Specifications, Part #s, Accessories, Dimensions

Specifications

General
Power ............................................. 12VDC from an MLC 206's power supply
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount ................................... Yes, with optional faceplate, and
Enclosure type .............................. Metal
Enclosure dimensions
Faceplate ................... 2.8" H x 3.5" W x 0.1" D
Boards ........................ 2.7" H x 2.6" W x 0.9" D
Product weight ............................. 0.2 lbs (0.1 kg)
Shipping weight ........................... 1 lbs (0.5 kg)
Vibration ....................................... ISTA/NSTA 1A in carton
Listings .......................................... UL, CUL as components of the MLC 206
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
IRCM-DV+ • Specifications, Part #s, Dimensions
A-2
or a System 5xi
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
furniture/wall mountable with optional
faceplates or AAP wall plates
(7.1 cm H x 8.9 cm W x 0.3 cm D)
(4 space high AAP plate)
(6.9 cm H x 6.6 cm W x 2.3 cm D)
(Depth excludes buttons. Allow at least
2.1" (5.3 cm) depth in the wall/furniture.)
(International Safe Transit Association)
as components of the MLC 206
(7.32-112601-D1)

Included Parts

These items are included in each order for a control module:
Included parts
IRCM-DV+ (gray, black, white)
3.5 mm, 5-pole captive screw connectors
IR Emitter
(for IRCM modules)
IRCM-DV+ User's Manual

Accessories

Accessories
AAP 102 (gray, black, white)
AAP 104 (gray, black, white)

Cables

Plenum Comm-link cable
50 feet/15.2 meters long
100 feet/30.5 meters long
200 feet/61.0 meters long
300 feet/91.4 meters long
400 feet/121.9 meters long
Conductor gauges in Extron Comm-Link cables
red and black single strands
white and violet shielded single strands (for signals)
drain wire
IRCM-DV+ • Specifications, Part #s, Dimensions
Part number
70-220-01, -02, -03
10-319-10
19-823-01
68-609-01
Part number
60-300-01, -02, -03
(2 gang)
60-301-01, -02, -03
(4 gang)
Part number
26-461-01
26-461-02
26-461-03
26-461-05
26-461-04
18 AWG
(for power/ground)
22 AWG
24 AWG
A-3
