Periodic inspection

Hoses check
Make sure the connecting hoses (Fig. 9) are in a good condition and attached correctly.
If the hoses are damaged, broken or poorly connected, they must be replaced.
When sticky materials are collected, check for possible clogging along the hose, in the inlet and on the baffle plate inside the
filtering chamber.
Scrape inlet (2, Fig. 9) from the outside and remove the deposited waste as indicated in the figure.
Check the main filter (and HEPA, if equipped) periodically for clogging and signs of damage (i.e. torn material, damaged
gaskets, etc.). Replace any damaged filters before returning the machine to service.
Filtering chamber leak check
If gasket (1, Fig. 10) between container (4) and filter chamber (3) fails to guarantee a good seal:
■ Loosen the four screws (2) that lock the filtering chamber (3) against the vacuum cleaner structure.
■ Allow the filtering chamber (3) to lower down and tighten the screws (2).
If an optimal seal cannot be obtained and the gasket is torn or cracked, etc. it must be replaced.

Disposing of the vacuum cleaner

Dispose of the vacuum cleaner in compliance with the laws in force.
To prevent damage to the environment or health caused by improper waste disposal, please separate this product from other
waste and recycle it responsibly in order to support the sustainable reutilisation of material resources.
This product can not be disposed of together with other commercial waste.

Recommended spare parts

The following is a list of spare parts that should be kept ready at hand in order to speed up maintenance operations.
Refer to the manufacturer's spare parts catalogue when ordering spare parts.
04/2012
Figure 11
Description
Star filter kit
Filter ring gasket
Filter chamber gasket
Filter clamp
HEPA filter
11
VHC200 / VHC200EXP
Model
VHC200 VHC200EXP
40000338 40000425
8-17026 8-17126
40000762
8-18079
4081700935
