Intel P4000IP Series Technical Product Specification
Intel P4000IP Series Technical Product Specification

Intel P4000IP Series Technical Product Specification

Server system/workstation system
Hide thumbs Also See for P4000IP Series:
Table of Contents

Advertisement

®
Intel
Server System P4000IP and
®
Intel
Workstation System
P4000CR Family
Technical Product Specification
Intel reference number G38159-001
Enterprise Platforms and Services Marketing
Revision 1.0
February, 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4000IP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intel P4000IP Series

  • Page 1 ® Intel Server System P4000IP and ® Intel Workstation System P4000CR Family Technical Product Specification Intel reference number G38159-001 Revision 1.0 February, 2012 Enterprise Platforms and Services Marketing...
  • Page 2: Revision History

    It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of air flow required for their specific application and environmental conditions.
  • Page 3: Table Of Contents

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table of Contents Table of Contents ® ® 1. Intel Server System P4000IP and Intel Workstation System Overview ....... 1 Intergrated System family overview ................ 1 ® 1.1.1 Intel Server System P4208IP4LHGC View ............
  • Page 4 Table of Contents Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 1200-W Power Supply ..................36 2.2.1 Mechanical Overview ................... 36 2.2.2 AC Input Requirements ..................39 2.2.3 Efficiency......................41 2.2.4 DC Output Specification ..................41 2.2.5 Protection Circuits ....................
  • Page 5 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table of Contents Fan Header Connector Descriptions ..............80 4. Storage and Peripheral Drive Bays ................. 81 2.5‟„ Hard Disk Drive Support ................81 4.1.1 2.5'' Drive Hot-Swap Backplane Overview ............82 4.1.2...
  • Page 6 List of Figures Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS List of Figures ® Figure 1. Internal Chassis View of Intel Server System P4208IP4LHGC ........6 ® Figure 2. Internal Chassis View of Intel Server System P4216IP4LHJC ........7 ®...
  • Page 7 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS List of Figures ® Figure 32. Fixed Fans in Intel Workstation System P4000CR ..........79 ® Figure 33. Hot-swap Fans in Intel Server System P4000IP ............. 80 Figure 34. 2.5'' Hard Disk Drive Cage ..................81 Figure 35.
  • Page 8 List of Tables Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS List of Tables ® Table 1. Intel Server System P4000IP Hot-Swap 3.5 HDDs and Non-HDD configuration base feature ..........................3 ® Table 2. Intel Server System P4000IP Hot-Swap 2.5 HDDs configuration base feature .... 4 ®...
  • Page 9 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS List of Tables Table 32. AC Line Sag Transient Performance ................. 41 Table 33. AC Line Surge Transient Performance ..............41 Table 34. Platinum Efficiency Requirement................41 Table 35. Minimum Load Ratings ....................42 Table 36.
  • Page 10 List of Tables Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 66 SMBAlert# Signal Characteristics ................62 Table 67. Thermal Requirements ....................65 Table 68. Input Connector and Pin Assignment Diagrams ............66 Table 69. PDB Cable Length ....................66 Table 70.
  • Page 11 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS List of Tables <This page is intentionally left blank.> Revision 1.0 Intel order number G38159-001...
  • Page 13: Intel Server System P4000Ip And Intel Workstation System Overview

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® ® Intel Server System P4000IP and Intel Workstation System Overview ® ® Intel Server System P4000IP and Intel Workstation System is 4U pedestal, 27'' length server ®...
  • Page 14 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® Your Intel Server System P4216IP4LHJC ships with the following items: ®  One Intel Server Board S2600IP4  Two CRPS 1200W power supply, installed in the chassis ...
  • Page 15: Table 1. Intel Server System P4000Ip Hot-Swap 3.5 Hdds And Non-Hdd Configuration Base Feature

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® Your Intel Server System P4216IP4LHKC ships with the following items: ®  One Intel Server Board S2600IP  Two CRPS 1600W power supply, installed in the chassis ...
  • Page 16: Table 2. Intel Server System P4000Ip Hot-Swap 2.5 Hdds Configuration Base Feature

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview Feature P4308IP4LHGC P4308IP4LHJC (L) P4308IP4LHKC  Four Back panel USB ports  One rear panel video port Video ® Table 2. Intel Server System P4000IP Hot-Swap 2.5 HDDs configuration base feature...
  • Page 17 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview Feature P4304CR2LFGN P4304CR2LFJN(L) P4304CR2LFKN option selected)  With Front Panel NIC1 Activity NIC2 Activity NIC3 Activity (no functional) LEDs and displays...
  • Page 18: Intel ® Server System P4208Ip4Lhgc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.1 Intel Server System P4208IP4LHGC View 750W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 19: Intel ® Server System P4216Ip4Lhjc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.2 Intel Server System P4216IP4LHJC View 1200W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 20: Intel ® Server System P4216Ip4Lhkc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.3 Intel Server System P4216IP4LHKC View 1600W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 21: Intel ® Server System P4224Ip4Lhkc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.4 Intel Server System P4224IP4LHKC View 1600W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 22: Intel ® Server System P4308Ip4Lhgc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.5 Intel Server System P4308IP4LHGC View 750W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 23: Intel ® Server System P4308Ip4Lhjc(L) View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.6 Intel Server System P4308IP4LHJC(L) View 1200W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 24: Intel ® Server System P4308Ip4Lhkc View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.7 Intel Server System P4308IP4LHKC View 1600W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 25: Intel ® Workstation System P4304Cr2Lfgn View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.8 Intel Workstation System P4304CR2LFGN View 750W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 26: Intel ® Workstation System P4304Cr2Lfjn(L) View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.9 Intel Workstation System P4304CR2LFJN(L) View 1200W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 27: Intel ® Workstation System P4304Cr2Lfkn View

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ® 1.1.10 Intel Workstation System P4304CR2LFKN View 1600W CRPS Power supply AC Input Power connecotor C. I/O ports D. Serial port knockout...
  • Page 28: Chassis Dimensions

    This Front Control Panel conforms to SSI specification with one exception that up to 4 LAN act/link LEDs are supported. The common front panel can support either the standard SSI 2x12 cable interconnect (2 LAN ports) or an Intel customized 2x15 cable interconnect (4 LAN ports). The Front Control Panel has the following features: ...
  • Page 29: Table 4. Power/Sleep Led Functional States

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview ID Button with integrated ID LED – Toggles the integrated ID LED and the Blue server board ID LED on and off. The ID LED is used to identify the system for maintenance when installed in a rack of similar server systems.
  • Page 30: Front Control Panel Led Status

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview USB Ports – In addition, the front panel provides two USB ports. The USB ports are cabled to the 2x5 connector on the server board.
  • Page 31: Back Panel Feature Overveiw

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview Back panel feature Overveiw CRPS Power supply IO module slot cover AC Input Power connecotor Alternate RMM4 knockout I/O ports...
  • Page 32: Hot Swap Hard Drivers And Front Panel Options

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview Hot swap Hard Drivers and front panel options Figure 13. Hot-Swap Hard Disk Drive Cage Chassis Security A variety of chassis security options are provided at the system level: ...
  • Page 33: Front Bezel Features

    Workstation System P4000CR. Figure 14. Front Closed Chassis View for Fixed Hard Drives Configuration ® Front bezel assembly with the door for hot-swap hard drives configuration on Intel Server System P4000IP. Security Lock Figure 15. Front Closed Chassis View for Hot-swap Hard Drives Configuration Both two pedestal front bezel are constructed of molded plastic and attaches to the front of the chassis with three clips on the right side and two snaps on the left.
  • Page 34 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Intel® Server System P4000IP and Intel® Workstation System Overview only be removed by first removing the server access cover. This provides additional security to the hard drive and peripheral bay area.
  • Page 35: System Power Sub-System

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 750-W Power Supply This specification defines a 750W redundant power supply that supports server systems. This power supply has 2 outputs; 12V and 12V standby. The AC input is auto ranging and power factor corrected.
  • Page 36: Table 7. Led Characteristics

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Name Name +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V PMBus SDA A0 (SMBus address) PMBus SCL...
  • Page 37: Ac Input Requirements

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Power Supply Condition LED State Output ON and OK GREEN No AC power to all power supplies AC present/Only 12VSB on (PS off) or PS in Cold redundant state 1Hz Blink GREEN AC cord unplugged or AC power lost;...
  • Page 38: Table 10. Power Factor Requirements For Computer Servers

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Table 10. Power Factor Requirements for Computer Servers 10% load Output power 20% load 50% load 100% load > 0.65 Power factor > 0.80 > 0.90 >...
  • Page 39: Table 13. Ac Line Sag Transient Performance

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.1.2.5 AC Line 12VSBHoldup The 12VSB output voltage stays in regulation under its full load (static or dynamic) during an AC dropout of 70ms min (=12VSB holdup time) whether the power supply is in ON or OFF state (PSON asserted or de-asserted).
  • Page 40: Efficiency

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 2.1.3 Efficiency The following table provides the required minimum efficiency level at various loading conditions. These are provided at three different load levels; 100%, 50%, 20%, and 10%. Output shall be load according to the proportional loading method defined by 80 Plus in Generalized Internal Power Supply Efficiency Testing Protocol, Rev.
  • Page 41: Table 17. Voltage Regulation Limits

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 17. Voltage Regulation Limits Parameter Tolerance Units +12V - 5%/+5% +11.40 +12.00 +12.60 +12V stby - 5%/+5% +11.40 +12.00 +12.60 2.1.4.5 Dynamic Loading The output voltages remains within limits specified for the step loading and capacitive loading specified in the table below.
  • Page 42: Table 20. Ripples And Noise

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system The residual voltage at the power supply outputs for no load condition does not exceed 100mV when AC voltage is applied and the PSON# signal is de-asserted.
  • Page 43: Figure 17. Differential Noise Test Setup

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS LOAD MUST BE AC HOT ISOLATED FROM POWER SUPPLY LOAD THE GROUND OF RETURN AC NEUTRAL THE POWER 10uF SUPPLY .1uF AC GROUND GENERAL NOTES: LOAD THE OUTPUT WITH ITS MINIMUM LOAD CURRENT.
  • Page 44: Protection Circuits

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Item Description Units signal. Delay from 12VSBbeing in regulation to O/Ps 1000 sb_vout being in regulation at AC turn on. Time the 12VSBoutput voltage stays within 12VSB_holdup regulation after loss of AC.
  • Page 45: Control And Indicator Functions

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 22. Over Current Protection Output VOLTAGE Input voltage range Over Current Limits 90 – 264VAC +12V 72A min; 78A max 90 – 264VAC 12VSB 2.5A min; 3.5A max 2.1.5.2...
  • Page 46: Figure 19. Pson# Required Signal Characteristic

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Signal Type Accepts an open collector/drain input from the system. Pull-up to VSB located in power supply. Logic level low (power supply ON) 1.0V Logic level high (power supply OFF) 2.0V...
  • Page 47: Thermal Clst

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Signal Type Open collector/drain output from power supply. Pull-up to VSB located in the power supply. PWOK rise and fall time 100sec Power down delay: T...
  • Page 48: Firmware Uploader

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 2.1.9 Firmware Uploader The power supply has the capability to update its firmware from the PMBus interface while it is in standby mode. This FW can be updated when in the system and in standby mode and outside the system with power applied to the 12Vstby pins.
  • Page 49: Table 27. Dc Output Connector

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 27. DC Output Connector Name Name +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V PMBus SDA...
  • Page 50: Table 28. Led Characteristics

    AC power cord is pulled into the power supply. The handle shall protect the operator from any burn hazard through the use of the Intel Corporation Industrial designed plastic handle or equivalent Intel approved material.
  • Page 51: Ac Input Requirements

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Item Description UNITS Operating temperature range; rack/pedestal 3000m op_rackped_ C 3000 ( 100% load, 3000m, rack/pedestal system flow impedance ) C Texit Maximum exit air temperature C...
  • Page 52 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Voltage (110) 90 V 100-127 V 140 V 85VAC +/- 74VAC +/- 4VAC 5VAC Voltage (220) 180 V 200-240 V 264 V Frequency 47 Hz 50/60...
  • Page 53: Efficiency

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 32. AC Line Sag Transient Performance AC Line Sag (10sec interval between each sagging) Duration Operating AC Voltage Line Frequency Performance Criteria 0 to 1/2 AC...
  • Page 54: Table 35. Minimum Load Ratings

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Table 35. Minimum Load Ratings Parameter Max. Peak 2, 3 Unit 12V main (200- 240VAC) 12V main (100- 127VAC) 12Vstby Notes: 12Vstby must provide 6A with two power supplies in parallel. The power supply fan is allowed to run in standby mode for loads >...
  • Page 55: Table 37. Transient Load Requirements

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 37. Transient Load Requirements Output  Step Load Size (See note) Load Slew Rate Test capacitive Load 20 F +12VSB 1.0A 0.25 A/sec 2000 F...
  • Page 56: Figure 21. Differential Noise Test Setup

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system with the capacitive load specified. The hot swap test must be conducted when the system is operating under static, dynamic, and zero loading conditions. The power supply shall use a latching mechanism to prevent insertion and extraction of the power supply when the AC power cord is inserted into the power supply.
  • Page 57: Protection Circuits

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.2.4.13 Timing Requirements These are the timing requirements for the power supply operation. The output voltages must rise from 10% to within regulation limits (T ) within 5 to 70ms. For 12VSB, it is allowed to vout_rise rise from 1.0 to 25ms.
  • Page 58: Control And Indicator Functions

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system latch off. The latch will be cleared by toggling the PSON signal or by an AC power interruption. The power supply shall not be damaged from repeated power cycling in this condition. 12VSB will be auto-recovered after removing OCP limit.
  • Page 59: Figure 22. Pson# Required Signal Characteristic

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Signal Type Accepts an open collector/drain input from the system. Pull-up to VSB located in power supply. PSON = Low PSON = High or Open Logic level low (power supply ON) 1.0V...
  • Page 60: Figure 23. Pwok Circuit Requirement

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system PWOK = High Power OK PWOK = Low Power Not OK Logic level low voltage, Isink=400uA 0.4V Logic level high voltage, Isource=200A 2.4V 3.46V Sink current, PWOK = low...
  • Page 61: Thermal Clst

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Open collector/drain output from power supply. Pull-up to Signal Type (Active Low) VSB located in system. Alert# = High Alert# = Low Power Alert to system Logic level low voltage, Isink=4 mA 0.4 V...
  • Page 62: Figure 24. Power Supply Outline Drawing

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Airflow direction Retention Latch 265mm 73.5m 40x56mm fan FCI 2x25 card edge connector 10035388-106 39mm 8.5mm Figure 24. Power Supply Outline Drawing 2.3.1.1 DC Output Connector...
  • Page 63: Table 47. Led Characteristics

    AC power cord is pulled into the power supply. The handle shall protect the operator from any burn hazard through the use of the Intel Corporation Industrial designed plastic handle or equivalent Intel approved material.
  • Page 64: Ac Input Requirements

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Power Supply Condition LED State Output ON and OK Solid GREEN No AC power to all power supplies AC present/Only 12VSB on (PS off) or PS in Cold redundant state 1Hz Blink GREEN AC cord unplugged;...
  • Page 65: Table 51 Ac Input Voltage Range

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.3.2.2 AC Inlet Connector The AC input connector shall be an IEC 320 C-14 power inlet. This inlet is rated for 10A/250VAC. 2.3.2.3 AC Input Voltage Specification The power supply must operate within all specified limits over the following input voltage range.
  • Page 66: Efficiency

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system conditions. All protection circuits in the power supply shall not cause the AC fuse to blow unless a component in the power supply has failed. This includes DC output load short conditions.
  • Page 67: Dc Output Specification

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.3.4 DC Output Specification 2.3.4.1 Output Power/Currents The following tables define the minimum power and current ratings. The power supply must meet both static and dynamic voltage regulation requirements for all conditions.
  • Page 68: Table 59. Capacitive Loading Conditions

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system (See note 2) 20 F +12VSB 1.0A 0.25 A/sec 2000 F +12V 60% of max load 0.25 A/sec Note: For dynamic condition +12V min loading is 1A.
  • Page 69: Figure 25 Differential Noise Test Setup

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS latching mechanism to prevent insertion and extraction of the power supply when the AC power cord is inserted into the power supply. 2.3.4.10 Forced Load Sharing The +12V output will have active load sharing.
  • Page 70: Table 61. Timing Requirements

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Note: When performing this test, the probe clips and capacitors should be located close to the load. 2.3.4.12 Timing Requirements These are the timing requirements for the power supply operation. The output voltages must rise from 10% to within regulation limits (T ) within 5 to 70ms.
  • Page 71: Protection Circuits

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS AC Input vout_holdup Vout pwok_low AC_on_delay pwok_off sb_on_delay sb_on_delay pwok_on pwok_off pwok_on PWOK pson_pwok pwok_holdup 12Vsb sb_vout 5Vsb holdup pson_on_delay PSON AC turn on/off cycle PSON turn on/off cycle Figure 26 Turn On/Off Timing (Power Supply Signals) 2.3.5...
  • Page 72: Control And Indicator Functions

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system output of the power supply‟s connectors. The voltage shall never exceed the maximum levels when measured at the power connectors of the power supply connector during any single point of fail.
  • Page 73: Figure 27. Pson# Required Signal Characteristic

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 0.3V ≤ Hysterisis ≤ 1.0V In 1.0-2.0V input voltages range is required Disabled  1.0 V PS  2.0 V PS is enabled is disabled Enabled 2.0V...
  • Page 74: Thermal Clst

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 3.3VSB 2N4401 PWOK out 2N4401 PWOK in Figure 28. PWOK Circuit Requirement 2.3.6.3 SMBAlert# Signal This signal indicates that the power supply is experiencing a problem that the user should investigate.
  • Page 75: Firmware Update

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.3.9 Firmware Update The power supply shall have the capability to update its firmware from the PMBus interface while it is in standby mode. This FW can be updated when in the system and in standby mode and outside the system with power applied to the 12Vstby pins.
  • Page 76: Mechanical Overview

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 2.4.1 Mechanical Overview Figure 29. Outline Drawing Intel order number G38159-001 Revision 1.0...
  • Page 77: Dc Output Specification

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.4.1.1 Airflow Requirements The power distribution board shall get enough airflow for cooling DC/DC converters from the fans located in the Power Supply modules. Below is a basic drawing showing airflow direction.
  • Page 78: Table 68. Input Connector And Pin Assignment Diagrams

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system for future 0.093'' PCBs in the system. The card edge connector has no keying features; the keying method is accomplished by the system sheet metal. Table 68. Input Connector and Pin Assignment Diagrams...
  • Page 79: Table 70. P1 Baseboard Power Connector

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS To connector From Length, mm No of pins Description Power Supply cover exit hole Processor 0 connector Power Supply cover exit hole Processor 1 connector Power Supply cover exit hole...
  • Page 80: Table 71. P0 Processor Power Connector

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Signal 18 AWG Color Signal 18 AWG Color PWR OK Gray (24AWG) Reserved N.C. 5 VSB Purple +5VDC +12V1 Yellow +5VDC +12V1 Yellow +5VDC +3.3VDC Orange Black 2.4.2.2.2...
  • Page 81: Table 74. P12 12V Connectors

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.4.2.2.5 2x2 12V connector (P12-P16) Connector header: Foxconn p/n HM3502E-P1 or equivalent Table 74. P12 12V connectors Signal 18 AWG color Signal 18 AWG Color Black...
  • Page 82: Table 79. Remote Sense Connection Points

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Signal 18 AWG Color Black +12V3 Yellow 2.4.2.3 Grounding The ground of the pins of the PDB output connectors provides the power return path. The output connector ground pins is connected to safety ground (PDB enclosure). This grounding is well designed to ensure passing the max allowed Common Mode Noise levels.
  • Page 83: Table 81. 12V Rail Distribution

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.4.2.5 12V Rail Distribution The below table shows the configuration of the 12V rails and what connectors and components in the system they are powering. Table 81. 12V Rail Distribution...
  • Page 84: Table 82. Hard Drive 12V Rail Configuration Options

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 2.4.2.6 Hard Drive 12V rail configuration options The below table shows the hard drive configuration options using the defined power connectors. In some cases additional converter or „Y‟ cables are needed.
  • Page 85: Table 85. Voltage Regulation Limits

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.4.2.9 DC/DC Converters Voltage Regulation The DC/DC converters‟ output voltages stay within the following voltage limits when operating at steady state and dynamic loading conditions. These limits include the peak-peak ripple/noise specified in Table 95.
  • Page 86: Figure 31. Differential Noise Test Setup

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system 2.4.2.13 Common Mode Noise The Common Mode noise on any output does not exceed 350mV pk-pk over the frequency band of 10Hz to 20MHz.  The measurement shall be made across a 100Ω resistor between each of DC outputs, including ground, at the DC power connector and chassis ground (power subsystem enclosure).
  • Page 87: Protection Circuits

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Description Units Output voltage rise time for each main output; 3.3V, 5V, -12V and msec 5Vstby. The main DC/DC converters (3.3V, 5V, -12V) shall be in regulation msec limits within this time after the 12V input has reached 11.4V.
  • Page 88: Pwok (Power Ok) Signal

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS System Power Sub-system Table 90. PDB Over Current Protection Limits/240VA Protection Output Voltage Min OCP Trip Limits Max OCP Trip Limits Usage +3.3V PCIe, Misc Meet 240VA PCIe, HDD, Misc...
  • Page 89: Pmbus

    System Power Sub-system Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 2.4.6 PMBus The PDB has no components on it to support PMBus. It only needs to connect the power supply PMBus signals (clock, data, SMBAlert#) and pass them to the 1x5 signal connector.
  • Page 90: Thermal Management

    ® The Intel Server System P4000IP is designed to operate at external ambient temperatures of between 10º C- 35º C. Working with integrated platform management, several features within the system are designed to move air in a front to back direction, through the system and over critical components in order to prevent them from overheating and allow the system to operate with best performance.
  • Page 91: Non-Redundant Cooling Solution

    Thermal Management Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Corresponding air ducts are needed in both configurations for supported boards. 3.3.1 Non-Redundant Cooling Solution ® Non-Redundant cooling solution is used in the Intel Workstation System P4000CR.
  • Page 92: Fan Control

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Thermal Management ® Figure 33. Hot-swap Fans in Intel Server System P4000IP Fan Control ® The fans provided in the Intel Server Chassis P4000M Family contains a tachometer signal ®...
  • Page 93: Storage And Peripheral Drive Bays

    Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays ® ® The Intel Server System P4000IP and the Intel Workstation System P4000CR product family has support for many storage device options, including: ...
  • Page 94: 2.5'' Drive Hot-Swap Backplane Overview

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays Amber Status LED Green Activity LED Figure 35. 2.5'' Hard Disk Drive Support - LED Status Table 94. 2.5'' Hard Disk Drive Status LED States...
  • Page 95: Cypress* Cy8C22545 Enclosure Management Controller

    Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS There are several connectors on the backside of each backplane. The following illustration identifies each of them: Label Description 4-port Mini-SAS cable connectors SMBus-Out cable connector for multi-backplane support Power connector SMBus-In cable connector –...
  • Page 96: Hard Disk Drive Support

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays 3.5'' Hard Disk Drive Support ® The Intel Server System P4308CP4MHEN and P4308CP4MHGC support 8x3.5'' drive configuration. The drive bay can support either SATA or SAS hard disk drives. Mixing of drive types within the hard drive bay is not supported.
  • Page 97: Drive Hot-Swap Backplane Overview

    Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Table 97. 3.5'' Hard Disk Drive Activity LED States Condition Drive Type Behavior LED stays on Power on with no drive activity SATA LED stays off...
  • Page 98: Figure 41. 2.5'' Backplane, Back Side

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays Label Description Reserved Power connector 4-port mini-SAS connectors SMBus connector Drive connector interface Figure 41. 2.5'' Backplane, Back Side A – Reserved B – Power Harness Connector - The backplane includes a 2x2 connector supplying power to the backplane.
  • Page 99: Cypress* Cy8C22545 Enclosure Management Controller

    Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS 4.2.2 Cypress* CY8C22545 Enclosure Management Controller The backplanes support enclosure management using a Cypress* CY8C22545 Programmable System-on-Chip (PSoC*) device. The CY8C22545 drives the hard drive activity/fault LED, hard drive present signal, and controls hard drive power-up during system power-on.
  • Page 100: Figure 44. 24-Port Expander Sas Connector/Drive Identification Block Diagram

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays 24-port SAS Expander 8-11 16-19 20-23 12-15 Figure 44. 24-Port Expander SAS Connector/Drive Identification Block Diagram Figure 45. Internal 36-Port SAS Expander Card 24-27...
  • Page 101 Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Each connector on the SAS expander card can be used as a “cable in” (SAS Controller to SAS Expander) or “cable out” (SAS Expander to Hot Swap Backplane) type connector. However, for contiguous drive mapping (0 –...
  • Page 102: Protocol Support

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Storage and Peripheral Drive Bays 4.3.1 Protocol Support Each port on the expander cards support SAS devices, SATA II devices, or both using SSP, SMP, STP, and SATA II as follows: ...
  • Page 103: Low Profile Eusb Ssd Support

    Storage and Peripheral Drive Bays Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Low Profile eUSB SSD Support The system provides support for a low profile eUSB SSD storage device. A 2mm 2x5-pin connector labeled “eUSB SSD” near the rear I/O section of the server board is used to plug these small flash storage devices.
  • Page 104: Reliability And Availability

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Reliability and Availability Reliability and Availability Mean Time between Failure The following is the calculated Mean Time Between Failures (MTBF) at maximum configuration at 40C (ambient air). These values are derived using a historical failure rate and multiplied by factors for application, electrical and/or thermal stress and for device maturity.
  • Page 105 Reliability and Availability Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Server Model P4208IP4LHGC Subassembly (Server in 40C ambient air) MTBF (hours) (flrs/10^9 hrs) Totals without motherboard = 86100 11,611 Totals with motherboard = 60200 16,593 Server Model...
  • Page 106: Intel Order Number G

    Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Reliability and Availability Server Model P4304CR2LFJN Subassembly (Server in 40C ambient air) MTBF (hours) (flrs/10^9 hrs) RMM4 10,960,687 Totals without motherboard = 91800 10,893 Totals with motherboard = 61900...
  • Page 107: Environmental Limits

    Mount BA Note: Intel Corporation server boards contain a number of high-density VLSI and power delivery components that need adequate airflow to cool. Intel ensures through its own chassis development ® and testing that when Intel server building blocks are used together, the fully integrated system will meet the intended thermal requirements of these components.
  • Page 108 Intel Corporation cannot be held responsible, if components fail or the server board does not operate correctly when used outside any of its published operating or non-operating limits.
  • Page 109: Appendix A: Integration And Usage Tips

    Appendix A: Integration and Usage Tips Appendix A: Integration and Usage Tips ® This appendix provides a list of useful information that is unique to the Intel Server Chassis Union Peak Long family and should be kept in mind while integrating and configuring your server.
  • Page 110: Glossary

    Glossary Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Glossary Word/Acronym Definition Australian Communication Authority ANSI American National Standards Institute Advanced Technology Attachment Advanced Technology Extended Auto-Ranging Power supply that automatically senses and adjust itself to the proper input voltage range (110 VAC or 220 VAC).
  • Page 111 Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Glossary Word/Acronym Definition Over Current Protection Over Temperature Protection Over-current A condition in which a supply attempts to provide more output current than the amount for which it is rated. This commonly occurs if there is a „short circuit‟ condition in the load attached to the supply.
  • Page 112: Reference Documents

    Reference Documents Intel® Server System P4000IP and Intel® Workstation System P4000CR Family TPS Reference Documents See the following documents for additional information: ® ®  Intel Server Board S2600IP and Intel Workstation Board W2600CR Technical Product Specification ® ® ...

Table of Contents
