Alliance Laundry Systems EA2011*A3000 Service Manual

Commercial washers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Commercial
Washers
Refer to Page 5 for Model Numbers
W247PE1A
Part No. 37951R1
www.comlaundry.com
June 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EA2011*A3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems EA2011*A3000

Summary of Contents for Alliance Laundry Systems EA2011*A3000

  • Page 1 Commercial Washers Refer to Page 5 for Model Numbers W247PE1A Part No. 37951R1 www.comlaundry.com June 2005...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 4 Timer No. 35368 Cycle Sequence (Short Cycle) ............88 Section 8 – Internal Wiring of Washer Motor Switch Motor Assembly (1 Speed Motors) .......89 Motor Assembly (2 Speed Motors) .......90 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 5: Section 1 - Safety Information

    • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the product is properly grounded and to reduce the risk of fire, electric shock, serious injury or death. W006R2 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 6: Locating An Authorized Servicer

    Locating an Authorized Servicer Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs. Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician and using authorized factory parts.

  • Page 7: Section 2 - Introduction

    EA2211*A1300 EA2211*A3000 EA2211*A3066 EA2921*A3000 EA2921*A3050 EA2921*A3059 GA2210*A1102 ZA2021*A1102 ZA2111*A1102 ZA2111*A3059 ZA2121*A1102 ZA2210*A1102 ZA2221*A1102 ZA2921*A1102 ZA2921*A3059 * Add Letter To Designate Color. L – Almond W – White 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 8: Customer Service

    Model and serial numbers are located on nameplate(s) as shown. Nameplate NOTE: Coin slide and coin drawer shown for illustration purposes only. W233SE3B © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 9: Section 3 - Troubleshooting

    Refer to appropriate wiring diagram. 3. NO WARM WATER POSSIBLE CAUSE TO CORRECT No hot water. Refer to Paragraph 1. No cold water. Refer to Paragraph 2. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 10: Water Fill Does Not Stop At Proper Level

    Timer is designed to pause when going from spin into rinse to allow the washtub to stop spinning before filling. Make sure that timer has advanced into fill portion of rinse cycle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 11: Motor Does Not Run

    Refer to Paragraph 12. Bind in pump. Replace pump. Loading door is open or door switch is inoperative. Close loading door or test switch and replace if inoperative. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 12: Constant Agitation

    Check that all these components are able to move freely. will not turn. Correct binding component. Incorrect voltage. Contact local utility company, or have a qualified electrician check power supply. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 13: Slow Spin Or No Spin

    Excessive wear on brake pads, or missing brake Replace brake pads. pads. Shorted or incorrect wiring. Refer to appropriate wiring diagram. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 14: Washer Stops In Cycle; Quits After A Couple Loads; Is Intermittent

    Drain hose out of clamp in back of cabinet. Remove washer front panel and install drain hose into clamp. Inoperative water pump. Replace pump. Obstruction in outer tub outlet hose. Remove obstruction. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 15: Excessive Vibration

    Outer tub cover gasket leaking. Replace gasket. Obstruction in drain causing water to come over top Remove obstruction. of outer drain tub cover. Tub-to-pump hose leaking at clamp. Tighten clamp. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 16: Troubleshooting Coin Drop

    IMPORTANT: Do not bend or damage mechanical parts within coin drop. Additional coins following path to sensor Coin in Coin Slot Coin Drop Sensor DRY2B Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 17 Refer to Adjustments prevent coins from section for instructions following through on cleaning drop. required check stages of drop.) Replace coin drop TLW302S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 18 Section 3 Troubleshooting Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 19: Troubleshooting Electronic Control

    Damaged terminals in the harness connector will appear burnt or show signs of heat discoloration on the connector block. Replace the control wire harness with the control to avoid repeated damage. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 20: Cannot Perform Infrared Communication

    Check the following: – (IR) disabled by manual prog. – Is the (IR) on the control covered or blocked? – If needed, change electronic W367S control board. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 21: Coins Ignored When Entered

    Retest again, if not successful run test again. run test again. the following is the problem: – Replace coin drop. If the problem still exists: – Replace electronic control. W368S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 22: Electronic Control Has No Visible Display

    "FS2" the electrical outlet to the electronic control. white? NOTE: This voltage check confirms that main power is present to the control. Replace electronic control. W369S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 23 Troubleshooting Electronic Control Notes 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 24: No Fill Analysis

    On mixing valve check and replace: – Inlet screens. – Wiring and connections. – Replace coils or mixing valve. – Check thermal protect and wiring W370S from thermal protect to "H3-3" © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 25 H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR TLW314S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 26: No Motor Run - Agitate Analysis

    BLU "H3-4" to "H3-2" refer to Section 7 RED "H3-6" to BRN or Paragraph 6. "H3-2" is there voltage? Replace electronic control board. W372S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 27 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR TLW315S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 28: No Motor Run - Spin Analysis

    BLU "H3-4" to "H3-6" refer to Section 7 BRN "H3-2" to "H3-6", or Paragraph 6. is there voltage? Replace electronic control board. W374S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 29 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR TLW316S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 30: Overflow Analysis

    If this happens, replace the mixing valve. Check for a locked open mixing valve. W376S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 31: Electronic Control

    H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR TLW317S 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 32: Audit Switch Function Analysis

    – Machine/cycle var reports. Check for proper wiring and connections. After wiring has been confirmed correct, replace electronic control board. D216S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 33: Section 4 - Grounding

    28. POWER CORD TO CONTROL HOOD, CONTROL HOOD TO THE CONTROL PANEL FRAME. Refer to Figure 3. Ground Ground Wires Wires Ground Ground W285SE3A W285SE3A Wires Wires Figure 3 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 34: Control Hood Wire Harness To Top Left Rear Corner Gusset Of Cabinet

    Gusset Ground Screw Ground Wires W340S Figure 4 30. WIRE HARNESS TO MOTOR Refer to Figure 5. Earth (Ground) Wires Wire Harness Connection Block W329SE3A Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 35: Section 5 - Service Procedures

    NOTE: Refer to appropriate wiring diagram when reconnecting wire harnesses, ground and switch leads. W284SE1A Figure 6 Disconnect Blocks Pressure Ground Ground Disconnect Switch Wires Wires Blocks Indicator Light W285SE3B Figure 7 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 36 (3) Pull switch out of control hood far enough W235SE1A to disconnect pressure hose and wires from Figure 8 switch. NOTE: Refer to appropriate wiring diagram when rewiring pressure switch. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 37: Timer Assembly

    (located on each side of terminal block plug). Refer to Figure 10. Then pull terminal block plug away from timer. (5) Disconnect ground wire from terminal on timer. Refer to Figure 10. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 38 Refer to Figure 11. with any moving parts in meter case. c. TIMER REMOVAL (Nonmetered Models): (1) Loosen two setscrews holding timer knob to timer shaft. Refer to Figure 12. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 39: Dual Coin Drop

    (7) Use a 7/16 inch socket with No. 310P4 1/4 inch Ratchet Extension Tool and remove two locknuts holding coin drop to front of meter case. Refer to Figure 14. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 40 (2) Carefully pull front of coin drop up and Coin Drawer forward, so the drop’s front face plate Housing W410SE3A clears the meter case’s door switch bracket. Refer to Figure 19. Figure 15 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 41 Case W413SE1A Coin-Return Stops Figure 18 W415SE1A Figure 20 (3) Rest the two coin-return stops on top of the coin drawer housing, as shown in Figure 20. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 42: Meter Or Timer Case Assembly

    Refer to Figure 13. (7) Remove front panel assembly. Refer to (11) Reinstall multiplier and reconnect wires. Paragraph 37. Refer to Figure 14. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 43: Drain Hose Elbow

    Elbow top. Attaching Screws Hose Drain Clamp W242SE1A Hose Timer Figure 24 Case Screw Timer Case Attaching Hardware W240SE1A Figure 23 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 44: Loading Door

    Remove brace from front panel by Loading swinging one end toward bottom of front panel Door and remove brace. Hinge Attaching Screws Right Left Hinge Hinge W287SE1A Figure 25 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 45 Section 5 Service Procedures Procedure One Door Front W288SE3A Procedure Two Door Front W289SE3A Procedure Three Door Front W290SE3A Figure 26 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 46: Motor And Mounting Bracket

    Belt MUST encircle rear pump leg when reassembling. Refer to Figure 30. IMPORTANT: Use care when releasing idler lever tension. If idler spring is overstretched, washer operation will be affected. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 47 Running a pump Drive Idler without water will ruin its seals. Belt Spring Hose Clamps W305SE1A Figure 28 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 48: Idler Lever And Pulley

    Figure 28. the out-of-balance switch. This condition will persist until lubricant is removed. Switch Attaching Screw Locking Motor Mount Motor Connection Attaching Screws Switch Block W333SE3A Figure 29 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 49: Motor Drive Pulley

    Lay motor assembly on its side. NOTE: To remove pulley, support motor shaft (to prevent bending shaft) and drive out pulley roll pin. Refer to Figure 31. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 50 Pump Legs Motor Motor Embosses Shaft (Clean shaft and apply a thin film of lubricant, No. 03637P) Motor Emboss Motor Assembly W272SE3A Figure 30 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 51 Motor Mount Post Shoulder Bolt Locknut Idler Spring Idler Clip Shaft Belt Washer (Agitate and (Felt) Spin) Washer (Nylatron) Pump Retainer Assembly Ring Screw W263PE3C Figure 31 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 52: Motor Switch

    Refer to Figure 29. f. Disconnect internal motor leads from motor switch terminals. NOTE: Refer to Wiring Schematics, SECTION 8 for rewiring internal switch wires. Agitator W247SE1A Figure 32 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 53: Cabinet Top Assembly

    NOTE: Cabinet top is self supporting, however, a W252SE1A small chain may be used for additional support. Refer to Figure 33. Figure 33 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 54: Cabinet Top Assembly Removal

    Refer to forward far enough to prevent damaging (bending) out-of-balance switch lever. Corner Pressure Gusset Hose Ground Wire Mixing Valve Wire Harness Disconnect Blocks W342S Figure 34 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 55: Agitator Drive Bell And Seal Kit

    W293SE1A with wide slots on drive bell. Tighten wing nuts Figure 37 on tool to hold jaws firmly against drive bell. Refer to Figure 36. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 56 No. 293P4 IMPORTANT: DO NOT allow any lubricants to Seal Tool. Refer to Figure 40. come in contact with outside surface of seal. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 57 Place No. 294P4 Bell Tool over top of drive bell. Screw bolt into transmission output shaft until it bottoms out. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 58: Out-Of-Balance Switch Assembly

    Place switch assembly into switch holder. Refer to Figure 42. i. Tighten screws using an open-end wrench. Push Cabinet Here Switch Lever W171SE1A Figure 43 Screws W273SE1B Figure 42 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 59: Mixing Valve Assembly

    Refer to Figure 44. NOTE: Refer to appropriate wiring diagram when rewiring solenoid. Wire Harness Disconnect Hose Terminals Clamp W322SE1A Figure 44 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 60: Outer Tub Cover And Clothes Guard

    Refer to Figure 45. remove cover. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 61 Part No. 273P4. Tub Cover Gasket 273P4 Tub Cover Tool Press Gasket Into Groove Using Your Fingers Hold-Down Hold-Down Tabs Tabs W208SE3B Figure 46 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 62 W255SE3A cover off tub flange. Figure 47 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 63 Then carefully push clothes guard down into washtub until all pins snap into their respective holes. Slots Washtub Screws Clothes Washtub Guard Screws Pins W209SE3A Figure 48 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 64: Hub And Seal Kit, No. 495P3A

    Thoroughly clean all foreign material from edge of water seal and tub (area located just inner surface of outer tub flange. below garter spring). Refer to Figure 50. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 65 Apply Bead of No. 27615P No. 27615P Sealant (3M800) Here Insert Sleeve From Sealant (3M800) Here (Step “f”) Bottom Side of Seal (Step “f”) W180SE3B Figure 50 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 66: Outer Tub Assembly

    Refer to Figure 51. hooked to motor mounting bracket. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 67 Pivot Dome Attaching Brake Screws Assembly Pivot Dome Lower Bearing Housing Drive Pulley Transmission Assembly Plate Screw Balance Ring W257SE3A Figure 52 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 68: Drive Pulley And Helix

    This condition will persist until lubricant is removed. Drive Pulley Washer Cap Screw Helix W271SE3A Figure 53 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 69 Apply Lubricant Here Drive Pulley Apply Lubricant Here Washer Helix Cap Screw Pivot Dome DO NOT LUBRICATE Washer Base Snubber Pad and Isolator Assembly W183SE3A Figure 54 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 70: Brake Assembly

    IMPORTANT: When installing brake spring (if present), make sure it is inserted into groove in large splines of lower transmission tube. Use tool, No. 242P4, for installing spring. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 71: Lower Bearing Housing

    IMPORTANT: When installing lower bearing housing, pivot dome and brake assembly, apply No. 27604P Anti-Seize Compound to area of transmission tube that will be contacting bearing. Refer to Figure 55. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 72 *NOTE: If there is no mark on balance ring before disassembly, mark it and also note the position of rack on transmission assembly. Refer to Figure 55. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 73 NOTE: Put a light film of transmission oil in slot on is bad, it will require replacing complete rack, also, transmission case where internal gear transmission cover assembly. Individual will ride. components are not available separately. 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 74 Both transmission pin tools must be left in place until all eight screws and nuts have been installed and tightened firmly. Then remove the two pins. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...
  • Page 75 Pinion (Through Serial No. 9604069377) Rack Slide Transmission Cover Assembly Screw Dowel Pin (Through Serial W186SE3A No. 9604069377) Sealant (Use between Transmission Case and Cover Figure 56 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 76: Balance Ring

    Ball Bearing Cap Screw Outer Upper Bearing Flinger Housing (If Present) Upper Flinger Bearing (If Present) Housing W196SE3A Figure 57 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 77: Snubber Pad And Isolator Assembly

    (not kinked or twisted). If it is not, loosen hose recess of washer base. clamp and straighten hose. Starting Edge Isolator Strip Elongated Hole Dome Area of Washer Base W220SE3C Figure 58 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 78 NOTE: Washer must be run through a complete k. Reinstall washer front panel. cycle to make sure it is operating properly. Pressure Hose W366S Tape Pressure Bulb Figure 59 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 79: Section 6 - Adjustments

    Washer Base Locknut Leveling Rubber Foot Front Panel Screws W286SE3A Figure 60 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 80: Pressure Switch

    60. OUT-OF-BALANCE SWITCH a. Raise cabinet top assembly. Refer to Paragraph b. Check for bent actuator arm or lever. Refer to Centering Figure 62. Spring W308SE1B Figure 63 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 81: Belt (Agitate And Spin)

    Figure 64. Save pin for reinstallation when Cotton cleaning is complete. Swab f. Move metal clip closer to sensor so that it DRY5B comes off frame. Refer to Figure 64. Figure 66 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 82 NOTE: If coin drop does not operate properly after above steps have been completed, corrosion of metal or vandalized components within coin drop may be preventing the coin drop from functioning correctly. Replace coin drop. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 83: Section 7 - Cycle Sequence Charts

    X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 28716 CYCLE SEQUENCE (LONG CYCLE – KINGSTON) 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 84: Timer No. 28719 Cycle Sequence

    D = DELICATE CYCLE C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 28719 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 85: Timer No. 31111P Cycle Sequence (Short Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 31111P CYCLE SEQUENCE (SHORT CYCLE) 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 86: Timer No. 31504 Cycle Sequence (Short Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 31504 CYCLE SEQUENCE (SHORT CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 87: Timer No. 34601P Cycle Sequence

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34601P CYCLE SEQUENCE (LONG CYCLE) 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 88: Timer No. 34603 Cycle Sequence (Long Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34603 CYCLE SEQUENCE (LONG CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 89: Timer No. 34604 Cycle Sequence

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34604 CYCLE SEQUENCE (LONG CYCLE) 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 90: Timer No. 35368 Cycle Sequence (Short Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 35368 CYCLE SEQUENCE (SHORT CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

  • Page 91: Section 8 - Internal Wiring Of Washer Motor Switch

    W003 White Brown Blue Yellow W310SE3A 4P M YELLOW OVERLOAD PROTECTOR AUX. W211SE3A MOTOR ASSEMBLY (1 Speed Motors) 37951 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 92: Motor Assembly (2 Speed Motors)

    W003 Wire Harness Connection Block White Blue Brown Violet Yellow W311SE3B 4P M YELLOW 6P M OVERLOAD PROTECTOR AUX. W224SE3A MOTOR ASSEMBLY (2 Speed Motors) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37951...

This manual is also suitable for:

Ea2011*a3050Ea2111*a3000Ea2111*a5400Ea2111*a5412Ea2111*a5417Ea2211*a1200 ... Show all

Table of Contents
