HDK-79GX
( FA-55 )
HIGH DEFINITION CAM ERA SYSTEM
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDK-79GX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ikegami HDK-79GX

Summary of Contents for Ikegami HDK-79GX

  • Page 1 HDK-79GX ( FA-55 ) HIGH DEFINITION CAM ERA SYSTEM OPERATION MANUAL...
  • Page 3 OUTLINE HDK-79GX NAME and FUNCTION ( FA-55 ) INSTALLATION and HIGH DEFINITION CAMERA SYSTEM CONNECTION OPERATION MANUAL OPERATION CAMERA SETTINGS and ADJUSTMENT TROUBLE SHOOTING and MAINTENANCE SPECIFICATIONS CHANGING INFORMATION 1301 Edition (U)
  • Page 4 Copyright © 2013 Ikegami Tsushinki Co., Ltd. Copyright © 2013 Ikegami Tsushinki Co., Ltd. We reserve the copyright on the software we create. We reserve the copyright on the software we create. No part of this publication may be modi ed or reproduced in any form, or by any means, without prior written permission from No part of this publication may be modi ed or reproduced in any form, or by any means, without prior written permission from Ikegami Tsushinki Co., Ltd.

  • Page 5: Products Conforming To Rohs Directive

    80% and less than 85% by weight 14. Lead in solders to complete a viable electrical connection between semiconductor die and carrier within integrated circuit Flip Chip packages 15. Decabrominated diphenyl ether (Deca-BDE) in polymeric applications HDK-79GX 1301 VER1 (U)

  • Page 6: Maintenance Of Products Conforming To Rohs Directive

    · If the customer mixed the lead-solder with the main body wiring or the circuit board, it becomes guarantee off the subject. Ikegami doesn't guarantee to do the repair work. Because the solder polluted with lead cannot be removed. 3. Parts Be sure to use parts conforming to RoHS directive.

  • Page 7: Information To The User

    1 E4-E5, EN55103-2 E4-E5 (for EMC), EN60950-1 (for LVD). For European customer. 3. Rated current value of the camera when BSF-55 are used for the system operation is shown below. Rated current value · BSF-55 DC180V : 0.8A HDK-79GX 1301 VER1 (U)

  • Page 8: Safety Precautions

    Indicates that mishandling may cause an electric shock. Indicates that mishandling may cause a re. Indicates that mishandling may cause injury. The following symbol is used to indicate other precautions to prevent damage or hazard from occurring: Indicates prohibited action. HDK-79GX 1301 VER1 (U)
  • Page 9 - In direct sunlight for a long time, or near a heater - High humidity or dusty - Exposed to water or other liquid - Strong vibration or shock - Strong magnetic eld or radio waves - lightning - In rain without the rain cover HDK-79GX 1301 VER1 (U)
  • Page 10 Wrong usage of batteries may cause liquid leak, explosion, and heat, and at worst injury or re. When changing or discarding a battery, please contact Ikegami's sales and service centers. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
  • Page 11 Radius Approx. 60mm Fiber Optic Cable - When connecting a ber optic cable to a ber connector, anchor the ber optic cable with a cable clamp. CAMERA CABLE Clamp CAMERA CABLE Clamp (optional) Optical Fiber Cable HDK-79GX 1301 VER1 (U)
  • Page 12 This product includes parts that wear out and have a limited life even in proper use or storage. Therefore, regular maintenance is recommended to extend the life and safe use of this product for a long time. Please contact Ikegami's sales and service centers for the regular maintenance and repair of our products.

  • Page 13: How To Read The Operation Manual

    HOW TO READ THE OPERATION MANUAL HOW TO READ THE OPERATION MANUAL This page explains general notes on reading the HDK-79GX Operation Manual, and the symbols and notations used in the manual. Notes on the Manual - This manual is written for readers with a basic knowledge of handling broadcast cameras.
  • Page 14 Structure of Operation Manual HDK-79GX High De nition Camera System Operation Manual is intended to both safely and smoothly operate the HDK-79GX. The Operation Manual consists of seven chapters. By reading it in sequence, you can smoothly perform a series of steps, from connection to operation.

  • Page 15: Table Of Contents

    Menu Confi guration and content ..87 5.3 Using the Memory Card ....100 HDK-79GX 1301 VER1 (U)
  • Page 16 6.5 Reset the Breaker ..... .114 Chapter 7 SPECIFICATIONS 7.1 HDK-79GX Specifi cations ....117 7.2 External Dimensions Diagram ... .119 7.3 External Connections .

  • Page 17: Chapter 1 Outline

    OUTLINE OUTLINE...
  • Page 18 HDK-79GX 1301 VER1 (U)

  • Page 19: Features Of This Product

    Super KNEE Includes a super KNEE function which produces the KNEE process with less saturation loss, and without changing the hue of the highlighted parts. Produces a more natural highlight appearance, rather than washing out the color. HDK-79GX 1301 VER1 (U)
  • Page 20 (page 109) for the ENGINEER camera system is used. This enables to initialize the camera status quickly even though the SET FILE and FACTORY SET settings are changed due to causes such as wrong operation of the menu. FILE. HDK-79GX 1301 VER1 (U)

  • Page 21: Operating Systems

    CSU (Camera Select Unit) Used when controlling multiple cameras. With using a MCP, one CSU can control up to 8 cameras, and contains terminals through which video is output on the monitor from the selected camera. HDK-79GX 1301 VER1 (U)
  • Page 22 CSU-1 BS-8 BS-8 PM, WFM, COMM BS-9 BS-9 CSU-2 BS-16 BS-16 BS-17 BS-17 CSU-3 BS-24 BS-24 BS-25 BS-25 CSU-4 BS-32 BS-32 ■ Example of VTR Location Configuration (Minimum Configuration of Camera, VTR, and PM) Camera Head HDK-79GX 1301 VER1 (U)
  • Page 23 BSH-200 BS-2 connector at the same time in this con guration. BS-3 CP cable Coaxial cable OCP-200 75Ω termination ARC1 CP cable ARC2 BS-4 ARC1 Coaxial cable ARC2 CPH-200 ARC3 75Ω termination BS-5 BSH-200 BS-6 HDK-79GX 1301 VER1 (U)
  • Page 24 HDK-79GX 1301 VER1 (U)

  • Page 25: Connection Diagram

    OUTLINE...

  • Page 27: Chapter 2 Name And Function

    NAME and FUNCTION NAME and FUNCTION...
  • Page 28 HDK-79GX 1301 VER1 (U)

  • Page 29: Camera And Viewfi Nder

    ⑦ POWER switch FILTER HEAD switch ⑭ ⑮ CC FILTER switch (ECC) SHUTT/SUP-V switch ⑬ ⑯ ND FILTER switch ⑰ FILTER local indicator GAIN SELECT switch    OUTPUT SELECT switch ⑳ ⑱ AWB/ABB switch ⑲ AWB SELECT switch HDK-79GX 1301 VER1 (U)
  • Page 30 ⑪ INCOM PHONE control knob Controls the volume of the intercom when the INCOM FRONT VR SELECT switch on the rear of the camera is set to "ENG" or "PROD". ⑫ Switch control panel cover Protects the switch control panel. HDK-79GX 1301 VER1 (U)
  • Page 31 ABB : By setting this switch to the ABB position, automatic adjustment of black balance starts. The adjusted value is stored in memory. If the switch is set to ABB continuously even during ABB activation, automatic adjustment of black shading starts. HDK-79GX 1301 VER1 (U)
  • Page 32 M : Gain value set by the menu is obtained. The set value is -6dB, -3dB, +3dB, +6dB +9dB or +12dB. : Gain value set by the menu is obtained. The set value is -3dB, +3dB, +6dB, +9dB +12dB or +18dB. HDK-79GX 1301 VER1 (U)

  • Page 33: Camera Left View

    ② VF connector VF CONNECTOR LOCK button ③ ① Shoulder belt hook ⑩ CAMERA CABLE clamp ④ VF CABLE clamp CAMERA connector ⑨ RET-1 button ⑥ ⑦ Breaker Memory Card Slot ⑪ ⑤ RET-2/MIC button ⑧ MIC CABLE clamp HDK-79GX 1301 VER1 (U)
  • Page 34 When storing or retrieving data, the access indicator on the side of the the slot is lit. Do not remove the card if the access indicator is lit. This could not only destroy the data on the card but also destroy camera data. HDK-79GX 1301 VER1 (U)

  • Page 35: Camera Front View

    2.1 Camera and Viewfi nder Camera Front View Cable clamp ⑨ ② LENS LOCK lever  ① Lens mount ⑦ P.FUNC switch ⑥ VF CHAR button LENS connector ⑧ ⑤ ROTARY PULSE switch ④ SET button MIC button ③ HDK-79GX 1301 VER1 (U)
  • Page 36 Connects a 12-pin lens cable. It is compatible with both BTA lens mounting method. "Lens Connector" (page 123) for the pin functions of the lens ⑨ Cable clamp connector. Secures the microphone cable and lens cable (pigtail cable). HDK-79GX 1301 VER1 (U)

  • Page 37: Camera Rear View

    I/O connector Q-TV/GL, MON OUT connector DC OUT connector HD SDI OUT connector MIC-1 POWER switch REMOTE connector MIC-2 POWER switch DC IN connector MIC-1 connector AUX OUT connector System expansion connector MIC-2 connector MON SDI connector HDK-79GX 1301 VER1 (U)

  • Page 38: Green Tally Indicator

    A multi-connector for input/output signals including GREEN/RED TALLY control output Note: signals, RET-1/RET-2 control input signals, and RS-422 data control signals. RS-422 data trunk line is optional. Reference: Refer to "7. SPECIFICATIONS", "I/O Connector" (page 136) for the pin functions of the I/O connector. HDK-79GX 1301 VER1 (U)

  • Page 39: Dc Out Connector

    ● When set to MON OUT Outputs the monitor signal. Select the MON, SYNC signals from the camera menu screen. ○   Q-TV/GL, MON OUT SELECT switch Selects the type of signal which is output from the Q-TV/GL, MON OUT connector. HDK-79GX 1301 VER1 (U)

  • Page 40: Select Switch

    Selects one system from the return video signals of 4 systems that are connected to the BS as RET-2 video. ○   MON SDI connector Outputs the HD SDI signal for monitoring. MAIN, VF, or RETURN can be selected from the camera menu. HDK-79GX 1301 VER1 (U)

  • Page 41: Viewfi Nder (Vf421Hd)

    ⑪ MIC HOLDER attaching mount Escutcheon Front View label display ⑨ FRONT TALLY Lamp BATT PEAKING CONTRAST BRIGHT ZEBRA TALLY HIGH  PEAKING knob ④ ⑧ TALLY switch CONTRAST knob ⑤ ⑦ ZEBRA switch BRIGHTNESS knob ⑥ HDK-79GX 1301 VER1 (U)
  • Page 42 R TALLY is input to various expansion devices. Since the REAR TALLY lamp serves as the switch, it can be turned ON/OFF by sliding. ⑪ MIC HOLDER attaching mount Attaches an external microphone holder. HDK-79GX 1301 VER1 (U)

  • Page 43: Displays In The Viewfi Nder

    The zebra indicator is turned ON or OFF using the ZEBRA switch on the front of the view nder. Reference: Refer to "5. CAMERA SETTINGS and ADJUSTMENT", "Menu Con guration and content" (page 87) for how to set the zebra signal. HDK-79GX 1301 VER1 (U)

  • Page 44: Side Mask Function

    ⑰ Shutter speed/focus indicator/   Zoom indicator ⑱ Digital Extender ⑯ AWB memory channel ⑩ OPT level ⑫ GAIN UP value ⑮ Operational priority for filter control ⑭ ND, ECC and EFF filter indication ⑨ SKIN DTL ON/OFF HDK-79GX 1301 VER1 (U)
  • Page 45 ⑬ Temperature warning ＴＥＭＰ！！ Auto Setup Display ■ ② Auto setup function ＡＢＢ ⑤ Execution result of auto setup Ｏ Ｋ ＢＬＫＳＥＴ ⑥ Adjustment item of auto setup Return Video Channel Display ■ ⑲ Return video input channel ＲＥＴ−１ HDK-79GX 1301 VER1 (U)
  • Page 46 (Selection between A-ch and B-ch is made by the AWB SELECT switch.) The AWB color temperature is also displayed when the FILTER switch is operated. ⑨ SKIN DTL ON/OFF "SK" is displayed when the SKIN DTL function is ON. HDK-79GX 1301 VER1 (U)

  • Page 47: Installation And Connection

    INSTALLATION INSTALLATION and CONNECTION and CONNECTION...
  • Page 48 HDK-79GX 1301 VER1 (U)

  • Page 49: Preparation

    Connection Example for Each Operating System Not only can the HDK-79GX be used stand-alone for video location operation, but it can also be used in various operating systems in studio and in eld as a system camera in combination with peripheral equipment such as the BS.
  • Page 50 3.1 Preparation HDK-79GX 1301 VER1 (U)
  • Page 51 INSTALLATION and CONNECTION...
  • Page 53 INSTALLATION and CONNECTION...

  • Page 55: Camera And Peripheral Installation And Connection

    Insert the rear wedge of the camera into the Camera right view groove of the tripod mount plate and move it backward slightly. Camera rear wedge Camera front wedge ④ Insert the camera wedges. Mount plate Tripod HDK-79GX 1301 VER1 (U)
  • Page 56 Press the red button on the lock lever to unlock the camera. Be sure to hold the handle while pressing the button to prevent the camera from falling. Lift the camera and remove the wedges from the tripod mount plate. HDK-79GX 1301 VER1 (U)

  • Page 57: Mounting And Removing The Lens

    Be sure to place the camera on a tripod or on a at, level, stable surface when you mount the lens. The lens can be mounted to the HDK-79GX either by BTA mounting method. Before proceeding any further, remove the lens cap by pushing up the lens lock lever.
  • Page 58 Counter-clockwise to the end Support the lens with your hand to prevent it from stop and remove the lens. falling. Remove the pigtail cable from the cable clamps. Put the lens cap on to protect the lens from scratches. HDK-79GX 1301 VER1 (U)

  • Page 59: Mounting And Removing The Viewfi Nder

    Align the pins on the view nder cable with the view nder connector and push until the connector lock button clicks. CAUTION: Be careful not to catch your ngers in the lock lever or guide-rail when attaching the view nder. Take caution to avoid injury. HDK-79GX 1301 VER1 (U)
  • Page 60 Rotate the eyepiece in the direction shown in the fi gure. Rotate the eyepiece until it clicks. You will hear a click sound when the eyepiece is locked to the view nder. mark HDK-79GX 1301 VER1 (U)

  • Page 61: Attaching The Microphone

    Refer to "4. OPERATION", "4.2 Switch Position Check" (page 58) for how to select the power supply. For details on the microphone, refer to the instructions accompanying the microphone to be used. HDK-79GX 1301 VER1 (U)

  • Page 62: Connecting The Headset

    3.2 Camera and Peripheral Installation and Connection Connecting the Headset Two intercom lines (1 and 2) can be connected to the HDK-79GX. Please select the engineer intercom or producer intercom depending on the use. This section explains how to connect the engineer intercom to the camera.

  • Page 63: Power Connection

    Connect the DC OUT connector on the POWER and the DC IN connector on the camera via the DC POWER cable. Turn the POWER switch on the POWER ON. The POWER indicator on the POWER will light. HDK-79GX 1301 VER1 (U)

  • Page 64: Power Supply From Bs

    This completes the procedure for connecting power from the BSF-55 to the camera. There are two methods of supplying power to the camera in this state: - When operating the camera power source from the BS. - When operating the camera power source from OCP (remote control). HDK-79GX 1301 VER1 (U)
  • Page 65 To turn on the BS MAIN POWER switch just after the switch is turned off, wait one or more seconds before you turn on the power. Repeating the on/off operation within one second activates the protector. When the protector is activated, turn on the BS MAIN POWER switch after ve or more seconds later. HDK-79GX 1301 VER1 (U)
  • Page 66 Power is supplied to the camera. CAM PWR switch Note: When the CAM POWER switch on the OCP is turned "ON/OFF", only power supply to the camera is turned "ON/OFF", and the BS power is not turned "ON/OFF". HDK-79GX 1301 VER1 (U)

  • Page 67: Monitor Connection

    3.4 Monitor Connection 3.4 Monitor Connection This section explains how to connect the HDK-79GX to the monitor. Connecting Camera and Monitor There are three connectors on the rear of the camera to output various video signals. The type of video signal output from each connector is different.

  • Page 68: Bs Connection

    3.5 BS Connection 3.5 BS Connection This section explains how to connect the HDK-79GX to the BS. BSF-55 is used here as an example. Two types of ber cables are available in different shapes. - Fiber cable (2-core single mode) : Diameter 9.2mm or 16mm, Maximum length 2000m (when BSF-55 is used)
  • Page 69 Remove the cable from the BSF-55 while pushing the unlocking ring of the CAMERA connector on the rear of BSF-55. If the connector tip is locked, the ber cable will not be removed. If it is locked, push the ber cable toward the CAMERA connector, and then remove as described above. HDK-79GX 1301 VER1 (U)
  • Page 70 HDK-79GX 1301 VER1 (U)

  • Page 71: Chapter 4 Operation

    OPERATION OPERATION...
  • Page 72 HDK-79GX 1301 VER1 (U)

  • Page 73: Operating Procedures

    4.1 Operating Procedures 4.1 Operating Procedures This chapter explains how to operate the HDK-79GX camera. ■  Initial Operation Check ―――――――――――――― When you use the camera for the first time after purchase, ensure that it works properly. Switch Position Check ◆...

  • Page 74: Switch Position Check

    Applicable for a dynamic microphone or a microphone with built-in power supply which requires no power supply. +48V Supplies +48V Phantom power Reference: For details on the microphone, refer to the instructions accompanying the microphone to be used. HDK-79GX 1301 VER1 (U)
  • Page 75 4.2 Switch Position Check ■ Viewfinder - TALLY switch : LOW - ZEBRA switch : ON TALLY switch ZEBRA switch HDK-79GX 1301 VER1 (U)

  • Page 76: Turning On Power

    : Lights when the ber cable is not connected or there is an "open" in the ber cable. SHORT (red) : Lights when a short circuit occurs in the ber cable due to a cause such as water. HDK-79GX 1301 VER1 (U)
  • Page 77 It is possible to use the OCP to control the camera power source. When the CAM POWER switch of OCP has been turned ON/OFF, only the camera power supply is turned ON/OFF. The BS power supply is not turned ON/OFF. HDK-79GX 1301 VER1 (U)

  • Page 78: Viewfi Nder Adjustment

    You can select the display mode for various markers and characters displayed in the view nder. Set the display mode suitable for the conditions in which the camera is used. Reference: The display mode is set by the menu. Refer to "5. CAMERA SETTINGS and ADJUSTMENT", "Menu Con guration and content" (page 87). HDK-79GX 1301 VER1 (U)

  • Page 79: Output Signal Check

    LCD panel Note: When no color bar signal is not displayed on the SDTV signal while you use MCP-200 and press the "Y" button of the MONITOR SELECT buttons, refer to the operation manual for MCP-200. HDK-79GX 1301 VER1 (U)

  • Page 80: Test Pulse (Cal Signal) Check

    RANGE SENS WFM/PM /Mix HEAD CLS OPEN ±1 ±2 CABLE OPEN SHORT ALARM CALL PREVIEW "R", "G", "B", "Y", "SEQ" LCD panel External Chart Check Shoot an external chart and ensure that the image is normal. HDK-79GX 1301 VER1 (U)

  • Page 81: Auto Setup

    Auto setup can be activated from the camera, OCP, and MCP. See the table in the next page for which device can activate which auto setup function. Reference: For how to execute auto setup from the OCP/MCP, refer to the relevant operation manual. HDK-79GX 1301 VER1 (U)
  • Page 82 - EXT (external reference) of REF is the value set by the reference set function. - The item for G channel with a circle only works when it is set with a diascope (lens option). When you use the external chart, set G channel to 100% level by IRIS. HDK-79GX 1301 VER1 (U)

  • Page 83: Full Auto Setup And Level Auto Setup

    - Press the SETUP button in the function switch part. - Press the AUTO SETUP button on the LCD. - Press the Full or Level button on the LCD. - Press the Start button on the LCD. HDK-79GX 1301 VER1 (U)

  • Page 84: Full Quick Auto Setup And Quick Auto Setup

    When the priority is given to the camera, an asterisk (*) is displayed in the view nder. Shoot a subject which contains something white. Make sure that the white subject lls at least 10% of the screen. HDK-79GX 1301 VER1 (U)
  • Page 85 If the control knob is not at the center position, the control range may be biased. Note: To activate the auto white balance from an OCP, press the AWB button in the camera function operation part. To activate it from an MCP, press the AWB button on the LCD. HDK-79GX 1301 VER1 (U)

  • Page 86: Auto Black Balance

    Note: To activate the auto black balance from an OCP, press the ABB button in the camera function operation part. To activate it from an MCP, press the ABB button on the LCD. ＡＢＢ Ｏ Ｋ HDK-79GX 1301 VER1 (U)

  • Page 87: Auto Black Shading

    - To activate the auto black shading from an OCP, press the ABB button in the camera function operation part. - To activate it from an MCP, press the Quick button on the LCD, then press the ABB button. Ａ.ＢＬＫ ＳＨＡＤＥ ＢＬＡＣＫ ＳＨＡＤＥ Ａ.ＢＬＫ ＳＥＴ Ｏ Ｋ HDK-79GX 1301 VER1 (U)

  • Page 88: Preparation For Shooting In Particular Environment

    When shooting where the electromagnetic eld is excessively Rainproof cover strong, such as in airports, military bases or transmitting stations, completely shield the camera by thoroughly covering it with aluminum foil. It is necessary to take the same measure for other devices. HDK-79GX 1301 VER1 (U)

  • Page 89: Camera Settings And Adjustment

    CAMERA SETTINGS CAMERA SETTINGS and ADJUSTMENT and ADJUSTMENT...
  • Page 90 HDK-79GX 1301 VER1 (U)

  • Page 91: Settings Using Switches On The Camera

    Set the INCOM FRONT VR SELECT switch on the rear of the camera to INCOM-1 or INCOM-2. Turn the INCOM PHONE control knob on the right side of the camera to adjust the volume. CAUTION: Be sure to adjust the volume to the appropriate level while listening to sound through the headset. HDK-79GX 1301 VER1 (U)

  • Page 92: Selecting Shutter Speed

    SEMI REMOTE MODE is set to "OFF"). For details on how to operate the various remote controllers, refer to the instruction manuals attached to the remote controllers. Camera right view Camera front view (Switch control panel) CHAR P.FUNC PUSH MENU Rotary pulse switch SHUTT/SUP-V switch HDK-79GX 1301 VER1 (U)
  • Page 93 - Set the SHUTT/SUP-V switch to OFF. The displayed speed is maintained until the switch is set to ON. The shutter speed is validated when the switch is set to ON. ■ To cancel the Shutter Speed Set the SHUTT/SUP-V switch to OFF. HDK-79GX 1301 VER1 (U)

  • Page 94: Enhancing The Vertical Resolution (Super-V Function)

    Each time the SHUTT/SUP-V switch is pressed to the SET position, the mode switches in the order of preset shutter, variable shutter and SUPER-V. Select "SUPER-V." Note: The ashing stops automatically in approximately 3 seconds after the setting operation ends. Press the SET button. To Cancel the Super-V Function ■ Set the SHUTT/SUP-V switch to OFF. HDK-79GX 1301 VER1 (U)

  • Page 95: Setting The Effect Fi Lter

    While the character of EFFECT fi lter position is fl ashing, turn the rotary pulse switch to any position, and press the SET button. Note: Flashing stops automatically about 3 seconds after the setting procedure is completed. HDK-79GX 1301 VER1 (U)

  • Page 96: Setting The Digital Extender

    Flashing stops automatically about 3 seconds after the setting procedure is completed. Reference: You can restrict the setting of ON/OFF and magni cation of the digital extender from the SET button. Refer to "5.2 Settings from the Menu", "Menu Con guration and content" (page 87). HDK-79GX 1301 VER1 (U)

  • Page 97: Switching The Gain

    For details on how to operate the various remote controllers, refer to the instruction manuals attached to the remote controllers. Use the GAIN (dB) on the remote controller to switch the setting according to the conditions. HDK-79GX 1301 VER1 (U)

  • Page 98: Allocating Functions To The P.func Switch

    Turns ON/OFF scene fi le 7 SCENE-8 Turns ON/OFF scene fi le 8 Set the P.FUNC switch to ON. The allocated function is now activated. Note: Setting the P.FUNC switch to OFF will turn the allocated function OFF. HDK-79GX 1301 VER1 (U)

  • Page 99: Screen Detail Enhancement (Dtl)

    Functions to the P.FUNC Switch" (page 82) for how to allocate the function. Activating from the Remote Controller ■ Reference: For details on how to operate the various remote controllers, refer to the instruction manuals attached to the remote controllers. HDK-79GX 1301 VER1 (U)

  • Page 100: Settings From The Menu

    Press the SET button while holding down the VF ＊＊＊ ＭＥＮＵ ＊＊＊ CHAR button on the front of the camera. ＶＦ DＩＳＰＬＡＹ The main menu appears in the view nder and monitor. ＶＦ DＴL ＶＦ ＭＯＤＥ ＦＯＣＵＳ ＡＳＳＩＳＴ ＭＩＣ ＧＡＩＮ ＣＯＮＴＲＯＬ ＲＥＴＵＲＮ ＳＥＬＥＣＴ ＭＯＤＥ ＦＩＬＴＥＲ ＳＥＲＶＯ ＭＯＤＥ ＳＷ ＦＵＮＣＴＩＯＮ ＩＮＦＯＲＭＡＴＩＯＮ  HDK-79GX 1301 VER1 (U)
  • Page 101 If the SET button is not pressed after selecting a value in the mode selection column, the change may be canceled. Note: - To return to the main menu, select " " and press the SET button. - The scroll guide is displayed on the submenu containing multiple items. HDK-79GX 1301 VER1 (U)
  • Page 102 This section explains how to exit the main menu/submenu in the view nder or monitor. Press the VF CHAR button on the front of the camera. The main menu/submenu disappears. Note: The menu in SE operation terminates when the MENU switch is turned OFF. HDK-79GX 1301 VER1 (U)

  • Page 103: Menu Confi Guration And Content

    *1 : It is possible to determine when loading MENU DATA from the SD CARD whether to read the entire MENU or to read only items related to VF. The setting of an item having a checkmark is read. *2: If the color VF is recognized automatically, the display switches to R/G/B. HDK-79GX 1301 VER1 (U)
  • Page 104 When assigning to ZOOM, FOCUS, a serial lens is required. RET-2 (HANDLE) RET-2 NONE 0 to 100 ZOOM SPEED Sets the operational speed of ZOOM, FOCUS control. The speed is slower for "0" and faster for "100". FOCUS SPEED 0 to 100 HDK-79GX 1301 VER1 (U)
  • Page 105 Sets the battery voltage threshold to display warning. BARS MODE Destination FULL : Displays the BARS signal conventionally used. BARS MODE FULL, MULTI setting MULTI : Displays the multiformat BARS signal. BARS ON ON, OFF Turns the color bar signal ON/OFF. HDK-79GX 1301 VER1 (U)
  • Page 106 GAIN changing switch, AWB SEMI REMOTE MODE OFF, ON changing switch, output changing switch and SHUTT/SUP-V switch on the right side of the camera. In this case, control on the remote controller side is not possible. HDK-79GX 1301 VER1 (U)
  • Page 107 When changing the switch, be sure to rst turn the power OFF. After compiling the reference le, be sure to return No. 2 of S11 to OFF. When compiling the reference le from the control panel, it is not necessary to turn this switch ON. HDK-79GX 1301 VER1 (U)
  • Page 108 V diminishes, making it possible to obtain an image with less noise. Can be turned on only when operating in 1080P29SF and LINE MIX ON, OFF 1080P25SF formats. Can reduce resolution in the vertical direction. HDK-79GX 1301 VER1 (U)
  • Page 109 MENU MODE If set to ON, possible to display engineer menu. ENGINEER MENU OFF, ON If the camera power is turned OFF, this menu setting returns to OFF. HDK-79GX 1301 VER1 (U)
  • Page 110 - Use an illumination meter to adjust the light so that light is evenly distributed over the whole chart. Dip switch S11-4 On allows creation of a lens fi le, Off prohibits creation of new lens fi les. HDK-79GX 1301 VER1 (U)
  • Page 111 Lens les memorize a difference in level between lenses. If the lighting or chart is changed, it cannot tell whether it is the lighting error, chart error, or lens error. HDK-79GX 1301 VER1 (U)
  • Page 112 "MANUAL" to "OFF", and press the SET button ＥＸＴＥＮＤＥＲ          ＯＦＦ to complete the lens fi le creation. Then, go to ＡＵＴＯ ＳＥＬ          ＯＦＦ M④ ＦＩＬＥ ＳＥＴ          ＯＦＦ Step 8. ＬＥＮＳ ＴＹＰＥ         ＊＊＊ Switch the cursor on "MANUAL" to "OFF"        ＬＥＮＳ ＮＯ．１ and confirm. HDK-79GX 1301 VER1 (U)
  • Page 113 Select the target lens （ＡＢ４０Ｘ１０ ＡＢＣＤ           ） The NO.5 lens set in "AUTO SEL" is selected here as number and confirm. ＥＸＴＥＮＤＥＲ  ＯＦＦ an example and the AUTO SEL NAME display part ＡＵＴＯ ＳＥＬ  ＯＦＦ ＦＩＬＥ ＳＥＴ  ＯＦＦ displays "AB40X10 ABCD". HDK-79GX 1301 VER1 (U)
  • Page 114 SET button. E⑧ （ＡＢ４０Ｘ１０ ＡＢＣＤ           ） Position the cursor on The item changes to the edit mode and ( ) at both ends the part for displaying ash. the lens name to be edited and confirm. ＮＯＷ ＣＯＮＮＥＣＴＥＤ ＬＥＮＳ （ＡＢ４０Ｘ１０ ＡＢＣＤ           ） HDK-79GX 1301 VER1 (U)
  • Page 115 3. "AUTO SEL NAME EDIT" is a function to edit the model name read through "AUTO READ". 4. This function is not available if the model name of the target serial lens has not been obtained through "AUTO READ". HDK-79GX 1301 VER1 (U)

  • Page 116: Using The Memory Card

    ＩＮＦＯＲＭＡＴＩＯＮ of the VF menu screen. When removing the memory card from the card slot, gently press the memory card until there is a clicking sound and then carefully remove the card. HDK-79GX 1301 VER1 (U)
  • Page 117 Never remove the memory card from the slot during display of [SAVING FILE] or while the access indicator is lighted, as data is being written to the memory card. Removing it at this time could damage the memory card data or the memory card itself. HDK-79GX 1301 VER1 (U)
  • Page 118 ＯＶＥＲＷＲＩＴＥ   ＮＯ Note: The images of the storage range for les are shown in the gure below. ALL FILE SNAPSHOT FILE Parameters for adjusting functions and ON/OFF state. SCENE FILE REFERENCE FILE (ABB/AWB) LENS FILE MENU FILE HDK-79GX 1301 VER1 (U)
  • Page 119 If changes as those listed below have been made in the le name stored to a PC, etc., it is not possible to display the le name normally. -If a le name with more than 8 characters has been set. -Using le names (kanji, kana, etc.) composed of characters other than half-size letters of the alphabet. HDK-79GX 1301 VER1 (U)
  • Page 120 Not a camera data fi le. FILE OF DIFFERENT CAMERA. Different type of fi le. RELEVANT DATA IS NOT FOUND. Relevant data cannot be found. WIRTE ERROR Write error. READ ERROR Read error. ERROR Other error. HDK-79GX 1301 VER1 (U)

  • Page 121: Trouble Shooting And Maintenance

    TROUBLE SHOOTING TROUBLE SHOOTING and MAINTENANCE and MAINTENANCE...
  • Page 122 HDK-79GX 1301 VER1 (U)

  • Page 123: Alarm Lamp On The Ocp Or Mcp Flashes On And Off

    HEAD CLS OPEN ±1 ±2 CABLE OPEN SHORT ALARM CALL PREVIEW ALARM indicator For the list of self diagnostic information of BSF-55, refer to the relevant operation manual. Perform the appropriate action referring to the list. HDK-79GX 1301 VER1 (U)

  • Page 124: Temp!!" Or "Fan!!" Appears On The Vf Screen

    To prevent temperature increase inside the camera, cooling fans are provided at the top of the camera and ber adaptor. For how to check which fan stops, refer to "5. CAMERA SETTINGS and ADJUSTMENT", "Menu Con guration and content" (page 87). HDK-79GX 1301 VER1 (U)

  • Page 125: Initializing The Settings Of This Product

    Press the SET button when the cursor ＰＲＥＳＥＴ ＦＩＬＥ ＬＯＡＤ automatically moves to "LOAD START". ＦＩＬＥ ＳＥＬＥＣＴ    ＥＮＧＩＮＥＥＲ The cursor moves to the mode selection column and ④ ＬＯＡＤ ＳＴＡＲＴ     ＲＥＡＤＹ Position the cursor on its display changes from "READY" to "START". "LOAD START" and confirm. HDK-79GX 1301 VER1 (U)
  • Page 126 "COMPLETED" is displayed at the bottom selected in "FILE SELECT". of the screen. ＰＲＥＳＥＴ ＦＩＬＥ ＬＯＡＤ ＦＩＬＥ ＳＥＬＥＣＴ    ＥＮＧＩＮＥＥＲ ＬＯＡＤ ＳＴＡＲＴ     ＳＴＡＲＴ ⑥     ＣＡＭＥＲＡ ＲＥＳＴＡＲＴ "CAMERA RESTART" is displayed at the bottom of the screen. HDK-79GX 1301 VER1 (U)

  • Page 127: Cleaning Camera Connectors

    Plug (male) Ferrule Plug (male) Alignment sleeve Receptacle (female) Receptacle (female) Ferrule Ferrule Ferrule Receptacle (male) Receptacle (male) Ferrule Male and Female Camera Connectors ● Receptacle (male) Plug (female) BSF-55 rear HDK-79GX Receptacle (female) Plug (male) HDK-79GX 1301 VER1 (U)
  • Page 128 Tighten the screw with a fl at-blade screwdriver or a coin. Camera male connectors have no "top" regardless of whether they are receptacles or plugs. For male connectors, therefore, steps 1, 2, and 6 above are not required. HDK-79GX 1301 VER1 (U)
  • Page 129 The extractor is removed from the alignment sleeve. Camera male connectors have neither "top" nor "alignment sleeve" regardless of whether they are receptacles or plugs. For male connectors, therefore, steps 1 to 3 and 8 above are not required. HDK-79GX 1301 VER1 (U)

  • Page 130: Reset The Breaker

    In this case, reset the breaker as follows: Check that the camera's POWER switch is OFF. Push in the breaker on the left side of the camera. Breaker HDK-79GX 1301 VER1 (U)

  • Page 131: Chapter 7 Specifications

    SPECIFICATIONS SPECIFICATIONS...
  • Page 132 HDK-79GX 1301 VER1 (U)

  • Page 133: Hdk-79Gx Specifi Cations

    7.1 HDK-79GX Specifi cations 7.1 HDK-79GX Specifi cations ■ Ratings Item Rating Remarks 1080/59.94i 1080/50i Scanning system Y:Pb:Pr 4:2:2 1080/29.97psF 1080/25psF Image sensor 2/3 inch CCD sensor Total pixels 2.3M Effective number of pixels 1920 (H)×1080 (V) 2000LX re ection rate 89.9 % Sensitivity F10 1080i/59.94...
  • Page 134 7.1 HDK-79GX Specifi cations ■ Output signals (FA-55) Item Rating Remarks Y,Pb,Pr 4:2:2 digital serial (optical connector) Main line video signal BTA S-004B compliant Y,Pb,Pr 4:2:2 digital serial (75 BNC) Monitor video signal RET image HD SDI 4:1:1 or VF HD SDI 4:2:2...

  • Page 135: External Dimensions Diagram

    7.2 External Dimensions Diagram 7.2 External Dimensions Diagram ■  Right View ±5 ±1 HDK-79GX 1301 VER1 (U)
  • Page 136 7.2 External Dimensions Diagram ■  Left View ±3 ±1 ±5 HDK-79GX 1301 VER1 (U)
  • Page 137 7.2 External Dimensions Diagram ■  Front View ±3 138.5 HDK-79GX 1301 VER1 (U)
  • Page 138 7.2 External Dimensions Diagram ■  Rear View ±3 138.5 HDK-79GX 1301 VER1 (U)

  • Page 139: External Connections

    (6.2 V± 0.1 V) F 16 : 3.4 V± 0.05 V ⑦ IRIS FOLLOW (3.4 V± 0.1 V) CLOSE : 2.5 V± 0.2 V (2.1 V to 2.9 V) Zin = 100 k ± 2% (100 k or more) HDK-79GX 1301 VER1 (U)
  • Page 140 ⑫ CAMERA → LENS + 0.5 V CMOS level (VCC 5V ±0.25V) Numbers within parentheses are standard values in the conventional SDTV system of 2/3-inch camera lens. : camera <- lens OUT : camera -> lens HDK-79GX 1301 VER1 (U)
  • Page 141 Ground for B VF VIDEO output signal ⑱ R VF VIDEO R VF VIDEO output signal ⑲ R VF VIDEO RET Ground for R VF VIDEO output signal ⑳ +12V RET Ground for DC+12V power supply HDK-79GX 1301 VER1 (U)
  • Page 142 Optical contact BS -> Camera ③ CONTROL (H) Control signal (H) BS -> Camera ④ CONTROL (C) Control signal (C) Camera -> BS ⑤ POWER (H) Power (H) supplied from BS ⑥ POWER (C) Power (C) supplied from BS HDK-79GX 1301 VER1 (U)
  • Page 143 Shield for intercom microphone input (H) ③ TALK (C) ④ TALK (H) Intercom microphone input (H) ⑤ COMM COMM GND terminal Intercom receiver R output (H) ⑥ LISTEN R (H) Shield for Intercom receiver R output (H) ⑦ LISTEN R (C) HDK-79GX 1301 VER1 (U)
  • Page 144 Pin No. Name Function External Interface ① TALK (C) Shield for intercom microphone input (H) ② TALK (H) Intercom microphone input ③ LISTEN (C) Shield for LISTEN output (H) ④ LISTEN (H) LISTEN L output (H) HDK-79GX 1301 VER1 (U)
  • Page 145 Connect to R (ring) of plug ③ LISTEN L (C) Termination for when the plug was removed ④ TALK (C) Termination for when the plug was removed Intercom microphone input (H) ⑤ TALK (H) Connect to T (tip) of plug HDK-79GX 1301 VER1 (U)
  • Page 146 Pin No. Name Function External Interface ① +12 V RET +12V input RET ② ③ ④ +12 V IN +12V input (11V to 16V) To power switch Pin A of connector on VTR (DC +12V input) HDK-79GX 1301 VER1 (U)
  • Page 147 + 12 V (REM) DC +12V power supply to remote controller ○ + 12 V RET (REM) Ground for DC +12V power supply ○ REM LISTEN Intercom output from remote controller ○ REM TALK Intercom input to remote controller HDK-79GX 1301 VER1 (U)
  • Page 148 VF R / Pr ○ 0.7 V 0.35 V Zout = 75 ○ N . C (Unusable) ○ N . C (Unusable) ○ N . C (Unusable) ○ N . C (Unusable) ○ N . C (Unusable) HDK-79GX 1301 VER1 (U)
  • Page 149 (2.0 V± 0.2 V) FOCUS FOLLOW SE Infinite distance : 7.0 V± 0.05 V ○ (7.0 V± 0.2 V) Zin = 100 k ± 2% (20 k or more) Zout = 1 k ± 10% (1 k or less) HDK-79GX 1301 VER1 (U)
  • Page 150 Zout = 1 k ± 10% (1 k or less) N . C (Unusable) ○ N . C (Unusable) ○ N . C (Unusable) ○ ○ N . C (Unusable) ○ N . C (Unusable) ○ N . C (Unusable) HDK-79GX 1301 VER1 (U)
  • Page 151 Cable side : PRC05-P3M Insertion Side Pin No. Name Function External Interface + 12 V ○ DC + 12V power supply + 12 V RET ○ Ground for DC + 12V power supply N . C ○ HDK-79GX 1301 VER1 (U)

  • Page 152: Scene File

    7.4 Scene File 7.4 Scene File ■ Save condition of a HDK-79GX scene file BSF-55 Item Save Data SELF DTL CONT HEAD GAIN -6dB to +18dB CAMERA CAMERA GAMMA OFF/0.35/0.40/0.45 CAMERA CAMERA GAMMA TYPE NORMAL, CINE1 to 2, CUSTOM1 to 5...

  • Page 153: Changing Information

    This chapter contains the revision information of user-speci c speci cation or design change requested by users or any changes done by Ikegami. Read by comparing this information with the main part of the operation manual. HDK-79GX 1301 VER1 (U)
  • Page 154 HDK-79GX 1301 VER1 (U)
  • Page 155 Ikegami Tsushinki Co., Ltd. - All rights reserved. Reproduction or duplication, without permission of Ikegami Tsushinki Co., Ltd. of editorial or pictorial content in whole or in part, in any manner, is prohibited. - Speci cations and design are subject to change without prior notice.
  • Page 158 Ikegami Tsushinki Co., Ltd. 5-6-16, Ikegami, Ohta-ku, Tokyo, 146-8567, Japan Phone : +81-(0)3-5700-4114 Fax : +81-(0)3-5748-2200 E-Mail : info_e@ikegami.co.jp URL : http://www.ikegami.co.jp/en/ Ikegami Electronics (U.S.A.),Inc. 37 Brook Avenue, Maywood, New Jersey 07607, U.S.A. Phone : +1-201-368-9171 Fax : +1-201-569-1626 E-Mail : engineering@ikegami.com, service@ikegami.com URL : http://www.ikegami.com...

This manual is also suitable for:

Fa-55

Table of Contents

Save PDF
