9. Final Drive Mechanism

Operational Precautions

Specification
Application gear oil: GEAR OIL SAE 85W-140
Recommended oil: KING MATE serial gear oils
Oil quantity:
HU10U/W 110 c.c. (100 c.c. when replacing)
HU05U 100 c.c. (90 c.c. when replacing)
Torque value
Gear box cover
Gear oil drain plug
Gear oil filling bolt
Special service tools
Inner type bearing puller
Outer type bearing puller
Gear box oil seal installer
Gear box bearing installer
Bearing (6204) installer
Bearing (6301) installer
Bearing (6203/6004UZ) installer
Drive shaft puller
Puller set

Trouble Diagnosis

Engine can be started but motorcycle can not be moved.
Damaged drive gear.
Burnt out drive gear.
Broken drive belt.
Noise
Worn or burnt gear.
Worn gear.
Gear oil leaks
Excessive gear oil.
Worn or damage oil seal.
9-2
To this chapter contents
2.0~2.4kgf-m
1.0~1.4kgf-m
0.8~1.2kgf-m
SYM-6204002
SYM-6204001
SYM-9120200
SYM-9125500
SYM-9110400
SYM-9610000
SYM-9620000
SYM-13000
SYM-13000-01
