32

Video output signals

Composite Video
Y/C Video
Luminance signal (Y)
Chrominance signal
(C)
Component Video
Luminance signal (Y)
Chrominance signal
(B-Y, R-Y)
DVI Video

Audio specifications

Analog audio input/output
Sampling method

Environmental specifications

• Minimum/maximum card ambient operating temperatures: 0 to 55º C
• Minimum/maximum storage temperature: –40 to 75º C
• Maximum altitude for operation: 3,000 meters
• Maximum altitude for transport: 12,000 meters
• Operating humidity: 20 to 80% relative humidity (non-condensing)
• Storage humidity: 5 to 95% relative humidity (non-condensing)
¡ Important To avoid damage to your Matrox RT.X2 components and/or
computer system, make sure that you don't operate your RT.X2 card at or
near the maximum operating temperature for a prolonged period of time.
Appendix A, Matrox RT.X2 Specifications
Signal Type Qty
OR
Voltage
1 1.0 V
1
1.0 V
PAL: 0.300 V
NTSC: 0.286 V
NTSC-EIAJ: 0.286 V
1
1.0 V
PAL: 0.700 V
p-p
NTSC: 0.700 V
p-p
NTSC-EIAJ: 0.757 V
bar
HD: 0.700 V
p-p
(not supported on RT.X2 SD)
1 Compliant with DVI specification,
single-link (not supported on
RT.X2 LE or RT.X2 SD)
Dependent on system's sound card
16-bit, 48 kHz
Impedance
p-p
p-p
burst
p-p
burst
p-p
burst
p-p
p-p
at 100% color bar
at 75% color bar
at 75% color
p-p
at 100% color bar
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
75 Ω
100 Ω
