Table Of Contents - Invacare XLT Power U-front Service Manual

Product description ................................................ 4
XLT Models .............................................................. 5
NB! ............................................................................. 6
Lifting the wheelchair ............................................. 6
Intended use ............................................................. 7
Upholstery and frame colours ............................. 8
Equipment and accessories ................................... 8
Technical data .......................................................... 9
Adjustments:
Legrests ................................................................... 10
Calf pads/Footplates ............................................. 11
Seat ........................................................................... 13
Backrest ................................................................... 14
Armrests/Mudguards ............................................ 17
Brakes ...................................................................... 18
Rear wheels ........................................................... 19
Castor wheels ........................................................ 20
Wheelchair heights ............................................... 21
10
5
9
1. Frame (chassis)
2. Backrest
3. Push handles
4. Seat
5. Rear wheel
INVACARE ® XLT Service Manual
Contents
Parts of the wheelchair
3
11
4
13
7
8
Accessories:
Anti-tip devices ...................................................... 29
Trunk support........................................................ 31
One-arm drive ....................................................... 32
Assistant manoeuvred drumbrakes .................. 33
Amputee legrest/External push handles .......... 34
Foldable push handles .......................................... 35
Pelvic belt ................................................................ 35
Washing and Disinfection ................................... 36
Reconditioning ....................................................... 37
Tool List .................................................................. 38
Check List ............................................................... 39
1
12
6
6. Hand rims
7. Brakes
8. Castors
9. Anti tip device
10. Armrests
2
14
11. Jaw
12. Legrests
13. Footrest
14. Footbow
3
