SYSTEM STATUS
SCREEN 1:
S
STATUS:
t
a
DEMAND CHANNEL 1 0%
t
u
DEMAND CHANNEL 2 0%
s
CAPACITY LIMIT
:
Displays the present status of the system.
Depending on system activity at the time, the field
could display: lockout (security loop open), active (unit
generating steam) or standby (security loop closed but
no modulation demand signal).
Demand channel 1:
This field will display the modulation demand input
on that channel.
Demand channel 2:
Field only visible if the unit is configured for dual
modulation. This field will display the modulation
demand input on that channel.
Capacity limit:
This field displays the user adjusted capacity limit
set for the humidifier.
SCREEN 2:
System demand:
SYSTEM DEMAND XXX%
BURNERS ACTIVE X/X
OUTPUT/BURNER
TOTAL OUTPUT
This field displays the total system demand as a
percentage.
Burners active:
This field displays the number of active burners
and the number of available burners.
LOCKOUT
0%
XXXLB
XXXLB
Output/Burner:
This field will display the actual output of steam
generated by each burner (kg/hr or lbs/hr).
Total output:
This field will display the total system steam output
(kg/hr or lbs/hr).
SCREEN 3:
W
at
WATER LEVEL:
er
le
FILL VALVE
v
DRAIN VALVE
el
:
DRAIN COOLING: SMART
This field displays the present water level detected
by the float system.
Fill valve:
This field displays status of fill valve, on, off, or
pulsed.
Drain valve:
This field displays status of drain pump, on or off.
Drain cooling:
This field displays the user (or factory default)
setting.
OFF: fill will not activate when drain is activated.
ON: fill will activate whenever the drain activates.
SMART: fill will activate only when drain water is
hot.
