Installation
WARNING: Prior to installation, please ensure that all computers and KVM switch(es)
are powered down.
Console Connection
The SV831DUSBAU is designed for use with USB console connections only. A USB
compatible keyboard and mouse and VGA monitor must be used for the local console.
A USB keyboard/mouse combo device that uses a single USB connector may also
be used, but must be connected to the USB Keyboard port only. If using audio,
separately connect the 3.5mm mini-jack cables for the speaker and microphone to the
corresponding Console connectors indicated.
Microphone
Speakers
VGA
Monitor
USB
USB
mouse
keyboard
Instruction Manual
2
