  • Page 1 Automatic Washers Refer to Page 5 for Model Numbers W138P Part No. 36007R2 www.comlaundry.com July 2005...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 4 81. Symptom: Washer Will Not Fill or Wrong Temperature Fill ..........97 82. Symptom: Washer Will Not Agitate Properly ............98 83. Symptom: Washer Will Not Spin Properly ..99 84. Control Replacement ........100 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 5: Section 1 - Safety Information

    • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the product is properly grounded and to reduce the risk of fire, electric shock, serious injury or death. W006R2 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 6: Locating An Authorized Servicer

    Locating an Authorized Servicer Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs. Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician and using authorized factory parts.

  • Page 7: Section 2 - Introduction

    EA2220* EA2221* EA2311* EA2520* EA2521* EA2610* EA2620* EA2621* EA2710* EA2721* EA2820* EA2821* EA2920* EA2921* JA0110*T * Add Letter To Designate Color. L – Almond W – White 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 8: Customer Service

    Model and serial numbers are located on nameplate(s) as shown. Nameplate NOTE: Coin slide and coin drawer shown for illustration purposes only. W233SE3B © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 9: Section 3 - Troubleshooting

    Broken, loose, or incorrect wiring. Refer to appropriate wiring diagram. †Inoperative electronic control. Refer to Section 8 to check electronic control operation. *Mechanical Timer Models only. †Electronic Control Models only. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 10: No Warm Water

    *Timer motor lead wire off timer terminal. Refer to appropriate wiring diagram and reattach wire. Broken, loose or incorrect wiring. Refer to appropriate wiring diagram. *Mechanical Timer Models only. †Electronic Control Models only. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 11: Motor Does Not Run

    Refer to appropriate wiring diagram for correct wiring. †Inoperative electronic control. Refer to Section 8 to check electronic control operation. *Mechanical Timer Models only. †Electronic Control Models only. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 12: No Agitation

    Inoperative transmission assembly. Repair or replace transmission assembly. †Inoperative electronic control. Refer to Section 8 to check electronic control operation. *Mechanical Timer Models only. †Electronic Control Models only. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 13: Washer Smokes, Overheats, Cycles On Motor Thermal Overload Protector, Switch Actuator Kicks In And Out

    Adjust motor bracket. Refer to Paragraph 64. *Inoperative electronic control. Refer to Section 8 to check electronic control operation. *Mechanical Timer Models only. †Electronic Control Models only. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 14: Constant Spin

    Free binding pads, or replace pads. Incorrect voltage. Contact local utility company, or have a qualified electrician check power supply. *Mechanical Timer Models only. †Electronic Control Models only. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 15: Outer Tub Does Not Empty

    Outer tub cover gasket leaking. Replace gasket. Obstruction in drain causing water to come over top Remove obstruction. of outer drain tub cover. Tub-to-pump hose leaking at clamp. Tighten clamp. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 16: Troubleshooting Coin Drop

    IMPORTANT: Do not bend or damage mechanical parts within coin drop. Additional coins following path to sensor Coin in Coin Slot Coin Drop Sensor DRY2B Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 17 Refer to Adjustments prevent coins from section for instructions following through on cleaning drop. required check stages of drop.) Replace coin drop TLW302S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 18 Section 3 Troubleshooting Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 19: Troubleshooting Electronic Control

    Damaged terminals in the harness connector will appear burnt or show signs of heat discoloration on the connetor block. Replace the control to avoid repeated damage. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 20: Cannot Perform Infrared Communication

    Check the following: – (IR) disabled by manual prog. – Is the (IR) on the control covered or blocked? – If needed, change electronic W367S control board. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 21: Coins Ignored When Entered

    Retest again, if not successful run test again. run test again. the following is the problem: – Replace coin drop. If the problem still exists: – Replace electronic control. W368S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 22: Electronic Control Has No Visible Display

    "FS2" the electrical outlet to the electronic control. white? NOTE: This voltage check confirms that main power is present to the control. Replace electronic control. W369S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 23 Section 3 Troubleshooting Electronic Control (Models EA2820*, EA2821*, EA2920* and EA2921*) Notes 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 24: No Fill Analysis

    On mixing valve check and replace: – Inlet screens. – Wiring and connections. – Replace coils or mixing valve. – Check thermal protect and wiring W370S from thermal protect to "H3-3" © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 25: Electronic Control

    H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR W371S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 26: No Motor Run - Agitate Analysis

    BLU "H3-4" to "H3-2" refer to Section 7 RED "H3-6" to BRN or Paragraph 6. "H3-2" is there voltage? Replace electronic control board. W372S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 27 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR W373S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 28: No Motor Run - Spin Analysis

    BLU "H3-4" to "H3-6" refer to Section 7 BRN "H3-2" to "H3-6", or Paragraph 6. is there voltage? Replace electronic control board. W374S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 29 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR W375S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 30: Overflow Analysis

    If this happens, replace the mixing valve. Check for a locked open mixing valve. W376S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 31 H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR W377S 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 32: Audit Switch Function Analysis

    – Machine/cycle var reports. Check for proper wiring and connections. After wiring has been confirmed correct, replace electronic control board. D216S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 33: Section 4 - Grounding

    W011GE3A Figure 2 28. POWER CORD TO CONTROL HOOD, CONTROL HOOD TO THE CONTROL PANEL FRAME Refer to Figure 3. Ground Wires Ground W285SE3A Wires Figure 3 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 34: Control Hood Wire Harness To Top Left Rear Corner Gusset Of Cabinet

    Corner Wire Gusset Ground Screw Ground Wires W013GE3A Figure 4 30. WIRE HARNESS TO MOTOR Refer to Figure 5. Ground Wire Harness Connection Block W329SE3C Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 35: Section 5 - Service Procedures

    NOTE: Refer to appropriate wiring diagram when reconnecting wire harnesses, ground and switch W284SE1A leads. Figure 6 Disconnect Blocks Pressure Ground Ground Disconnect Switch Wires Wires Blocks Indicator Light W285SE3B Figure 7 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 36 IMPORTANT: When installing pressure switch, blow air into hose before connecting hose to switch to remove any moisture that may have accumulated in hose. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 37 NOTE: Refer to appropriate wiring diagram when rewiring switches and indicator lights. (5) Remove control panel overlay by peeling it from control panel frame. NOTE: Control panel overlay has an adhesive backing. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 38: Timer Assembly

    Refer to Figure 10. Shoulder Screw Meter Case Timer Ground Wire Terminal Timer Timer Bracket Bracket Attaching Screws Terminal Block Plug W237SE1A Figure 10 W334SE1B Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 39 (7) Make sure wire harness is routed along rewiring timer. bottom of meter case so it will not interfere with any moving parts in meter case. Setscrew Clutch W238SE1A Figure 11 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 40: Meter Or Timer Case Assembly

    Timer Case Screw Lockwasher Timer Plate Attaching Screw Timer Knob Timer Case Screws Attaching Hardware W240SE1A Figure 13 Timer Case Timer Attaching Timer Screw W239SE1A Figure 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 41: Drain Hose Elbow

    NOTE: Reverse procedures when installing loading door. Loading Door Hinge Attaching Screws Elbow Attaching Screws Hose Drain Clamp W242SE1A Hose Right Left Hinge Figure 14 Hinge W287SE1A Figure 15 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 42 Section 5 Service Procedures Procedure One Door Front W288SE3A Procedure Two Door Front W289SE3A Procedure Three Door Front W290SE3A Figure 16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 43: Front Panel Assembly

    Remove brace from front panel by swinging one end toward bottom of front panel and remove brace. Cabinet Top Hold Down Screws Hold-Down Clip Front Panel Screws W292SE3A Figure 17 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 44: Belts

    IMPORTANT: Drive belt MUST be replaced with belt No. 28808 (special clutch-type belt) for proper washer operation. Pump Bracket Pump Mounting Belt Screws W283SE1E BELT DRIVEN PUMP Figure 18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 45 Hose Clamp Tub-to-Pump Hose Hose Coupler 31969 Pump Assembly (Includes four 31098 Screws) Hose Support Hose Screw Clamps Pump Mounting Bracket Pump Mounting Screw W192PE3E Figure 19 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 46 Helper Spring Motor The round spring Mounting hook must be Bracket hooked in rear hole for proper W248SE3B idler lever operation Figure 20 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 47: Motor And Mounting Bracket

    NOTE: Refer to Figure 22 for motor and mounting bracket assembly sequence. Switch Locking Attaching Screw Connection Motor Motor Mount Block W267SE3A Switch Attaching Screws Figure 21 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 48 Shoulder Mounting Bolt Bracket Idler Pulley Motor Mount Locknut Idler Post Shaft Washer (Felt) Washer Belt (Nylatron) (Agitate and Retainer Spin) Belt Ring W122PE3D (Pump) Figure 22 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 49: Motor Drive Pulley Or Pump Pulley

    Mounting e. Disconnect internal motor leads from motor Screw Bracket switch terminals. W250SE1A NOTE: Refer to Wiring Schematics, SECTION 10 Figure 23 for rewiring internal switch wires. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 50: Agitator

    NOTE: Cabinet top is self supporting, however, a small chain may be used for additional support. Refer to Figure 25. Chain Agitator W247SE1A Figure 24 W252SE1A Figure 25 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 51: Cabinet Top Assembly Removal

    Carefully lift cabinet top off washer and set on protective padding. WARNING To reduce the risk of serious injury, be careful not to damage door switch and out- of-balance switch assembly when removing cabinet top. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 52 Section 5 Service Procedures Corner Gusset Pressure Ground Hose Wire Mixing Valve Wire Harness Disconnect Blocks 274P4 Tub Cover Tool W314SE3D Figure 26 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 53: Agitator Drive Bell And Seal Kit, No. 36443P

    IMPORTANT: If large nut is turned clockwise approximately three quarters of the way. Refer when pulling drive bell, you will twist off the to Figure 27. quarter inch bolt. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 54 Apply remainder of supplied grease, Part No. 36765P, to exposed surface of washer between there should be no gap! transmission output shaft and seal. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 55 Push down on tool with a quick motion until it bottoms out and the top of seal is fully seated. NOTE: Do not push agitator onto drive bell any Refer to Figure 33. further than necessary. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 56: Out-Of-Balance Switch Assembly

    Screws W273SE1A through holes in switch holder. TAPPING SCREW INSTALLATION (6) Place switch assembly into switch holder. Refer to Figure 34. Figure 34 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 57 Switch Clip Push Tabs Here W174SE1A Figure 36 272P4 Switch Tool Cabinet Switch Lever W171SE1A Figure 35 Switch Clips W175SE1A Switch Holder Switch Slots Holder Figure 37 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 58: Mixing Valve Assembly

    Figure 39. e. Remove wires and quick disconnect blocks from mixing valve solenoid terminals. Refer to Figure 39. NOTE: Refer to appropriate wiring diagram when rewiring solenoid. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 59: Outer Tub Cover And Clothes Guard

    Refer outer tub cover. Refer to Figure 40. to Figure 40. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 60 Part No. 273P4. Tub Cover Gasket 273P4 Tub Cover Tool Press Gasket Into Groove Using Your Fingers Hold-Down Hold-Down Tabs Tabs W208SE3B Figure 41 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 61 W255SE3B cover off tub flange. Figure 42 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 62 Then carefully push clothes guard down into washtub until all pins snap into their respective holes. Slots Washtub Screws Clothes Washtub Guard Screws Pins W209SE3A Figure 43 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 63: Hub And Seal Kit, No. 495P3

    Lubricate inner splines of new hub assembly (supplied in kit) with No. 27604P Anti-Seize Compound. h. Carefully place new hub assembly on splined Flinger transmission tube. W179SE1E Figure 44 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 64 Apply Bead Of No. 27615P Apply Bead Of Sealant Here No. 27615P (Step "f") Sealant Here (Step "f") Insert Sleeve From W180SE3A Bottom Side Of Seal Figure 45 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 65: Outer Tub Assembly

    (with transmission, balance ring and bracket and move idler lever to left to release pivot dome attached) straight up and out of tension on belt. washer cabinet. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 66 Pivot Dome Attaching Brake Screws Assembly Pivot Dome Lower Bearing Housing Drive Pulley Transmission Assembly Plate Screw Balance Ring W257SE3A Figure 47 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 67: Drive Pulley And Helix

    This condition will persist until lubricant is removed. Drive Pulley Washer Cap Screw Helix W271SE3A Figure 48 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 68 Apply Lubricant Here Drive Pulley Apply Lubricant Washer Here Helix Cap Screw Pivot Dome DO NOT LUBRICATE Washer Base Snubber Pad and Isolator Assembly W183SE3C Figure 49 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 69: Brake Assembly

    NOTE: Refer to Figure 49 for assembly sequence. NOTE: When installing spring, be sure it is inserted into groove in large splines of lower transmission tube. Use tool, No. 242P4, for installing spring. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 70: Transmission Assembly

    (cover end up) and remove three transmission assembly straight up and out of screws and lockwashers. balance ring and upper bearing. Refer to Figure 50. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 71 Carefully remove output shaft and washer from transmission case. IMPORTANT: Carefully examine area inside cover tube (seals, bearing, roller clutch, etc.). If oil is present between seals and bearing, or roller clutch 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 72 Refill transmission case with new No. 27243P Transmission Oil (one fill). © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 73 Gear (Input) Identification Groove Agitator Pinion Dowel Rack Slide Transmission Cover Assembly Screw Dowel W186SE3C LOCTITE Use as a sealant between Transmission Case and Cover Figure 51 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 74: Balance Ring

    NOTE: When reinstalling upper bearing assembly threads of cap screws must be secured using Loctite. Ball Bearing Cap Screw Outer Upper Bearing Flinger Housing Upper Flinger Bearing Housing W196SE3D Figure 52 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 75: Snubber Pad And Isolator Assembly

    (not kinked or twisted). If it is not, loosen hose clamp and straighten hose. Starting Edge Isolator Strip Elongated Hole Dome Area of Washer Base W220SE3C Figure 53 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 76 Then reinstall control panel. NOTE: Washer must be run through a complete k. Reinstall washer front panel. cycle to make sure it is operating properly. Pressure Hose W317SE3A Figure 54 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 77: Section 6 - Adjustments

    If these locknuts are not tight, washer will not remain stationary during operation. Washer Base Locknut Leveling Rubber Foot Front Panel Screws W286SE3A Figure 55 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 78: Pressure Switch

    Paragraph 36. Centering b. Open cabinet top assembly. Refer to Paragraph Spring W256SE1A c. Check for bent actuator arm or lever. Refer to Figure 58 Figure 57. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 79: Belt (Agitate And Spin)

    After belt tension is obtained, tighten pump attaching screws. Refer to Figure 59. Pump Bracket Pump Mounting Belt Screws W283SE1E Figure 59 Pump Motor Pulley Pulley 1/2 in. (12.7 mm) W231SE1A Figure 60 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 80: Idler Spring Tension

    Refer to Figure 62. Reinstall the idler spring. CORRECT Green Clip W020BE3B Figure 61 INCORRECT Green Clip W021BE3B Figure 62 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 81: Cleaning Coin Drop

    Move metal clip closer to sensor so that it comes off frame. Refer to Figure 63. g. Remove coin return from coin drop frame. Refer to Figure 64. Cotton Swab DRY5B Figure 65 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 82 Place drop on level surface to verify that coins follow correct path in drop. It may be necessary to lift drop to allow coin to follow through sensor. o. Reinstall coin drop into machine. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 83: Section 7 - Test Procedures

    VIOLET WIRE. LOW SPEED TERMINALS MANUALLY DEPRESS ACTUATOR. CONTINUITY EXISTS INOPERATIVE LOW SPEED SWITCH. BETWEEN SWITCH TERMINAL P REPLACE SWITCH. AND VIOLET WIRE. MOTOR SWITCH CHECKS OK. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 84: Emerson Motor Windings

    INDICATE WHETHER YES, MOTOR PASSED THIS TEST OR, NO IT FAILED THIS TEST Washer Motor Failure Motor Switch Motor Windings Start Terminals: Start Winding: High Speed Winding: High Speed Terminals: Low Speed Winding: Protector/Common Lead: Low Speed Terminals: © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 85: Section 8 - Service Procedures Unique To The Ea2311* Electronic Control Model

    DO NOT use an YOUR HOME HAS ADEQUATE ELECTRICAL extension cord or an adapter to connect POWER TO OPERATE THE WASHER. washer to electrical power source. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 86: Grounding Instructions

    • Do not modify plug provided with washer - if it is used by authorized persons to set up control and will not fit outlet, have a proper outlet installed washer. by a qualified electrician. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...
  • Page 87 WARM, LUKEWARM or COLD for NORMAL information. wash cycle. Cold operates only cold water side of Receptacle Attaching Screwdriver Screws Slot Meter Case Mounting Knockout Bracket Receptacle W263SE3A Figure 70 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 88 DELICATE L = LUKEWARM WAS COLD, 18:35 17:35 15:15 Without extra rinse RINSE FILL 35:35 34:35 WILL BE 22:45 21:45 18:55 With extra rinse COLD. 39:45 38:45 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 89: Power Outage Or Interruption

    36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 90: Program Transfer

    PROGRAM TRANSFER pad. direct sunlight. Display will show “Pro” for approximately one Flat Plug Receptacle Meter Case Cable and Plug Connector from Handheld Programmer W264SE3A Figure 71 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 91: Handheld Programmer

    Pressing pad again will display number of closures for line number two. Type of coin acceptor used will determine what these numbers translate to in actual money. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 92 Side At Display The Top Programmer Plug Connector END VIEW OF PLUG Function Mode (Audit Capability) Audit Function Key Lock Locked DETAIL OF W265SE3A LOCK KEY Figure 72 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 93: Cycle Programming

    Pressing SLIDE/DROP pad displays what coin acceptor washer is programmed for. Displays are “SL” for slide, “dP1” for single coin drop, and “dP2” for dual coin drop. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 94: Coin Acceptor

    Run washer through a cycle to make sure water continues to fill when loading door is opened. Agitation or spinning should not occur with loading door open. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 95: Troubleshooting Electronic Control

    IMPORTANT: It is not recommended to operate washer for extended periods of time in a single diagnostic mode, premature failure and overheating may result. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 96 Green GROUND Microcomputer Transformer Brown Black SPIN PNK/ Orange Yellow NEUT PRESS SW Blue/White AGITATE COLD Gray W266SE3A CONNECTION, RELAY AND TRANSFORMER DIAGRAM (ELECTRONIC CONTROL) Figure 73 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 97: Symptom: Indicator Led's (I.e. Wash, Rinse, Spin, Unbalanced) Do Not Light

    If problem persists, *For precision, this measurement must wiring? replace control. be taken with a digital multi-meter set on 200 Ohm scale. Correct wiring. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 98: Symptom: Tripped Circuit Breaker Or Blown Fuse

    If problem replace control. persists, replace control. Correct wiring. *For precision, this measurement must be taken with a digital multi-meter set on 200 Ohm scale. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 99: Symptom: Washer Will Not Fill Or Wrong Temperature Fill

    Problem not related to mixing valve electronic control. Refer to Section 3 “Troubleshooting” for diagnosing problems with Check water inlet components other than the pressure and electronic control. temperature 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 100: Symptom: Washer Will Not Agitate Properly

    “P8” (neutral) on control? Problem not related to electronic control. Refer to Section 3 “Troubleshooting” for diagnosing problems with components other than the electronic control. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 101: Symptom: Washer Will Not Spin Properly

    (START/AGITATE) and “P8” control. (neutral) on control? Problem not related to electronic control. Refer to Section 3 “Troubleshooting” for diagnosing problems with components other than the electronic control. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 102: Control Replacement

    A copy of replacement report, shown on the following page, must be completely filled out and returned with control. Warranty credit will be issued only if control is handled and packaged properly. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 103: Electronic Control Board Replacement Report

    Additional Comments: Both copies of this form must be completed and returned with the control board. Warranty is void if control board is returned improperly packed or damaged. 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 104 Section 8 Service Procedures Unique to the EA2311* Electronic Control Model Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 105: Section 9 - Cycle Sequence Charts

    X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 28716 CYCLE SEQUENCE (LONG CYCLE – KINGSTON) 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 106: Timer No. 31111P Cycle Sequence (Short Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 31111P CYCLE SEQUENCE (SHORT CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 107: Timer No. 34601P Cycle Sequence (Long Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34601P CYCLE SEQUENCE (LONG CYCLE) 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 108: Timer No. 34602 Cycle Sequence (Long Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34602 CYCLE SEQUENCE (LONG CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 109: Timer No. 34454 Cycle Sequence (Long Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34454 CYCLE SEQUENCE (LONG CYCLE) 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 110: Electronic Control No. 33422P Cycle Sequence

    18:35 17:35 15:15 Without extra rinse RINSE FILL 35:35 34:35 WILL BE 22:45 21:45 18:55 With extra rinse COLD. 39:45 38:45 ELECTRONIC CONTROL NO. 33422P CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

  • Page 111: Section 10 - Internal Wiring Of Washer Motor Switch

    W003 White Brown Blue Yellow W310SE3A 4P M YELLOW OVERLOAD PROTECTOR AUX. W211SE3A MOTOR ASSEMBLY (1 Speed Motors) 36007 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 112: Motor Assembly (2 Speed Motors)

    W003 Ground Wire Harness Connection Block White Blue Brown Violet Yellow W311SE3E 4P M YELLOW 6P M OVERLOAD PROTECTOR AUX. W224SE3A MOTOR ASSEMBLY (2 Speed Motors) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36007...

This manual is also suitable for:

Ea2020 seriesEa2111 seriesEa2120 seriesEa2121 seriesEa2210 seriesEa2220 series ... Show all

Table of Contents
