Connecting A Vcr, Game Console, Camcorder Or Cable/Satellite Set-Top Box - Skyvue SKY5230 Owner's Manual

Connecting to External Equipment
■ When using Component cable (COMPONENT):
• Blu-ray disc player
• HD cable/satellite set-top box
• To enjoy 1080p display capability, connect your external equipment using an HDMI-certifi ed cable or a component cable and
set the equipment to 1080p output.

Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box

■ When using Composite cable (VIDEO 1 or 2):
• Game console
• Camcorder
VIDEO (Yellow)
AUDIO-L (White)
AUDIO-R (Red)
2012 SKYVUE
LC-80LE633U_70_60_52LE640U_C6400U_E.indb 14
• DVD player
P (Red)
R
• VCR
• Cable/Satellite set-top box
Audio cable
AUDIO-R (Red)
AUDIO-L (White)
Y (Green)
P (Blue)
B
Component video cable
AV cable
COMPONENT OUT
14
