Summary of Contents for Jura Capresso Impressa 68193
- Page 1 CAPRESSO Impressa S9 One Touch Fully Automatic Coffee & Espresso Center with Clearyl Water Care System Operating Instructions and Warranty Customer Service 1-800-220-5701 Impressa S9 One Touch...
-
Page 2: Important Safeguards / Jura Capresso
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against fire, electric shock and personal injury, do not immerse cord, plugs or appliance in water or other liquids. - Page 3 Notice: This machine has a 3-prong grounded plug. To reduce the risk of electrical shock, this plug will fit in an outlet only one way. If the plug does not fit in the outlet, contact a qualified electrician. DO NOT modify the plug in any way.
-
Page 4: Drawings
FIG. 1 FIG. 1a a. Scoop b. Cleaning tablets c. Water indicator d. Clearyl filter 1. Height-Adjustable Dual Coffee Spout 2. Operating Display (Fig.2) 3. Removable Water Tank 4. Low Water Flotation Device (inside) 5. Clearyl Water Care Cartridge (Not Installed) 6. - Page 5 Operating Display C O F F E E FIG. 2 R E A D Y SELECT PRODUCT Display Dialog System 3.1 Hot Water Portion symbol ON/OFF Button 3.2 Milk Portion symbol 1-CUP Espresso Button 3.3 Selector Dial with push button 1-CUP Coffee Button 3.4 Hot Water symbol RINSE Button...
- Page 6 FIG. 5 FIG. 6 FIG. 7 FIG. 8 FIG. 9 FIG. 10 FIG. 11 FIG. 12 FIG. 13 Extension rod...
- Page 7 FIG. 14a Black fitting Milk hose FIG. 16 Frothing range Steam only DIAL no siphoning Steaming range FIG. 14b Transparent fitting Stainless steel rod FIG. 17 Siphoning with flexible hose FIG. 15 Coffee spout Milk / Steam spout FIG. 17a venting tip chrome face plate...
- Page 8 FIG. 18 FIG. 19 FIG. 20 FIG. 21 FIG. 22 FIG. 23 FIG. 24 FIG. 25...
-
Page 9: Table Of Contents
Important Safeguards / Jura Capresso ... 2 Drawings ...4-8 Important / Battery Back-up... 11 Product Warranty Registration... 11 Operating Instructions / Quick Reference Guide ... 11 Welcome to the Impressa S9 One Touch... 11 Bean-to-cup, “Crema Coffee” and Pressure Brewing ... 12 Different Coffee Drinks... - Page 10 12a. Water Hardness Monitor ... 21 12b. Changing the Water Hardness Monitor ... 22 Clearyl Water Filter Cartridge... 22 13a. Installing and Activating the Clearyl Water Cartridge ... 23 13b. Automatic Clearyl Replacement... 23 13c. Manual Clearyl Replacement ... 24 13d.
-
Page 11: Important / Battery Back-Up
IMPORTANT / BATTERY BACK-UP The Impressa S9 One Touch has an internal battery back-up for the clock functions. After plugging the S9 OT in for the first time, turn the Main Power Switch in the back of the machine on (Fig. 1b; the red indicator light in the ON/OFF button (Fig. -
Page 12: Pressure Brewing
3a. BEAN-TO-CUP / “CREMA COFFEE" / HIGH PRESSURE BREWING According to the majority of coffee experts, grinding the beans just before brewing, tamping and brewing under high pressure is the ideal extracting process for maximum flavor and aroma. Your S9 OT automatic coffee center will always produce espresso and coffee with a thick, foamy layer called "crema."... -
Page 13: Factory Settings / Options
• Never fill anything but fresh, cold clean water into the water container, except when decalcifying (chapter 17.1). • Never use mineral or carbonated water. You can use tap water, bottled water, spring water, distilled water and reverse osmosis water. •... -
Page 14: Preparing The Machine For The First Time
Factory Settings for Beverage Buttons: • All coffee buttons are set to temperature HIGH. • The hot water function is set to XHIGH. • 1-CUP Espresso button (Fig. 2,C) 2 oz./ STRONG. • 2-CUP Espresso button (Fig. 2,F) 2 oz. per cup / XSTRONG. •... -
Page 15: 6C. Turning The Machine On For The First Time
Oily Beans: Beans with an oily surface tend to stick together. This may prevent a continuous flow of beans from the bean container into the burrs. As a result the grinder does not grind enough coffee and you might get weak or no coffee at all. Stir the beans in the bean container just before grinding. -
Page 16: 8A. Turning The Machine Off / Rinsing
RINSING. The water will be caught in the drawer underneath. The rinse cycle stops by itself and the display reads: READY. You are now ready to make coffee. *Note: S9 OT can be programmed to automatically start the rinsing cycle after HEATING UP is displayed (chapter 14.7). -
Page 17: 9C. Overriding Strength And Cup Size During Brewing
Please note: You can always stop the brewing process by pressing any of the coffee buttons. 9c. OVERRIDING STRENGTH AND CUP SIZE DURING BREWING During brewing you can override the strength of the two one- cup buttons (Fig. 2, C, D) and the cup size of all four coffee buttons. -
Page 18: Auto Cappuccino System
Please note: If the Ground Coffee button (Fig. 3A,O) is pressed by mistake just press one of the coffee buttons, ENOUGH PRE-GROUND. The machine will automatically stop and return to COFFEE READY. Please note: After use of sugar coated or flavored coffee through the pre-ground coffee funnel you may experience some flavor transfer when switching back to your regular coffee. -
Page 19: 10C. Preparing One-Touch Cappuccino, Cafe Mocha And Latte
(6 to 4 o’clock). Milk will be steamed, not frothed. Turning the dial towards the 4 o’clock position increases milk temperature. Steam Only Position: When the dial points to the steam symbol (3 o'clock), the siphoning is blocked. Only steam will pass through the frotherXpress. -
Page 20: 10F. Overriding The Cappuccino Settings
"MILK PORTION" siphons milk for a programmed time and stops automatically). • Push the button inside the Selector Dial. The display shows MILK MILK PORTION. During this time hot steamed / frothed milk is created and delivered into your cup. COFFEE READY. -
Page 21: Visual Programming Of Beverage Portions
The temperature for this function can be set to LOW, NORMAL and XHIGH (chapter 14.1; example 3) You can override the WATER PORTION during the hot water release with the Rotary Dial. You can re-program the hot water portion (chapter 14.1). 11. -
Page 22: 12B. Changing The Water Hardness Monitor
One or more sections of the indicator strip will turn reddish. • Change the water hardness setting according to the table below. Level Display Not Active* INACTIVE 1. extremely soft water 2. soft water 3. medium water 4. hard water 5. -
Page 23: Installing And Activating The Clearyl Water Cartridge
13a. INSTALLING & ACTIVATING THE CLEARYL WATER CARTRIDGE Installing: Important: Never install the cartridge before or during "Preparing Machine For The First Time" (chapter 6). • Remove cartridge from its bag and rinse cartridge under water. • Add the extension rod to the cartridge (Fig. 11). •... -
Page 24: 13C. Manual Clearyl Replacement
13c. MANUAL CLEARYL REPLACEMENT If the filter is more than 2 months old and the display does not indicate to replace filter, replace as follows. COFFEE READY. • Push the Rotary Dial until the display shows MAINTENANCE. • Push Rotary Dial again, display shows •... -
Page 25: Products
Temperature: for all coffee drinks the temperature can be set to NORMAL HIGH MILK PORTION: steaming can be set from 3 to 120 seconds. PAUSE: the pause time between milk production and coffee brewing for the one-touch Cappuccino and Latte Macchiato buttons can be set from 0 to 60 seconds. -
Page 26: Restoring Factory Settings For Beverage Buttons
9. Turn the Rotary Dial until the display shows 10. Push the dial, MILK 14 SEC, and turn the dial until the display shows MILK 20 SEC. 11. Push the Rotary Dial to confirm: CONFIRMED MILK 20 SEC. 12. Push the Rotary Dial until the display shows 13. -
Page 27: Actual Time And Weekday
If the machine is primarily used for coffee this setting saves energy. The heating element for steam (milk frothing) will shut off after approx. 10 minutes after last use. At this time the white indicator lights in the cappuccino and latte macchiato buttons turn off. -
Page 28: Auto-Off
Example: Set the On-time to 6:15 AM and program the S9OT not to turn on automatically on Sundays. COFFEE READY • Push the Rotary Dial until the display shows MAINTENANCE. • Turn the Dial until the display shows • Push the Dial UNIT ON --.--, push again •... -
Page 29: Information
CAUTION / WARNING In the setting INIT RINSE AUTO the machine will automatically dispense hot water through the Dual Coffee Spouts. Please keep children and pets away! Cappuccino rinse cycle (CAPP RINSE) The S9 OT is factory-set to immediately remind you to run a rinse cycle after milk use (chapter 10g). -
Page 30: Manual Maintenance Cycles
can resume brewing coffee. Make sure the Dual Coffee Spouts are moved upwards. Carefully lift and pull out the removable drawer (Fig. 18 and 19). MISSING. There is water in the drawer. Empty the drawer and the used coffee container, assemble and replace. Make sure the two metal contacts of the drawer are clean and dry. -
Page 31: Removing Stones Etc. From The Burr Grinder
If you push the Rotary Dial to enter one of the above programs, the display guides you through the necessary steps. Please note: If the display shows MAINTENANCE not select one of the above programs within five seconds, the S9 OT will return to COFFEE READY. -
Page 32: Automatic Cleaning Cycles
If you use the frothXpress extensively or forgot to clean it, milk fat starts building up inside the frothXpress. In this case use the Cappuccino Cleaner liquid in the Welcome Pack. Run a CLEAN CAPPUCCINO cycle as follows: COFFEE READY. •... -
Page 33: Manual Tablet Cleaning
exit the program. In this case the S9 OT will remind you with the message CLEAN MACHINE. 2. Make sure that the water container is at least half full. 3. Push the Rinse Button. EMPTY TRAY. 4. Remove and empty the tray and the used coffee container and replace. -
Page 34: Decalcifying Procedure
17.1 DECALCIFYING PROCEDURE COFFEE READY / DECALCIFY MACHINE 1. Push the Rinse button until display shows DURATION 45 MIN. / START YES. Please note: To start at a later time, turn the Rotary Dial to START NO and push the Rotary Dial. The machine will still display COFFEE READY / DECALCIFY 2. -
Page 35: Tips For Better Coffee
18. TIPS FOR BETTER COFFEE Height adjustable coffee-spout Adjust the height of the coffee-spout to the size of your cups. Grinding Please refer to chapter 7 "Adjusting the Grinder." Pre-warm cups Pre-warm cups in advance with hot water (chapter 9a). Sugar and cream Warmth is lost by stirring the contents of the cup. -
Page 36: Supplies
B. THE DISPLAY READS "FILL WATER ENOUGH WATER IN THE WATER TANK. Reason: The floatation device (Fig.1,4) is stuck or missing. Solution: Clean the water container and make sure the floatation device moves freely. Solution: Within the water tank is a small compartment (like a mouse trap). -
Page 37: Limited Two-Year Warranty
• Special Cleaning Tablets (two included) Model #62205. Tip: If you brew 10 cups a day you need about one tablet every 3 weeks. Always keep extra tablets available. • Auto-Cappuccino Cleaner (one bottle included). Model #63801 Tip: If you use the auto cappuccino cleaner every other day you need a new bottle every 5 weeks. -
Page 38: Free Repair Service / Extra Repair Coverage
set forth above and no person is authorized to assume for JURA-CAPRESSO any other liability in connection with the sale of the machine. JURA-CAPRESSO expressly disclaims liability for incidental and consequential damages caused by the machine. The terms "incidental damages" refer to the loss of the original purchasers time, loss of the use of the machine or other costs relating to the care and custody of the machine. - Page 39 Jura-Capresso Inc. 81 Ruckman Road, Closter, NJ 07624 201-767-3999 • Fax: 201-767-9684 Customer Service: 1-800-220-5701 Email: contact@capresso.com • Website: www.capresso.com...
