Connecting the Monitor, Keyboard, and Mouse
!
007-4275-001ML
Connect the monitor, keyboard, mouse, and other external devices to their appropriate
ports.
Caution: Before connecting external devices, make sure the server is not plugged in, or
equipment could be damaged.
A B
M
L K
I G
J H
Rear Panel I/O Ports and Features
Figure 1
Rear panel I/O ports and features are indicated in Figure 1, as follows:
A. AC input power connector
B. Optional external SCSI connector ports
C. Hot-plug 64-bit, 33 MHz PCI add-in board slots
D. Hot-plug 64-bit, 66/33 MHz PCI add-in board slots
E. Non-hot-plug 32-bit, 33 MHz PCI add-in board slots
These slots can also accept an optional Intelligent Chassis Management Bus (ICMB)
SEMCONN 6-pin connector in/out, port 1
F. Video connector
Connecting the Monitor, Keyboard, and Mouse
F E D
O
N
C
