OSD (On Screen Display) Operation
Port Channel
Address
Highlighted by
arrow keys
Security
enabled port
White indicates
power off
Green indicates
power on
By hitting the left <CTRL> key twice within two seconds, you may see the 'Hotkey
Menu' if it is enabled (an OSD option). Or, by hitting the left <CTRL> key three
times within two seconds, you will see a 'KVM MENU' screen displaying a list of the
computers with corresponding channel addresses, names and status.
Instruction Manual
6
Currently
selected channel
address
To a 16-port
Slave
To an 8-port
Slave
Eye mark
enabled
Master port
name (group
name)
User-input port
names
Eye mark enabled
