Ikegami IHD-D525S Instruction Manual

Hybrid camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Hybrid Camera
MODEL
IHD-D525S
OUTDOOR USE WARING
WARNING – TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
The apparatus shall not be exposed to
dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the
apparatus.
Ikegami Electronics
, Inc.
(U.S.A)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IHD-D525S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ikegami IHD-D525S

Summary of Contents for Ikegami IHD-D525S

  • Page 1 INSTRUCTION MANUAL Hybrid Camera MODEL IHD-D525S OUTDOOR USE WARING WARNING – TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

  • Page 2: Table Of Contents

    Thank you for choosing this Ikegami Hybrid Camera. Please read this Instruction Manual carefully to keep your Ikegami camera at peak performance for longer service period. This unit is a dome-type 1 CMOS color camera and making use of a 1/2.9” sensor.
  • Page 3 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
  • Page 5 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

  • Page 6: Handling Precautions

    1. Handling Precautions • Do not expose the internal mechanism of the camera in a water-splashed or highly humid environment. • Do not use the camera where the ambient temperature drops below -10°C or rises above +50°C. The images and component parts may be adversely affected or the camera may not function correctly.

  • Page 7: Features

    3. Features (1) Compact Dome Configuration The camera lens is housed in a compact dome configuration to enable surveillance with images without having to be aware that a camera is installed. (2) Integrated unit with triaxial adjustment varifocal lens in a single unit This is an integrated type design featuring a varifocal lens.

  • Page 8: Camera Installation

    4. Camera Installation 4-1. Pre-work before installation For camera fixing, two holes are needed. Holes for camera fixing 4-2. Mounting the camera (Ceiling) Put two fixing screws leaving about 5mm clearance. Those two screws will be tightened later to secure the dome camera. Put the cable wiring ①...

  • Page 9: Name Of Each Section And Its Function

    5. Name of each section and its function ③ ② ① ④ ⑥ ⑤ ⑦ ⑧...
  • Page 10 ① Lens fixing screws (elevation) These are screws to fix the camera in the desired elevation position. Fix these screws after setting the viewing position. ② Vari-focal lens Can be used with flexible angle of view using varifocal lens. ③ Switches for camera setup Refer to Section 8 (Operating Procedure) ④...

  • Page 11: Connections

    6. Connections Be sure not to apply power before making connections. 6-1. Power cable Use DC12V (10.5V to 15V), or AC24V (± 10%) in both 60Hz and 50Hz. * This installation should be made by a qualified service person and should conform to all local codes.

  • Page 12: Angle And Lens Adjustment

    Angle and Lens adjustment 7-1. Angle adjustment Before doing this, the clear dome cover has to be ● removed. Remove the dome cover Turn the black section of the dome cover in a counterclockwise direction to remove. Pay attention not to drop a dome cover while doing this.

  • Page 13: Operating Procedure

    8. Operating Procedure 8-1. User Setup This dome camera is provided with user setup function for picture quality, and camera ID. The setup menu is a tree type on-screen-display. When installing the camera it is possible to set up the various functions. 8-2.
  • Page 14 8-3-1. MAIN MENU When the OSD menu is launched, you are presented with the adjacent opening screen. A menu option followed by a indicates the presence of a sub-menu. Options set to OFF will not show a until set to ON. Use RETURN to the previous menu.
  • Page 15 (2)EXPOSURE It selects Lens Mode, Brightness, Shutter speed, Sens-up and AGC Gain. ① LENS - DC or Manual selection. ② BRIGHTNESS - Sets the level of the overall. ③ SHUTTER - Auto, Manual, FLK selection, 1/30~1/30K. Set this on to reduce the exposure time of each image. This can be used to reduce blur in images with fast changing content.
  • Page 16 (4)DAY & NIGHT Selecting Day or Night is available. ① AUTO - The image is automatically switched between high-quality color image for the day and highly-sensitive monochrome image for the night. ② COLOR - Fixes the camera in color mode. ③...
  • Page 17 (6)DNR(Digital Noise Reduction) This function is used to improve the picture quality by filtering the noise which is generated under low light conditions. (7)ADJUST Color gain, sharpness, gamma, mirror, flip, ace, defog and privacy are available. ① COLOR GAIN It adjusts the color intensity. ②...
  • Page 18 (8)MOTION This function detects and dispalys the object in motion. ① DET WINDOWS Select and set up to 4 motion areas. ② SENSITIVITY Level control. ③ TEXT ALARM Display “Motion Alarm” on Screen. ④ SIGNAL OUT - N/A MOTION DET WINDOWS DET TONE MDDECT FILL SENSITIVITY...
  • Page 19 (9)SYSTEM ① OUTPUT CVBS(default), CVI, AHD Selectable. ② FRAME RATE Select from 1080P - 30P or 720P - 30P or 720 - 60P ③ FREQ 60Hz or 50Hz can be seleted. ④ Set com port and speed. ⑤ IMAGE RANGE Used to adjust black level in dark sceen.

  • Page 20: Warranty And After-Sale Service

    9. Warranty and after-sale service A warranty accompanies this product. Read and fill out the warranty card ● Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics that you have received at your dealer. Keep this card in a safe place.
  • Page 21 (1) Image Sensor: 2Mega Pixel Cmos Sensor (2) HD Resolution: Full HD (1920 x 1080) (3) Scanning system: 16:9 Progressive scan (4) Sync system: Internal (5) Video output: Analog Output-CVBS(default) HD Output-CVI,AHD(Full HD) (6) Day/Night switching: Digital Day/Night (7) S/N ratio: Over 52dB(p-p/rms) (8) Minimum object illumination: 0.08Lx at B/W at Sens up<<off>>...
  • Page 22 Dome cover: (23) Inner and Outer, Double Dome Type Φ124.2mm x 102.0mm (excluding protrusions) Size (Diameter & Height): (24) Weight: Approx. 340g (25) Input/Output connectors: • VIDEO OUT: BNC (26) • Power input : open-ended wires • MON.out : Connecter output (27) Supplied accessories: Instruction Manual: Tapping screws to secure camera: 2...

  • Page 23: External Appearance

    11. External Appearance 100.0 124.2 (Unit:mm)

  • Page 24: Setup Flow Chart

    12. Setup Flow Chart...
  • Page 26 Ikegami Electronics (U.S.A.), Inc. 300 Route 17 South, Mahwah, NJ 07430, U.S.A. Phone: (201) 368-9171, FAX (201) 569-1626 cctv@ikegami.com www.Ikegami.com...
