  • Page 1: Users Manual

    2-Port Pocket USB KVM switch Users Manual (DS-11402-1)

  • Page 2: Table Of Contents

    Index 1. INTRODUCTION……………………………………………………………………………………………2 1.1 F …………………….…..………………………………….………………………… ………2 EATURES 1.2 P …….…………………………………...…..………………………………………3 HYSICAL IAGRAM 1.3 P …………………………………...……………..………………………………...3 ACKAGE ONTENTS 2. SPECIFICATIONS………………………………………………………………………………………….4 2.1 G ……………………………………………………………...…………………………………4 ENERAL 3. INSTALLING THE CABLE KVM SWITCH………………………………………………………………5 3.1 S ………………………………………….…………………………………….5 YSTEM EQUIREMENTS 3.2 H ………...………………………...……………..……………………………5 ARDWARE NSTALLATION 3.3 H ……………………….……………...……………………..………………………….6 WAPPABLE...

  • Page 3: Introduction

    1. Introduction Thank you for your purchase of the 2-port USB/VGA Cable KVM Switch with Audio! You now have a high quality, durable system that enables you to control two computers and/or servers from one console (USB Mouse, Keyboard, and Monitor). In addition, proprietary new technology allows you to independently control and switch audio between two computers.

  • Page 4: Physical Diagram

    1.2 Physical Diagram PC connection 2 LED Indicators (Green) PC connection 1 LED Indicators (Green) PC 1 LED Indicators (Red) PC 2 LED Indicators (Red) USB Mouse USB Keyboard VGA Output PC Selection Push Button PC Selection Push Button Speaker Jack MIC Jack ...

  • Page 5: Specifications

    2. Specifications 2.1 General Specification Number Of Computers Controlled Selection Method USB Keyboard Hot Key and Push button USB Versions supported 1.1/2.0 Red for PC Selection LEDs Green for PC ON-Line Selection 2 x Type A USB Connectors Connectors Video 2 x HDB-15 male Speaker 2 x Stereo speaker plugs...

  • Page 6: Installing The Cable Kvm Switch

    3. Installing the Cable KVM Switch 3.1 System Requirements (1) A PC with USB port and 1 VGA port. (2) Windows 98 or later, Mac OS 8/9/OS X, Linux Kernel 2.3 or later. (3) USB Keyboard and mouse. (4) Monitor with VGA port. 3.2 Hardware Installation...

  • Page 7: Hot Swappable

    Plug the USB keyboard, USB mouse, and monitor into the corresponding connectors of your 2-port USB/VGA Cable KVM Switch. Plug the speakers into the corresponding jacks of your 2-port USB/VGA Cable KVM Switch. Connect the KVM cables into the corresponding ports on the computers. 3.3 Hot Swappable The 2-port USB/VGA Cable KVM Switch supports hot-swap technology.
  • Page 8 C. Please insert the “Windows 98” CD into your CD-ROM drive. Click “CD-Rom drive” and press “Next” to continue. (Ref. Fig. C) Fig. C D. Press “Next” to start the installation process. (Ref. Fig. D) Fig. D D1. Sometimes Windows cannot locate the necessary driver automatically.
  • Page 9 * The driver might be located in a different directory from the figure above. D2. Press “OK” to continue (Ref. Fig. D2) Fig. D2 E. Press “Finish” and Windows has finished installing the USB Human Interface Device driver for PS/2 keyboard & mouse. (Ref.

  • Page 10: Operation

    4. Operation The 2-port USB/VGA Cable KVM Switch can switch the keyboard, video, mouse by pushing button and Hot Key. The switching of Audio inputs (speaker & microphone) is independent and be controlled by Hot Key only. The Audio inputs is not be switched with PC selection.

  • Page 11: Hot Key Operation

    4.2. Hot Key Operation When using the Hot Key sequences, the keys must be pressed within 6 seconds, otherwise the Hot Key action will terminate. The Hot Key Operation is only supported under Microsoft Windows series system. 4.2.1. PC Selection [ScrollLock] + [ScrollLock] →...

  • Page 12: Fcc Statement

    Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages.
