General Specifications (continued)
Other AMX Equipment
AMX Products Compatible with
All DXLink Transmitters
AMX Products Compatible with
DXLink RX
Included Accessories
Compatible / Optional Equipment
Compatibility Note: DXLink Transmitters and Receivers are compatible with other DXLink products (see the
Compatible AMX Products listed in the table above). The Wallplate TX and the Decor Wallplate TX require an
approved DXLink power injector (see table above) when connecting directly to an HDMI RX (Transmitters
require firmware v1.2.40 or later; Receivers require firmware v1.0.80 or later). AMX does not support the use
of power supplies other than the one provided or power injectors other than those listed as they may
potentially damage DXLink equipment.
NetLinx and Control Specifications
ICS LAN / Ethernet Port
(Modules Only)
Serial (Modules Only)
IR Control (Modules Only)
USB (HID)
Advanced Configuration Interface
ID Pushbutton
AMX reserves the right to modify its products and their specifications without notice.
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
• DXLink HDMI RX
• Enova DGX Digital Media Switchers
• Enova DVX-3155HD
• Enova DVX-2155HD
• DXLink HDMI TX
• DXLink Multi-Format TX
• DXLink Wallplate TX
• DXLink Decor Wallplate TX
• Enova DGX Digital Media Switchers
• Enova DVX-3155HD
• Enova DVX-3150HD
• Enova DVX-2155HD
• Enova DVX-2150HD
Desktop power supply (ENERGY STAR
Important: Only the provided desktop power supply should be used, and it
must not be altered in any way.
• CC-NIRC NetLinx Emitter Cable (FG10-000-11)
• IR03 External IR Receiver Module (FG-IR03)
• PDXL-2 (FG1090-170)
• PS-POE-AT-TC (FG423-84)
• TCP/IP port (ICS LAN 10/100)
• RJ-45
• Bidirectional RS-232
• Standard NetLinx baud rate 1200 to 115K
• Parity support: Odd/Even/None
• 3.5 mm pluggable Phoenix terminal block
• Port for use with IR03 Receiver (optional accessory FG-IR03)
• Port for use with CC-NIRC Emitter (optional accessory FG10-000-11)
• Multi-Format TX or HDMI TX: USB type B connector
• Wallplate TX and Decor Wallplate TX: USB mini-B connector
• Receiver Module USB type A connector
USB mini-B connector (Program port)
• Toggle between DHCP and static IP addressing
• Places system in NetLinx Device ID assignment mode
• Reset the factory default settings
• Restore the factory firmware image
Product Overview and Specifications
®
qualified): 1 per module
