INSTRUCTION MANUAL

Color Camera

MODEL
ISD-A15
ISD-A15TDN
OUTDOOR USE WARNING
WARNING – TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
The apparatus shall not be exposed to
dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the
apparatus.
Ikegami Tsushinki Co., Ltd.

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISD-A15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ikegami ISD-A15

  • Page 1: Instruction Manual

    ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Ikegami Tsushinki Co., Ltd.
  • Page 2: Table Of Contents

    Thank you for choosing this Ikegami Hyper Wide Dynamic DPS Camera. Please read this Instruction Manual carefully to keep your Ikegami camera at peak performance for longer service period. This unit is a cube-type 1 CMOS color camera and making use of a 1/3” type digital pixel sensor system (DPS).
  • Page 3 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
  • Page 5 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 6: Handling Precautions

    1. Handling Precautions splashed or highly humid environment. -10°C or rises above +50°C. The images and component parts may be adversely affected or the camera may not function correctly. for setup or installation because there are precision electrical and electronic components inside and accident may result. transporting it.
  • Page 7: Features

    3. Features (1) Hyper Wide Light Dynamic Range (Hyper WDR) The WDR function provides for very effective compensation of high light and dark areas in screen. This situation may occur generally outside or viewing from indoor to outdoor scenes. Even in large light fluctuations, bright-and-dark subjects can be captured and viewed clearly with a natural appearance.
  • Page 8: Name Of Each Section And Its Function

    4. Name of each section and its function VIDEO OUT SET UP POWER LENS AC24V 50/60Hz 160mA DC12V 170mA MAX40mA...
  • Page 9 Lens mount (CS mount) This is used to mount the lens on the camera. Many types of CS mount lens can be attached. Back focus lock screw After completing the flange back adjustment of the camera, use the supplied Allen wrench to tighten the screw until it is fully fixed. Holder mounting screw holes These holes are used to install and fix the camera on the camera mounting or bracket.
  • Page 10: Operating Procedure

    Video output terminal (VIDEO OUT) To be used to give out the video signal. Connect this to the video input terminal of a monitor, switcher etc. (To be terminated with 75-ohm impedance.) Power indicator (POWER) The LED indicator stays on in green while the camera power is on. DC12V/AC24V power input terminal Keep the input power at DC10.5-15.0 V or AC24V±10%.
  • Page 11 5-3-1. SETUP MENU 1/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) SCENE Possible to easily set the image quality to fit the photography environment without making fine settings of the picture quality. NORMAL: This is a standard image quality setting that can be used for almost all photographic subjects.
  • Page 12 COLOR: The color mode can be selected. B/W: The Monochrome (B/W) mode can be selected. (4) SENS UP Selection of electronic sensitivity increase mode. Possible to choose electronic sensitivity increase rate. OFF: Electronic sensitivity increase mode is OFF. ON: Possible to set the maximum magnification during operation of electronic sensitivity increase.
  • Page 13 Once the 1SPOT ZONE screen appears, select RET and press the E button. The previous menu shows up. preset. Take the same procedure as for the 1SPOT mode. W.DINAMIC: The hyper wide dynamic level can be varied. Adjust the marker while watching an actual scene to have an optimum result.
  • Page 14 AWC: This is the so-called one-push automatic white balance control. Shoot a target white subject and press the E button, and the white balance will be adjusted. MANUAL: Adjust manually Select MANUAL, press the E button and the screen at left appears on screen.
  • Page 15 5-3-2. SETUP MENU 2/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CHROMA Possible to adjust chroma level. Adjust while viewing the screen. (3) DETAIL Possible to adjust details. Adjust while viewing the screen. (4) PEDESTAL Possible to choose pedestal level.
  • Page 16 5-3-3. SETUP MENU 3/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CAMERA ID Up to 24 characters can be displayed on screen. OFF: No screen display. ON: Screen display.
  • Page 17 VERT: Flips the image up or down. BOTH: Flips the image up and down or right and left. (4) PRIVACY MASK Possible to set up to 8 privacy masks. Move to the Privacy Mask item and press the E button to display screen to the right.
  • Page 18 screen to a translucent blue screen. When multiple mask displays are ON, each time the E button is pressed for a mask whose display is ON, the selection condition changes in the following order (masks whose display is OFF are skipped).
  • Page 19 5-3-4. SETUP MENU 4/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) MONITOR The optimum picture quality can be selected according to the monitor used. CRT: To be used when the camera is connected with a CRT (cathode ray tube) monitor.
  • Page 20 OK: Selection screen will appear, as shown right. NTSC or PAL can be selected. * Ever time changing the standard, all the parameters of video related items goes back to the factor y setting position *Note Select the video signal method according to your TV system.
  • Page 21: Focus Ez Function

    6. FOCUS EZ function 6-1. Screen Displays FOCUS EZ is a function to support focus adjustment. A focus indicator displayed on the screen can be used to confirm the focus conditions. In case of auto-iris, it is possible to open the lens aperture forcibly for a set time period to carry out focus adjustment without worrying about field of depth even in a bright environment during the day.
  • Page 22: Warranty And After-Sale Service

    A warranty accompanies this product. Read and fill out the warranty card that you have received at your dealer. Keep this card in a safe place. Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics (Europe) GmbH or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period accord- ing to the warranty coverage.
  • Page 23 DC-driven) (5) Video output: VBS 1.0Vp-p/75 ohms (6) Day/Night switching: ISD-A15: Digital Day/Night ISD-A15TDN: True Day/Night (7) Resolution: Horizontal; 520 TV lines (high-resolution mode 690TVL-Effective)
  • Page 24 (22) Auto iris function: Compatible with DC iris (switchable, with DC iris level adjuster) (23) Lens flange back adjustment: Built-in (24) Power Requirement: AC 24 V±10% (50/60Hz) DC 12 V (+10.5V ~ + 15V) (25) Power Consumption 2.2W (26) Outer dimensions: 52(W)×52(H)×55(D) mm (no protrusion included) (27) Weight:...
  • Page 25 Esta unidad es una cámara en color de CMOS de tipo cubo y que utiliza un sistema de sensor de píxeles digital de tipo de 1/3”. Este producto de Ikegami se fabrica con componentes que respetan el medio ambiente, basándose en nuestra política corporativa y de responsabilidad social que contribuye a la solución medioambiental global para la conservación de la energía...
  • Page 26 El signo de exclamación dentro de un triángulo equilátero tiene la finalidad de avisar al usuario de la presencia de instrucciones de funcionamiento y mantenimiento (reparaciones) importantes en los manuales que acompañan al aparato. NOTA: Este equipo ha sido probado y ha demostrado cumplir con los límites establecidos para los dispositivos digitales de la clase A, en conformidad con el apartado 15 de los Reglamentos de la FCC.
  • Page 27 INSTRUCCIONES IMPORTANTES DE SEGURIDAD 1) Lea estas instrucciones. 2) Conserve estas instrucciones. 3) Preste atención a todas las advertencias. 4) Siga todas las instrucciones. 5) No utilice este aparato cerca de agua. 6) Limpie solamente con un paño seco. 7) No bloquee ninguna de las aberturas de ventilación. Instale de acuerdo con las instrucciones del fabricante.
  • Page 28 14) Solicite cualquier reparación a personal de ser vicio cualificado. La reparación se requerirá cuando el aparato se haya dañado de alguna forma, por ejemplo, cuando se haya dañado el cable o el enchufe de alimentación, se haya vertido líquido o hayan entrado objetos dentro del aparato, cuando el aparato haya estado expuesto a la lluvia o la humedad, cuando no funcione normalmente, o cuando haya caído.
  • Page 29: Precauciones De Manejo

    1. Precauciones de manejo se salpique agua o exista mucha humedad. o superior a +50°C. Las imágenes y las piezas componentes podrían ser afectadas o la cámara podría funcionar mal. necesario para su preparación o instalación, porque en su interior hay componentes eléctricos y electrónicos de precisión y podría producirse un accidente.
  • Page 30: Características

    3. Características (1) Gama dinámica luminosa hiperamplia (Hiper WDR) La función WDR proporciona una compensación muy efectiva para las áreas muy iluminadas y oscuras de la pantalla. Esta situación puede ocurrir generalmente en exteriores o cuando se observan escenas exteriores desde interiores. Incluso cuando las fluctuaciones de la iluminación son grandes, los motivos brillantes y oscuros pueden captarse y verse claramente con una apariencia natural.
  • Page 31: Nombre De Cada Sección Y Su Función

    4. Nombre de cada sección y su función VIDEO OUT SET UP POWER LENS AC24V 50/60Hz 160mA DC12V 170mA MAX40mA...
  • Page 32 Montura del objetivo (montura CS) Ésta se utiliza para montar el objetivo en la cámara. Se pueden montar muchos tipos de objetivos de montura CS. Tornillo de bloqueo de enfoque posterior Después de completar el ajuste de la distancia entre la superficie de montaje del objetivo y el plano focal de la cámara, utilice la llave Allen suministrada para apretar el tornillo hasta que quede completamente fijado.
  • Page 33: Procedimiento De Operación

    Terminal de salida de vídeo (VIDEO OUT) Se utiliza para dar salida a la señal de vídeo. Conecte este terminal al terminal de entrada de vídeo de un monitor, conmutador, etc. (Será terminado con una impedancia de 75 ohmios.) Indicador de alimentación (POWER) El indicador LED permanece encendido en verde mientras la alimentación de la cámara está...
  • Page 34 5-3-1. SETUP MENU 1/4 * Las configuraciones nuevas se pueden guardar si se seleccionó EXIT para salir del menú. (1) PAGE Se pueden cambiar páginas. (2) SCENE Se puede ajustar fácilmente la calidad de la imagen para adecuarla al entorno de fotografía sin realizar ajustes finos de la calidad de la imagen.
  • Page 35 COLOR: Se puede seleccionar el modo de color. B/W: Se puede seleccionar el modo de blanco y negro (B/W). (4) SENS UP Selección del modo de aumento de sensibilidad electrónico. Se puede elegir el índice de aumento de sensibilidad electrónico. OFF: Modo de aumento de sensibilidad electrónico desactivado.
  • Page 36 Utilizando el botón U, D, L o R, el campo se puede reducir. * Para salir de la pantalla de ajuste del campo, mantenga pulsado el botón E durante más de 2 segundos. Una vez que aparezca la pantalla 1SPOT ZONE, seleccione RET y pulse el botón E.
  • Page 37 ATW Ex: El balance del blanco cambia automáticamente a seguimiento automático a tiempo completo, pero el área de cobertura de la gama de temperaturas del color aumenta más que en el modo ATW. En comparación con el modo ATW, la precisión del seguimiento del blanco no es muy buena en este modo, pero en cier tas condiciones, esto puede ser bueno para compensar las diferencias de color.
  • Page 38 5-3-2. SETUP MENU 2/4 * Las configuraciones nuevas se pueden guardar si se seleccionó EXIT para salir del menú. (1) PAGE Se pueden cambiar páginas. (2) CHROMA Se puede ajustar el nivel de croma. Ajuste observando la pantalla. (3) DETAIL Se pueden ajustar los detalles.
  • Page 39 5-3-3. SETUP MENU 3/4 * Las configuraciones nuevas se pueden guardar si se seleccionó EXIT para salir del menú. (1) PAGE Se pueden cambiar páginas. (2) CAMERA ID En la pantalla se puede visualizar un máximo de 24 caracteres. OFF: No hay visualización en pantalla. ON: Hay visualización en pantalla.
  • Page 40 (3) VIDEO FLIP Establecimiento de volteo de vídeo OFF: No hay volteo de vídeo. HORIZ: Voltea la imagen hacia la derecha o la izquierda. VERT: Voltea la imagen hacia arriba o abajo. BOTH: Voltea la imagen hacia arriba y abajo, o hacia la derecha y la izquierda.
  • Page 41 Cada botón es para: U : Mueve la línea inferior de una máscara hacia arriba (Reducción de altura) D : Mueve la línea inferior de una máscara hacia abajo (Aumento de altura) R : Mueve el lado derecho de una máscara hacia la derecha (Aumento de anchura) L : Mueve el lado derecho de una máscara hacia la izquierda (Reducción de anchura)
  • Page 42 (7) PROGRES.SCAN Activa o desactiva la exploración progresiva. (8) EXIT Se utiliza para guardar la configuración y salir del menú. (9) CANCEL Se utiliza para cambiar las configuraciones por otras que fueron guardadas previamente. (10)RESET Se utiliza para volver a los ajustes de fábrica. S-14...
  • Page 43 5-3-4. SETUP MENU 4/4 * Las configuraciones nuevas se pueden guardar si se seleccionó EXIT para salir del menú. (1) PAGE Se pueden cambiar páginas. (2) MONITOR La calidad de imagen óptima se puede seleccionar según el monitor utilizado CRT: Para ser utilizado cuando la cámara se conecte a un monitor CRT (tubo de rayos catódicos).
  • Page 44 OK: Aparecerá la pantalla de selección, como se muestra a la derecha. Se puede seleccionar NTSC o PAL. * Cada vez que se cambia el sistema, todos los parámetros de los elementos de vídeo relacionados cambian a los ajustes de fábrica. *Nota Seleccione el método de señal de vídeo de acuerdo con su sistema de televisión.
  • Page 45: Función Focus Ez (Enfoque Fácil

    6. Función FOCUS EZ (enfoque fácil) 6-1. Visualizaciones en pantalla FOCUS EZ es una función para apoyar el ajuste del enfoque. El indicador de enfoque visualizado en la pantalla puede utilizarse para confirmar las condiciones de enfoque. En el caso de iris automático, es posible abrir a la fuerza la apertura del objetivo durante un período de tiempo establecido para realizar el ajuste del enfoque sin preocuparse por la profundidad de campo incluso en un entorno brillante durante el día.
  • Page 46: Garantía Y Servicio Postventa

    Consulte a Ikegami Electronics (U.S.A.) Inc., a Ikegami Electronics (Europe) GmbH o a su concesionario para obtener una información completa de la garantía. Su concesionario reparará o reemplazará el producto libre de todo gasto siempre que no haya vencido el periodo de la garantía y se cumplan con todas las condiciones de la misma.
  • Page 47 CC.) (5) Salida de vídeo: VBS 1.0Vp-p/75ohmios (6) Cambio de día/noche: ISD-A15: Día/noche digitales ISD-A15TDN: Día/noche reales (7) Resolución: Horizontal; 520 líneas de TV (modo de alta resolución efectiva de 690 TVL) (8) Relación señal a ruido:...
  • Page 48 (17) Ajuste de máscara privada: Incorporada, hasta 8 áreas (18) Selección de salida de Incorporada, tipo CRT o LCD, monitor óptima: seleccionable (19) Identificación de cámara: 1 línea, hasta 24 caracteres (letras, números y símbolos) (20) Temperatura y humedad -10 a +50°C, 30% a 90% de humedad relativa de funcionamiento: relative (sin condensación) (21) Montura del objetivo: Montura CS (Posibilidad de fijación de...
  • Page 49: External Appearance

    9. External Appearance 2-1/4”-20UNC VIDEO OUT SET UP POWER LENS AC24V 50/60Hz 160mA DC12V 170mA MAX40mA LABEL...
  • Page 50: Setup Flow Chart

    10. Setup Flow Chart...
  • Page 52 37 Brook Avenue, Maywood, N.J. 07607, U.S.A. Phone: (201) 368-9171, FAX (201) 569-1626 www.Ikegami.com Ikegami Electronics (Europe) GmbH Ikegami Strasse 1, D-41460 Neuss, Germany Phone : 02131-123-0, FAX 02131-102820 www.Ikegami.de Ikegami Electronics U.K. Office: Unit E1, Cologne Court, Brooklands Close, Windmill Road, Sunbury-on-Thames, Middlesex, TW16 7EB, U.K.
