SETUP

1. Locating your scale
The rugged design of your Setra Quick Count scale ensures that it
will operate
Nonetheless, you should treat your scale as you would any piece of
precision equipment,
protected, where possible, from extremes of draft and vibration.
2. Leveling your scale
a. Retract the right rear foot completely into the scale.
b. Adjust
centered in the circle.
c. Extend the right rear foot until it contacts the mounting
surface. Make certain that all four feet are contacting the
mounting surface.
d. Make certain the scale is stable by placing both hands on the
scale platform and attempt to rock the scale. If it moves,
adjust the leveling feet until the scale stands firmly on the
mounting surface.
3. Installing the weighing pan
Using the Allen wrench provided, secure the pan support to the four
posts over the sensor. Next, place the weighing pan over the pan
support.
4. Connecting your scale to an AC outlet
To connect your scale to an AC outlet, insert the appropriate end
of the AC adaptor into an electrical outlet. Now connect the other
end into the back of the scale (see FIGURE 1). Once you have
plugged your scale into a live outlet, it is automatically on,
unless the scale is equipped with a battery, in which case the on-
off switch on the rear panel should be put in the 'on' position to
Setra Quick Count™ Operator's Manual
well in typical
locating
the two front feet

Installing Your Scale

factory or office
it on a clean,
until the leveling
An Allen wrench and four socket head cap
screws are provided to assist in the
installation of the load frame support for
sclaes using a rectangular weighing
platform.

Section One

environments.
dry surface;
bubble is
3
