EXPANDING A ZONE WITH AN EXTERNAL AMPLIFIER
To provide more power in a zone, use an external
amplifier. A preamplifier output connection for each
zone of the IntelliControl
FM
ANT
AM
ANT
CASCADE AUDIO
OUT
L R
ICS allows you to connect
®
MASTER BEDROOM
SI-245
Variable AUDIO
Line Level
VIDEO
OUT
CASCADE AUDIO
OUT
® ICS SYSTEM CONFIGURATIONS
external amplifiers for zones requiring additional
power. Below is an example of how to connect an
amplifier to the GXR2 Modular Multizone Receiver.
ZONE 1
Two-Conductor
Speaker Cable
COMMUNICATION
& CONTROL SWITCH
CAT-5 Cable
