Operation, cont'd
and output 7 have no connections in this organization, so they have been
crossed out on the worksheet.
Camera
main
podium
1
1
Main
hall
monitor
Preset #
Fill in the preset number, use colors or dashes, etc. to make connecting lines.
Indicate if the configuration is for Video, Audio, or both.
Figure 3-15 — Worksheet example 1: System equipment
Inputs include video cameras, audio tape and CD players, laser disc players,
VCRs, and a VTG 200 video test generator. Output devices include monitors,
front and rear projectors, a stereo, and a VCR. This example, labeled preset 3, is
used as the daily configuration. Choose your own method of notation.
The Extron VTG 200 video test generator connected to input 12 enables a video
test pattern to be sent to one, several, or all output devices for problem isolation
or adjustment purposes. An audio test tape or CD could be used in a similar
manner to check out the audio components.

Worksheet example 2: Daily configuration

Figure 3-16 continues from worksheet example 1 by showing the video and
audio ties that make up the configuration of preset 3, a solid ink line shows video
ties, and a dashed pencil line shows the audio ties. In this example, the image of
the presenter, from the main podium camera (input 1) is displayed on the main
podium monitor (output 6) and taped on the VCR (output 5) for a tape archive.
The audio from the presenter's microphone (input 4) is also routed to the podium
monitor (output 6) and the VCR (output 5). Videotaped material from two VCRs
(inputs 6 and 7) is displayed on two rear projection displays (outputs 3 and 4).
Classical music from the CD player (input 5) is played on the lunch room stereo
(output 8). Meanwhile security cameras (inputs 2 and 3) are routed to two local
monitors (outputs 1 and 2).
3-14 Matrix 50 Series Switchers • Operation
Lobby
Security
Podium Audio
camera security
mic CD
camera
#2
2 3 4 5
2 3 4 5
Class Class Archive
Lobby
room #1 room #2 VCR
monitor
rear proj rear proj
Output destinations
3 Title: Daily configuration Video:
Input sources
Class Class Class Class
room #1 room #2 room #1 room #2
VCR VCR LD LD
6 7 8 9
6 7 8
Main Lunch
podium room
monitor stereo
Audio:
VTG
200
10 11 12
