Specifications

Video Input Connector
Stereo Audio Input
Output Connectors
Video Input Signals
Compatible Signal Formats
Audio Input Signals
Power Supply
Power Requirements
Product Weight
Shipping Weight
Dimensions (with front plate)
Regulatory Approvals
Parts Included
TPT101-1 or TPT101-2: Twisted Pair Transmitter for High-Resolution Video and Stereo Audio
IN9206: 15VDC; 1A Power Supply
TPT101 / TPR101 Operation Manual
Input Connector
Video Output Connector
Audio Outputs
Power Supply
Product Weight
Shipping Weight
Dimensions
Regulatory Approvals
Parts Included
TPR101-1: Twisted Pair Receiver for High-Resolution Video
IN9230: IEC Power Cable
IN9339: Adjustment Tool with Technician's Blade
TPT101 / TPR101 Operation Manual
© 2003 - EXTRON, Inc.
TPT101 Twisted Pair Transmitter
Analog Video, 1.5 Vp-p max. Sync Signals: TTL
Composite, S-Video, Component
Local Power Mode: IN9206 15VDC, 1A External Adapter
Remote Power Mode: Power Provided by TPR101
4.5"H x 2.75"W x 1.7"D / 11.4cm x 7.0cm x 4.3cm
UL 1950, CAN / CSA-22.2 No. 950, 3
CE: EN55022 (1987), EN50081-1 (1991),
EN50082-1 (1992 and 1994), EN60950-92
TPR101 Twisted Pair Receiver
Output Signal Has Same Video Format as Input
(2) 5-pin captive screw terminals for
Stereo or Mono Balanced Audio
90 - 260VAC; 0.25A; 47 - 63Hz
1.64"H x 8.42"W x 6"D / 4.2cm x 21.45cm x 15.2cm
UL 1950, CAN / CSA-22.2 No. 950, 3
CE: EN55022 (1987), EN50081-1 (1991),
EN50082-1 (1992 and 1994), EN60950-92
TPT101 / TPR101 Operation Manual - Preliminary 8/18/2003
(1) 15-pin HD female
(1) 3.5mm Stereo mini female
(2) RJ45 female
RGBHV, RGBS, RGsB,
Line Level Stereo Audio
Accepts 15 - 40 VDC
Requires 500mA @ 15VDC
.22 lb. / 0.1 Kg
2.3 lbs. / 1.1 Kg
(2) RJ45 female
(1) 15-pin HD female
1.9 lbs. / 0.9 Kg
3.2 lbs. / 1.5 Kg
