Figure 20
DAU's Connectors
AUDIO OUT
N.C. = Not Connected
AUDIO OUT RJ45 Connector
TOP COVER
Signal
OUT1+
OUT1-
OUT2+
OUT2-
OUT3+
OUT3-
OUT4+
OUT4-
OUT5+
OUT5-
OUT6+
OUT6-
OUT7+
OUT7-
OUT8+
OUT8-
DAX200/DAX400 – Installation Guide
AUDIO OUT
1-4
5-8
PCB
8
7
6
5
4
3
2
1
1 2 3 4 5 6 7 8
Pin
2
1
6
3
4
5
8
7
2
1
6
3
4
5
8
7
Issue: 02 complete, approved
CAN BUS
AUDIO MON
Signal
OUT'n'+
Balanced audio output +VE connection
0 dBu @ 600 Ω impedance
OUT'n' −
As above but –VE connection.
CAT5 Cable (EIA 568-B)
Page 18 of 28
Description
orange
orange/white
green
green/white
blue
blue/white
brown
brown/white
orange
orange/white
green
green/white
blue
blue/white
brown
brown/white
