Oven with cooling fan min 30 mm min 30 mm Minimum clearances and Minimum clearances and ventilation requirements ventilation requirements (oven installed below)
Page 9
FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40 mm thick. The kit includes four “F” brackets and four self-threading screws “S” (fig. 6). ■...
Strain the feeder cable and block it with cable clamp “D” (by hooking hook “E” and screwing screw “C”). ■ Close the cover “A” of the terminal board “F” (check the two hooks “B” are correctly hooked). VOLTAGE AND POWER CONSUMPTION Mod. DEIND603 220-240/380-415 V 3N~ 50/60 Hz 6700 W 29.13 A (diversity not applied) Mod.
Page 11
FEEDER CABLE SECTION This hob must be connected to electrical supply using V105 insulated cable. 220-240 V ac 3 x 4 mm (*) (**) 380-415 V 2N ac 4 x 2.5 mm (*) (**) 380-415 V 3N ac 5 x 2.5 mm (*) (**) (*) Connection with wall box connection (**) Notes for models DEIND604, DEIND804 only:...
ELECTRIC DIAGRAMS Model DEIND603 Figure 9 Models DEIND604, DEIND804 Figure 10...
Page 13
ELECTRIC DIAGRAM KEY ID160 Induction zone, Ø 160 mm ID200 Induction zone, Ø 200 mm ID250 Induction zone, Ø 250 mm User interface Lin-Bus Interface power supply Main supply (L, N) Terminal block...
USE AND CARE FEATURES AND TECHNICAL DATA Mod. DEIND603 Mod. DEIND604 Figure 11 Figure 12 Mod. DEIND804 Figure 13 1. Induction cooking zone Ø 160 mm Normal Power: 1200 W Booster Power: 1400 W 2. Induction cooking zone Ø 160 mm Normal Power: 1400 W 3.
CHILD LOCK SAFETY) Pause function key Front right cooking zone display (for models DEIND604, DEIND804 only) Rear right cooking zone display (or Central right zone desplay for model DEIND603 only) Front left cooking zone display Rear left cooking zone display Automatic cooking timer key/display 10.
HOW TO USE THE COOKING HOB The ceramic hob is fitted with induction cooking zones. These zones, shown by painted disks on the ceramic surface, are controlled by a touch control system. In the front central area of the hob, the displays of the touch control system indicate: = Cooking zone Off (not activated) Figure 15...
Page 17
REMAINING HEAT INDICATORS When the temperature of a cooking zone is still hot, the relevant remaining heat indica- tor lights up on the display to alert you of the hot surface. Avoid touching the hob surface over the cooking area. Please pay special attention to children.
Page 18
HOW TO SWITCH ON/OFF THE COOKTOP Switching ON Figure 16 Touch the key until the touch control system is lit (fig. 16). The displays of the cooking zones read “ ”. Notes: ■ If the safety Child Lock protection is active, the cooktop can be used only after having deactivated this protec- tion (see chapter CHILD LOCK SA-...
BOOSTER FUNCTION This function allows the cooking zone to operate at the “Booster” maximum power (above the nominal power) for maximum 5 minutes; it could be used, for example, to rapidly heat up large amount of water. – The “Booster” function is always limited to a maximum of 5 minutes. –...
Page 20
OPERATION TIME LIMIT OF POWER LEVEL OF OPERATION THE COOKING ZONES COOKING ZONES TIME LIMIT Each cooking zone is automatically 480 minutes switched Off after a maximum preset time if no operation is performed. The maximum preset time limit depen- 360 minutes ds on the set power level, as illustra- ted in this schedule.
Page 21
2300 not available 1400 3000 3000 (*) only for models DEIND604, DEIND804 ((*) only for model DEIND603 EXAMPLES OF COOKING POWER SETTING Cooking zone not operating Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand Simmering Rice, pudding, sugar syrup...
Page 22
PROGRAM AUTOMATIC Figure 20 SWITCHING OFF OF A COOKING ZONE This function permits to set a timer from “ ” to “ ” minutes for automatic turning Off the cooking zone/s. With the cooktop switched On: ■ Select the cooking zone and set the de- sired power level.
The program for automatic switch Off can be cancelled at any time: ■ Select the programmed cooking zone by touching the relevant display of the cooking zone. ■ Touch one time the timer key and then, within 8 seconds, the timer display will switch Off.
MAXIMUM USABLE POWER FOR THE Figure 26 Controlled by COOKING ZONES 1st power board The left and right cooking zones are controlled by two separate power boards. Where a power board manages two zones (front/rear LH zones; front/rear RH zones in model with four zones) the maximum total po- wer per each power board is 3700 W.
Page 25
ERROR CODES ON THE DISPLAYS OF THE COOKING ZONES Error code Example What to do Switch Off the cooktop and discon- nect it from the mains. Wait for about 1 minute, then recon- Erxx nect the cooktop and turn on the co- or Ex (not E2 or oking zones.
Page 26
ADVICE FOR SAFE USE OF THE HOB Figure 27 ■ Before switching on make sure that you have the correct cooking zone for the hotplate chosen. It is advisable to put the pan on the hotplate before switching on and to take it away after switching off.
CLEANING AND MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off ■ and disconnected from the electrical power supply. ■ It is advisable to clean when the appliance is cold. ■ Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the surfaces. ■...
SERVICE AND MAINTENANCE Servicing the appliance: Service may be obtained by contacting our Customer Service Centre to locate the nearest Authorised Delonghi Service Agent: Servicing shall be carried out only by authorized personnel. The appliance shall not be modified.
