SummaCut User' s Manual

2.2.11 LOAD

WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
The LOAD instruction is used to initiate a load sequence. Press the key to
execute. The origin can be changed first if necessary. Press the or jogging
key to change the origin in the Y-direction. Press the or jogging key to
change the origin in the x-direction. Press the key to confirm. Then the media
window can be changed. Press the or jogging key to change the length of
the window or press the key to change the value of the length of the media
window. The or jogging key change the value in steps of 100mm, the or
jogging key change it in steps of 10mm (When the machine is set up in English
units, the step sizes are respectively 0.5" and 2.5"). Then press the key to finish
the load procedure.

2.2.12 ALIGN LOAD

The Align load sub menu is used for contour cutting. Refer to section 3 for the complete
explanation on contour cutting. Section 2.3.11 explains how to change the align
method. Press the key to execute.

2.2.13 SYSTEM SETUP

The SYSTEM SETUP submenu covers the menu items you normally only need when
establishing the initial set-up e.g. when you install the cutter in combination with the
software you use.
Press the confirmation key to access the different submenu items, which are explained
in section 2.3.
Operation 2-8
