Ctrl+Alt+Delete
Click this button to send the "Control Alt Delete" key-sequence command to the remote
system. (Also, see section 5.4.1 for configuring new key-sequence buttons).
Drive Redirection button
Click this button to open the Drive Redirection options at the top of the Remote Console
window (see the screenshot below). For more details, see section 11.2.
Auto Adjust button
If the quality of the Remote Console video is bad, or if the Remote Console window is
distorted in some way, click this button and wait a few seconds while the CAT5
8-PORT/16-PORT IP-KVM tries to detect the video mode of the VGA connection of the
Host system to the CAT5 8-PORT/16-PORT IP-KVM. Once detection is complete, the
CAT5 8-PORT/16-PORT IP-KVM will adjust itself for the best possible video quality.
Sync mouse
Clicking this button activates the mouse synchronization process. Choose this option to
synchronize the Host-side mouse cursor with the Remote-side mouse cursor. (Double
Mouse Mode only)
.
Single/Double mouse mode
Clicking this button switches between Single Mouse Mode (where only the Host-side
mouse pointer is visible) and the Double Mouse Mode (where the Host-side and
Remote-side mouse pointers are both visible and need to be synchronized). On SUN
operating systems, Double Mouse Mode only functions if you use SUN JVM 1.5 or higher.
We recommend using only Single Mouse Mode on Mac OS X systems. For more
information on Single and Double Mouse mode and troubleshooting mouse
synchronization, please refer to Section 9.3.4.
