Technical Data; Gsx Limited - Sea-doo GSX Limited Shop Manual

GSX LIMITED

ENGINE
Engine type
Induction type
Exhaust system
Exhaust valve
Starting system
Lubrication
Number of cylinders
Bore
Stroke
Displacement
Corrected compression ratio
Cylinder head warpage (maximum)
Piston ring type and quantity
Ring end gap
Ring piston groove
Piston/cylinder wall
clearance
Cylinder taper (maximum)
Cylinder out of round (maximum)
Connecting rod big end axial
play
Crankshaft deflection
Connecting rod/crankshaft
pin radial clearance
Connecting rod/piston pin
radial clearance
ADDITIONAL INFORMATION:
Type
Water injection fitting (head)
Water injection fitting (cone)
Water injection fitting
(muffler)
Fuel/oil mixture
Oil injection pump
Oil type
Standard
First oversize
Second oversize
New
Wear limit
New
Wear limit
New (minimum)
Wear limit
New
Wear limit
New
Wear limit
New
Wear limit
www.SeaDooManuals.net
Section 06 TECHNICAL DATA
Subsection 01 (GSX LIMITED)
GSX Limited (5625)
Bombardier-Rotax 947
Reed valve
Water cooled, water injected with regulator
3.5 mm (.139 in)
N.A.
3.5 mm (.139 in)
Rotax Adjustable Variable Exhaust (RAVE)
Electric start
VROI (Variable Rate Oil Injection)
Direct driven
BOMBARDIER-ROTAX FORMULA XP-S
Synthetic injection oil (or equivalent synthetic oil)
88 mm (3.465 in)
88.25 mm (3.474 in)
N.A.
78.20 mm (3.079 in)
951.2 cm³ (58 in³)
6.0: 1
N.A.
2 Semi-trapez
0.25 - 0.40 mm (.010 - .016 in)
1.00 mm (.039 in)
0.025 - 0.070 mm (.001 - .003 in)
0.2 mm (.008 in)
0.110 mm (.0043 in)
0.200 mm (.008 in)
0.100 mm (.004 in)
0.080 mm (.003 in)
0.311 - 0.678 mm (.012 - .027 in)
1.2 mm (.047 in)
MAG side: 0.050 mm (.002 in); PTO side: 0.030 mm (.001 in)
0.017 - 0.034 mm (.0007 - .0013 in)
0.050 mm (.002 in)
0.003 - 0.012 mm (.00012 - .00047 in)
0.015 mm (.00059 in)
0
2
06-01-1
