Part Names

TV (Front)
TV (Rear/Side)
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH
Volume
buttons
(VOL k / l )
2012 SKYVUE
LC-80LE633U_70_60_52LE640U_C6400U_E_01.indd 10
Remote control sensor
/ )
Antenna/
USB 2
Cable in
terminal
DIGITAL AUDIO
OUTPUT terminal
ETHERNET
terminal
AUDIO IN terminal
(shared for PC IN
and HDMI 1)
OPC sensor *
Center Icon illumination
RS-232C terminal
PC IN terminal
VIDEO 2
terminals
VIDEO 1
terminals
COMPONENT
terminals
AUDIO OUT terminal
USB 1 terminal
HDMI 1 terminal
ARC: Audio Return Channel
HDMI 2 terminal
HDMI 3 terminal
HDMI 4 terminal
