Page 1: Electric Start
7800 Starting Watts / 6500 Rated Watts Electric start PORTABLE GENERATOR MODEL NUMBER 41351 10006 Santa Fe Springs Road SAVE THESE INSTRUCTIONS Santa Fe Springs CA 90670 Important Safety Instructions USA / 1-877-338-0999 MADE IN CHINA are included in this manual. REV 41351-20120712 www.championpowerequipment.com... - Page 2 Have questions or need assistance? Do not return this product to the store! WE ARE HERE TO HELP! Visit our website: www.championpowerequipment.com for more info: • Product Info & Updates • Tech Bulletins • Frequently Asked Questions • Product Registration –...
-
Page 3: Table Of Contents
41351 7800 Starting Watts / 6500 Rated Watts Electric Start PORTABLE GENERATOR TABLE Of CONTENTS Spark Arrester . . . . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
Introduction Accessories Congratulations on your purchase of a Champion Champion Power Equipment manufactures and sells Power Equipment generator . CPE designs and builds accessories designed to help you get the most from generators to strict specifications . With proper use and your purchase . -
Page 5: Manual Conventions
. Please call our help line at 1-877-338-0999 situation which, if not avoided, could result in death or serious injury . CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury . REV 41351-20120712... -
Page 6: Safety Rules
Inform your electricity provider immediately if you or anyone in your household depends on electrical equipment to live . Inform your electrical provider immediately if a loss of power would cause you or anyone in your household to experience a medical emergency . REV 41351-20120712... - Page 7 – Electrical output is lost – Equipment sparks, smokes or emits flames A spark arrestor may be required . The operator – Equipment vibrates excessively should contact local fire agencies for laws or regulations relating to fire prevention requirements . REV 41351-20120712...
-
Page 8: Controls And Features
Battery – Used to start the engine . Air Cleaner – Protects the engine by filtering dust and debris from the intake air . Power Panel – See “Power Panel” . Recoil Starter – Used to start the engine . REV 41351-20120712... -
Page 9: Power Panel
. This receptacle powers 240 Volt AC, 60 Hz, single phase loads . If an L14- 30P plug is wired for only one 120 Volt leg (3-wire connection) then this receptacle powers 120 Volt AC, 60 Hz, single phase loads . REV 41351-20120712... -
Page 10: Parts Included
41351 ENGLISH CONTROLS ANd fEATURES Parts Included Your 41351 Gasoline Powered Generator ships with the following parts: Wheel Kit – 10” Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . -
Page 11: Assembly
2 . Slide the wheel bolt (M10x120) through the washer, sleeve and wheel . 3 . Slide the bolt through the mount point on the frame . 4 . Fasten securely with the M10 nut . 5 . Repeat steps 2-4 to attach the second wheel . REV 41351-20120712... -
Page 12: Add Engine Oil
Check oil often during the break-in period . Refer to the Maintenance section for recommended service intervals . NOTE The generator rotor has a sealed, pre-lubricated ball bearing that requires no additional lubrication for the life of the bearing . REV 41351-20120712... -
Page 13: Grounding
. It is advisable to always shut off the fuel supply, run the engine to fuel starvation and drain the tank when the equipment is not in use for more than 30 days . REV 41351-20120712... -
Page 14: Operation
. 1. Install UL1449, CSA-listed, plug-in surge suppressors on the outlets feeding your sensitive equipment. Surge suppressors come in single- or multi-outlet styles . They’re designed to protect against virtually all short-duration voltage fluctuations . REV 41351-20120712... -
Page 15: Connecting Electrical Loads
If the generator will be connected to a building electrical system, consult your local utility company or a qualified electrician . Connections must isolate generator power from utility power and must comply with all applicable laws and codes . REV 41351-20120712... -
Page 16: Do Not Overload Generator
5 . Plug in and turn on the next item . 6 . Allow the engine to stabilize . 7 . Repeat steps 5-6 for each additional item . NOTE Never exceed the specified capacity when adding loads to the generator . REV 41351-20120712... -
Page 17: Maintenance And Storage
. 5 . Squeeze in a clean, absorbent cloth to remove all excess oil . 6 . Place the fi lter in the assembly . 7 . Reattach the air fi lter cover and snap in place . REV 41351-20120712... -
Page 18: Spark Arrester
Contact our help line at 1-877-338-0999 to locate the 3 . Remove the spark arrester screen . nearest Champion Power Equipment certified service 4 . Carefully remove the carbon deposits from the spark dealer for your generator or engine maintenance needs . -
Page 19: Storage
2 amps . Follow the instructions included with the battery charger . The battery should be fully charged at least once per month . NOTE A Float Charger will maintain the battery condition over long storage periods . REV 41351-20120712... -
Page 20: Specifications
10% by volume . Use 10W-30 4-Cycle automotive oil . Oil capacity is 1 . 1 6 qt (1 . 1 L) . Please reference the following chart for recommended oil types for use in the generator . REV 41351-20120712... -
Page 21: Wiring Diagram
41351 ENGLISH SPECIfICATIONS Wiring diagram REV 41351-20120712... -
Page 22: Parts Diagram
41351 ENGLISH SPECIfICATIONS Parts diagram REV 41351-20120712... -
Page 23: Parts List
Screw M5×38 ST02FD-1152010-5 Grounding line ST05FD-05215006 Build up GB5789 M6×12 Flange Bolt M6×12 ST05FD-05205011-CSA Control Box ST182FD-1742003-UC Straight Bottom rubber GB896 8 Uncork baffle Φ8 27 .001 GB896 6 Uncork baffle Φ6 ST05FD-03161202 Handle underlay 509 .200701 .07 Handle REV 41351-20120712... -
Page 24: Engine Parts Diagram
41351 ENGLISH SPECIfICATIONS Engine Parts diagram REV 41351-20120712... -
Page 25: Engine Parts List
Bolt,Cylinder Head GB29 .2-88-FB5-20 Flange boltM5×20 ST188F-1040010-Φ Push rod GB93-87-LW-5 Lock Washer Φ5 ST188F-1040012 Valve Lifter ST188F-1123000 CoilΦCharging 139FMD-1003101 Drain plug bolt ST188F-1030002 Plate,Wire 139FMD-1003102 Drain plug washer ST188FD-1031011-G Crankcase Cover ST188F-1030013 Dowel pin ST188F-1030008-G Cylinder head casket REV 41351-20120712... -
Page 26: Troubleshooting
Review load and adjust . See “Power Management” Faulty cords or device Check for damaged, bare or frayed wires . Replace defective device for further technical support: Technical Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 tech@championpowerequipment .com REV 41351-20120712... -
Page 27: Warranty
. Warranty Qualifications Other Exclusions Champion Power Equipment (CPE) will register this This warranty excludes: warranty upon receipt of your Warranty Registration Card – Cosmetic defects such as paint, decals, etc . - Page 28 Champion Power Equipment, Inc (CPE), Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with Environment Canada (EC) emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: CPE is pleased to explain the Emission Control Systems Warranty on your 2012 small off-road engine.
- Page 29 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System Warranty Coverage. Emission Control System Warranty (ECS Warranty): 1. APPLICABILITY: The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
- Page 30 Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours. Claims for repair or adjustment found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used.
