Page 1: Installation Instructions
Installation Instructions Home Laundry Automatic Clothes Washers D311IE3A Keep These Instructions for Future Reference. (If the washer changes ownership, be sure this manual accompanies the washer.) Part No. 38910 September 1999... -
Page 3: Table Of Contents
© Copyright 1999, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. -
Page 4: Roughing In Dimensions
Roughing In Dimensions 71,1 cm (28") 10,2 mm (0,4") 66,0 cm (26") W519IE3A 65,0 cm (25,6") *WITH LEVELING LEGS TURNED INTO BASE Before You Start Tools Electrical For most installations, the basic tools you will need are: Refer to Serial Plate for specific electrical requirements. -
Page 5: Installing The Washer
Installing the Washer Step 1: Remove the Shipping Brace and Shipping Plug NOTE: Install dryer before washer. This allows room for attaching exhaust duct. Remove the shipping brace from under the lid. The plastic shipping plug will be released from the base of the washer when removing the cardboard base from the washer. -
Page 6: Step 3 Connect Water Inlet Hoses
Installing the Washer Step 3: FILTER WASHER Connect Water Inlet Hoses (Screen must be facing outward) NOTE: Refer to Section on Water Supply Requirements before connecting water inlet hoses. Remove the two screened filter washers and the two RUBBER WASHER (Plain) plain rubber washers from accessories bag, and install them according to the illustration. -
Page 7: Step 4 Connect Drain Hose To Drain Receptacle
Installing the Washer Step 4: STANDPIPE ADAPTER Connect Drain Hose to Drain Receptacle RETAINER CLAMP Remove the drain hose from its shipping position on the rear of the washer by unhooking the hose from the retainer clamp. Find the instructions, on the following pages, that are appropriate for your type of drain receptacle (standpipe, high standpipe, low standpipe, sink, wall, or laundry tub). - Page 8 High Standpipe Installation: STANDPIPE Place the adapter into the standpipe. Remove the ADAPTER DRAIN beaded tie-down strap from accessories bag and place HOSE around standpipe and drain hose, approximately 30 cm (12 inches) down from the top of pipe and tighten strap to hold hose to standpipe.
- Page 9 Installing the Washer Sink Installation: TIE-DOWN STRAP OR WIRE TIE For this type of installation, use the beaded tie-down DRAIN HOSE strap (supplied in accessories bag), or use a large wire tie (available from your local hardware store) and secure the drain hose to the cabinet top hinge. See illustration.
-
Page 10: Step 5 Position And Level The Washer
Installing the Washer Step 5: Position and Level the Washer Place rubber feet on all four leveling legs. LEVEL Place washer in position on a clean, dry, and reasonably firm floor. Installing the washer on any type of carpeting is not recommended. Loosen 7/8"... -
Page 11: Step 7 Add Water To The Washer
Installing the Washer Step 7: Add Water to the Washer To prevent damage to pump, do not run washer before adding at least one quart water to the tub. If the washer is run before any water is added, the pump seal may overheat causing the pump to leak. -
Page 12: Electrical Requirements
Electrical Requirements (240 Volt, 50 Hertz with 3-Prong Grounding Plug) Earthing Instructions NOTE: The wiring diagram is located in the control hood. The washer must be earthed. In the event of malfunction or breakdown, earthing will reduce the risk of electric shock by providing a path of least WARNING resistance for electric current. -
Page 13: Water Supply Requirements
Water Supply Requirements Water Temperature WARNING Cold: Under certain conditions, hydrogen gas Recommended cold water temperature is 10° to 24° may be produced in a hot water system that Celsius, 50° to 75° Fahrenheit. has not been used for two weeks or more. Hot: HYDROGEN GAS IS EXPLOSIVE. -
Page 14: Water Pressure
Water Supply Requirements Water Pressure Risers Pressure must be a minimum of 138 to a maximum of Risers (or air cushions) may have to be installed if the 827 kPa per square inch (20 to 120 pounds per square pipes knock or pound when flow of water stops. The inch) static pressure measured at the faucet. -
Page 15: Installer Checklist
Installer Checklist Fast Track for Installing the Washer (Refer to the manual for more detailed information) • Remove • Position and LEVEL Level the the Shipping D255IE0A Brace and Washer. Shipping Plug. CHECK CHECK W405IE0A W316IE0A • Plug In the •...
