30

RT.X2, RT.X2 LE, and RT.X2 SD cards

General

Nominal RT.X2 LE/SD dimensions
Typical operating voltages and current
consumption (RT.X2 card)
Voltage
Current
Total power consumption: 18.0 watts
Typical operating voltages and current
consumption (RT.X2 LE/SD cards)
Voltage
Current
Total power consumption: 10.0 watts
Appendix A, Matrox RT.X2 Specifications
PCI interface
Regulatory compliance
Video standards
Nominal RT.X2 dimensions
+3.3 V
1.8 A
+3.3 V
1.9 A
RT.X2: Full-size PCI Express card
RT.X2 LE/SD: 3/4-size PCI Express card
FCC Class B, CE Mark Class B, ACMA Class B,
VCCI Class B, RoHS Directive 2002/95/EC
RT.X2 and RT.X2 LE: NTSC, PAL, NTSC-EIAJ,
1080i, 1080p/PsF, and 720p
RT.X2 SD: NTSC, PAL, and NTSC-EIAJ
31 cm × 10.7 cm (12.2" × 4.2")
Card
Card including bracket
(13.875" × 4.9")
Overall thickness including components
(0.75")
Card 20.3 cm × 10.7 cm (8.0" × 4.2")
Card including bracket
(8.5" × 4.9")
Overall thickness including components
(0.75")
+5 V +12 V
1.4 A 0.4 A
+12 V
0.3A
35.2 cm × 12.4 cm
1.9 cm
21.6 cm × 12.4 cm
1.9 cm
