OPERATING INSTRUCTIONS

The IMPRES Adaptive Charger System is a fully automated battery
care system. All a user needs to do is follow these simple steps:
1. Place the radio / IMPRES battery into the charger.
2. Remove the radio / IMPRES battery when it's fully charged (LED
turns steady GREEN).
The charger pockets accommodate either a radio with an IMPRES
battery attached or an IMPRES battery alone. Prior to charging a
radio with an IMPRES battery, turn the radio off. Batteries charge
best at room temperature.

Charging Procedure

1. Plug the charger end of the power supply cord into the power
receptacle located at the back of the charger.
2. Plug the wall receptacle end of the power supply cord into the
appropriate AC outlet. A successful power-up sequence is
indicated by a SINGLE FLASH GREEN on the charger indicator.
3. Insert an IMPRES battery, or a radio with an IMPRES battery (with
the radio turned off), into the charger's pocket by:
a. Aligning the groove on each side of the battery with the
corresponding raised rail on each side of the charger pocket.
b. Pressing the battery toward the rear of the pocket.
c. Sliding the battery into the charger pocket, ensuring complete
contact between the charger and battery contacts.
4. To remove a radio or IMPRES battery from the charger, use two
hands to remove a radio or battery from the charger pocket - one
hand to hold and support the charger, and the other hand to remove
the radio or battery.
