Sync - Moog THE SOURCE Owner's Manual

1. Touch Id in the Osc 1 section. Hold down any key. This is an unfiltered sawtooth waveshape. The sawtooth
waveform is rich in harmonics, and has a "bright" sound.
2. Touch Q in the Osc 1 section. This is a triangular waveshape. It has a harmonic structure unlike acoustic
instruments, so it sounds very " electronic."
3. Touch IliBil . The rectangular waveshape has an adjustable duty cycle (comparative time of the positive
portion of the waveshape). The incremental control will change the duty cycle from 5% to 95%. Setting
the duty cycle at 50% produces a square wave, with a characteristic "hollow" sound. Other settings
produce brighter, "reedy" sounds.
SYNC
Osc 2 may be "locked" to the frequency of Osc 1 by activating the Sync function (located between the two
oscillators on the front panel).
When the two oscillators are synchronized, new waveforms are produced when an attempt is made to change the
frequency of Osc 2. Osc 2 may be statically detuned by changing the Interval and/or Octave controls, or dynamically
detuned by moving the pitch wheel (when the Sync function is programmed "on," the pitch wheel is routed to
Osc 2 only).
Touch program 12:
VOLTAGE CONTROLLED FILTER
KB TRACK
28
