Owner's Operator and Maintenance Manual
®
Recumbent
Handcycle Series
Top End XLT™
Top End XLT Jr.
Top End XLT Pro
Top End XLT Gold
Top End Force™
DEALER: This manual MUST be given to
the user of the handcycle.
USER: BEFORE using this handcycle, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Advertisement
Table of Contents
Related Manuals for Invacare Force
Summary of Contents for Invacare Force
- Page 1 Top End Force™ DEALER: This manual MUST be given to the user of the handcycle. USER: BEFORE using this handcycle, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
- Page 2 ACCESSORIES WARNING INVACARE PRODUCTS ARE SPECIFICALLY DESIGNED AND MANUFACTURED FOR USE IN CONJUNCTION WITH INVACARE ACCESSORIES. ACCESSORIES DESIGNED BY OTHER MANUFACTURERS HAVE NOT BEEN TESTED BY INVACARE AND ARE NOT RECOMMENDED FOR USE WITH INVACARE PRODUCTS. NOTE: Updated versions of this manual are available on www.invacare.com. Recumbent Handcycle Series...
-
Page 3: Table Of Contents
TABLE OF CONTENTS REGISTER YOUR PRODUCT ... 7 DEALER/TECHNICIAN INFORMATION ... 8 SPECIAL NOTES ... 8 TYPICAL PRODUCT PARAMETERS ... 10 SECTION 1—GENERAL GUIDELINES ... 12 Proper Fit ...12 Operating Information...12 Tire Pressure ...14 Weight Limitation...14 SECTION 2—SAFETY AND HANDLING ... 15 Safety and Handling of the Handcycle...15 Stability and Balance...15 A Note to Handcycle Assistants...15... - Page 4 Adjusting Seat Fore/Aft - XLT Gold and Top End Force Only ...37 Adjusting Seat Height - All Models Except XLT Gold and Top End Force ...38 Adjusting Back Angle - All Models Except XLT Gold and Top End Force ...39 Adjusting Back Angle - XLT Gold...40...
- Page 5 TABLE OF CONTENTS SECTION 8—SERVICE PROCEDURES ... 46 Replacing the Fork/Crank Assembly ...46 Replacing the Crank Arms - XLT Gold, XLT PRO and Top End Force ...49 Replacing the Left Side Crank Arms...49 Replacing the Right Side Crank Arms ...49 Installing/Removing/Adjusting the Road Crown Compensator ...50...
- Page 6 TABLE OF CONTENTS SECTION 9—OPTIONS ... 60 Installing Rear Safety Light...60 Batteries ...60 Mounting the Safety Light...60 Operating the Safety Light ...60 Installing the Water Bottle ...61 Installing/Using the Tow Bar ...61 Installing the Draft Bumper ...62 Installing the Safety Flag...62 Using Safety Helmet...62 Installing Seat Positioning Strap...63 Installing the Computer ...63...
-
Page 7: Register Your Product
Register ONLINE at warranty.invacare.com Please have your model number and purchase date available to complete your registration. Any registration information you submit will only be used by Invacare Corporation and protected as required by applicable laws and regulations. Part No 1114850... -
Page 8: Dealer/Technician Information
CHANGE WITHOUT NOTICE. HANDCYCLE USER As a manufacturer of handcycles, Invacare endeavors to supply a handcycle to meet many needs of the end user. However, final selection of a handcycle to be used by an individual rests solely with the user and his/her health care professional capable of making such a selection. - Page 9 ALWAYS wear your seat positioning strap. Inasmuch as the seat positioning strap is an option on this handcycle (you may order with or without the seat positioning strap), Invacare strongly recommends ordering the seat positioning strap as an additional safeguard for the handcycle user. The seat positioning strap is a position- ing belt only.
-
Page 10: Typical Product Parameters
TYPICAL PRODUCT PARAMETERS Seat Width: 14 to 20 inches Seat Depth: 15 inches Seat-to-Floor (approx.): 12, 13, or 14 inches Back Style: Adjustable Back Angle 90° - 110° Back Height Fixed/ 11-14 inches (Wide) Adjustable Angle: 20 inches (Narrow, Tall) Footrest: Adjustable Fore and Aft Side - Wheel Clearance: 2 inches - * 2½... - Page 11 TOP END XLT PRO Seat Width: 14 to 18 inches Seat Depth: 15 inches Seat-to-Floor (approx.): 12, 13 and 14 inches Back Style: Adjustable Back Angle 90° - 110° Back Height Fixed/ 11-14 inches (Wide) Adjustable Angle: 18½ inches (Narrow, Tall) Footrest: Adjustable Fore and Aft Side - Wheel Clearance: 2 inches - * 2½...
-
Page 12: Section 1-General Guidelines
SECTION 1—GENERAL GUIDELINES SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. Proper Fit The handcycle MUST be adjusted to fit the rider. For a proper fit: • The rider MUST be able to see over the hand crank. • The rider MUST have a slightly bent elbow when the hand pedals are toward the front of the handcycle (farthest from the riderʹs face). • The rider MUST have a slight bend at the knee when feet are in the footrests. Feet should be flat against footrest hoop. • XLT Series requires a 18ʹ turning radius. If leg touches tire during turn and user cannot sense this, a leg guard attachment is recommended. • The riderʹs knees MUST not obstruct hand crank operation. Check the seat position, back angle, quick‐release on threaded axles, footrest fore/aft position, hand crank height for proper fit and smooth operation of your handcycle. Operating Information Wear your helmet at all times when riding the handcycle. - Page 13 SECTION 1—GENERAL GUIDELINES Top End XLT, XLT jr., and XLT Gold Models Only ‐ The parking brake of the handcycle MUST be engaged before attempting any transfer. Top End XLT Pro Model Only ‐ This model may be ordered with or without a parking brake. If ordered without a parking brake, the handcycle MUST be positioned securely against a stable object before any transfer is attempted. If ordered with the optional parking brake, the parking brake MUST be engaged before attempting any transfer. Care MUST be taken when operating on roads, streets or highways. Operation of the handcycle is subject to all traffic rules and regulations. (This may include the use of a safety lights and reflectors for dusk/night riding.) Give pedestrians the right of way. Slow down at all street intersections and observe to the left, to the right and back to left again before proceeding. Use proper hand signals when turning. DO NOT attempt to move up or down an incline with an ice or oil film. DO NOT attempt to ride over curbs or obstacles or speed bumps. Doing so may cause your handcycle to ʺbottom outʺ and/or turn over and cause bodily harm or damage to the handcycle. Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. DO NOT attempt to lift the handcycle by any removable (detachable) parts. Lifting by means of any removable (detachable) parts of an handcycle may result in injury to the user or damage to the handcycle. DO NOT stand on the seat or frame of the handcycle. ALWAYS wear your seat positioning strap. Inasmuch as the seat positioning strap is an option on this handcycle (you may order with or without the seat positioning strap), Invacare strongly recommends ordering the seat positioning strap as an additional safeguard for the handcycle user. The seat positioning strap is a positioning belt only. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear appear, belt MUST be replaced immediately. With regard to restraints – seat/chest positioning straps – it is the obligation of the DME dealer, therapists and other healthcare professionals to determine if a seat/chest positioning strap is required to ensure the save operation of this equipment by the user. SERIOUS INJURY CAN OCCUR IN THE EVENT OF A FALL FROM A WHEELCHAIR. Avoid all surface hazards. DO NOT carry any riders. DO NOT carry any items that may obstruct your view or prohibit you from operating the ...
-
Page 14: Tire Pressure
SECTION 1—GENERAL GUIDELINES Tire Pressure DO NOT use your handcycle unless it has the proper tire pressure (p.s.i.). DO NOT overinflate the tires. Failure to follow these suggestions may cause the tire to explode and cause bodily harm. DO NOT ride on a flat or underinflated tires. Riding on flat or underinflated tires can cause injury, as well as, damage to the tire, tube and handcycle. Weight Limitation The Invacare Top End XLT handcycles have a weight limitation of 250 lbs. A weight limitation label is on the rear axle of the handcycle. Top View Weight Capacity Label FIGURE 1.1 Weight Limitation Recumbent Handcycle Series Part No 1114850... -
Page 15: Section 2-Safety And Handling
SECTION 2—SAFETY AND HANDLING SECTION 2—SAFETY AND HANDLING Safety and Handling of the Handcycle Requires the close attention of the user as well as the assistant. This manual points out the most common procedures and techniques involved in the safe operation and maintenance of the handcycle. It is important to practice and master these safe techniques until you are comfortable in maneuvering the handcycle. Use this information only as a basic guide. The techniques that are discussed on the following pages have been used successfully by many. Individual users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming obstacles that they may encounter. Techniques in this manual are a starting point for the new handcycle user and assistant with safety as the most important consideration for all. Stability and Balance For stability and proper operation of your handcycle, you MUST at all times maintain proper balance. Your handcycle should remain upright and stable during normal daily activities when operated correctly. Invacare recommends using seat positioning straps for additional safety. A Note to Handcycle Assistants When learning assistance techniques for the handcycle, have an experienced assistant help you before attempting it alone. When you are assisting with a transfer to/from the handcycle, remember to use good ... -
Page 16: Percentage Of Weight Distribution
Percentage of Weight Distribution Transferring in and out of the handcycle will cause a change to the normal balance, the center of gravity, and the weight distribution of the handcycle. To determine and establish your particular safety limits, practice transferring activities in several combinations in the presence of a qualified health care professional before attempting a transfer alone. Proper positioning is essential for your safety. Transferring Into/Out of the Handcycle Before attempting to transfer in or out of the handcycle, every precaution should be taken to reduce the gap distance. Position the XLT on level ground and as close as possible to the object you are transferring into or out of. - Page 17 NOTE: During independent transfer, little or no seat platform will be beneath you. Although it may be difficult to wedge the transfer board between the handcycle seat and the handcycle seat, use a transfer board if necessary. NOTE: Refer to STEPS A‐F in FIGURE 2.1 for details regarding transfer to/from a handcycle. 6. Shift body weight onto object while transferring. 7. Lift and place left leg past front frame across seat and over center tube. WARNING If installed, parking brake MUST be secured. STEP F: Place both legs onto handcycle footrests and secure safety straps. Handcycle Pedals (positioned toward the front of the handcycle). Footrest Seat Frame STEP E: Lift and shift weight down into handcycle seat.
-
Page 18: Section 3-Safety Inspection
SECTION 3—SAFETY INSPECTION Safety Inspection Checklist NOTE: Every six months, take your Top End XLT to a qualified technician for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your Top End XLT. For safe and proper operation, your handcycle MUST be cared for just like any other vehicle. Routine maintenance will extend the life and efficiency of your Top End XLT. NOTE: Invacare recommends that the following adjustments be performed by a qualified technician. Initial adjustments should be made to suit your personal body structure and preference. Thereafter follow these maintenance procedures. Inspect/Adjust Initially ❑ Inspect for bent or broken frame. ❑ Inspect parking brake ‐ Adjust brake shoes to front rim. Check for worn or missing shoes. Check for wax or oil on rim. ❑ Ensure cable anchor is attached securely to brake arm. ❑ Ensure internal stopping brakes engages easily. As with any vehicle, the wheels/casters and tires should be checked periodically for cracks, flat spots and wear, and should be replaced. -
Page 19: Inspect/Adjust Weekly
❑ Inspect seat positioning strap for any signs of wear. Ensure buckle latches. Verify hardware that attaches strap to frame is secure and undamaged. Replace if necessary. ❑ Inspect upholstery for rips or sagging. ❑ Clean upholstery with light detergent and water. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Ensure that casters are free of debris. Inspect/Adjust Weekly ❑ Inspect parking brake ‐ Adjust brake shoes to front rim. Check for worn or missing shoes. Check for wax or oil on rim. ❑ Ensure cable anchor is attached securely to brake arm. ❑ Ensure internal stopping brakes engages easily. As with any vehicle, the wheels/casters and tires should be checked periodically for cracks, flat spots and wear, and should be replaced. ❑... -
Page 20: Inspect/Adjust Monthly
Inspect/Adjust Monthly ❑ Inspect for bent or broken frame. ❑ Ensure that casters are free of debris. Inspect/Adjust Periodically ❑ Inspect for bent or broken frame. ❑ Inspect parking brake ‐ Adjust brake shoes to front rim. Check for worn or missing shoes. Check for wax or oil on rim. ❑ Ensure cable anchor is attached securely to brake arm. ❑ Ensure internal stopping brakes engages easily. As with any vehicle, the wheels/casters and tires should be checked periodically for cracks, flat spots and wear, and should be replaced. ❑ Ensure axle nuts are tight. Wheel should be centered in fork. Keep wheel bearings adjusted and keep spokes tight and wheel in proper alignment. -
Page 21: Troubleshooting
Troubleshooting VEERS VEERS SLUGGISH RIGHT LEFT TURN OR PERFORMANCE Maintenance Maintenance Safety Precautions After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. DO NOT overtighten hardware attaching to the frame. This could cause damage to the frame tubing. - Page 22 7. The wheels and tires should be checked periodically for cracks and wear, and should be replaced if damaged. 8. Check chain for slack and readjust.Refer to Installing/Adjusting Seven Speed Hub Chain on page 54 or Installing/Adjusting Twenty‐Seven Speed Cassette Chain on page 55. 9. Regularly check for loose spokes in the front and rear wheels. If loose, have them aligned at your local bike shop. 10. Check road crown compensator and steering dampner for proper operation. Refer to Installing/Removing/Adjusting the Road Crown Compensator on page 50 and Installing/Removing/Adjusting the Steering Dampener ‐ For Top End XLT Gold and Force Only on page 52. 11. Check upholstery for sagging, rips or tears. Refer to Replacing Seat Upholstery on page 58 and Replacing Back Upholstery on page 59. 12. Check alignment of front wheel. If it wobbles or takes too much effort to turn by hand, have it aligned at your local bicycle shop. Recumbent Handcycle Series WARNING ® lubricant. WARNING CAUTION...
-
Page 23: Section 4-Initial Setup
4. Adjust chain length (Adjusting Seven Speed Hub Chain on page 55 or Adjusting Twenty‐Seven Speed Cassette Chain on page 56) if crank has been adjusted. 5. If installed, ensure parking brake functions properly (Adjusting/Replacing the Parking Brake on page 57). Check tension and adjust parking brake cable if necessary. 6. Check brakes to make sure brakes work properly. 7. If back height is adjustable, adjust back height (Adjusting Back Height ‐ Wide Back Option Only on page 41). 8. Adjust seat position/upholstery (Adjusting Seat Fore/Aft ‐ All Models Except XLT Gold and Top End Force on page 36, Adjusting Seat Height ‐ All Models Except XLT Gold and Top End Force on page 38 and/or Replacing Seat Upholstery on page 58). 9. Adjust the hand crank. Refer to Adjusting Hand Crank on page 34. 10. Check that all hardware is tight. Part No 1114850 WARNING TOOLS REQUIRED: 1/2-inch Box Wrench 1/2-inch Socket Wrench Medium Flat Screwdriver... - Page 24 SECTION 4—INITIAL SETUP Top End XLT/XLT Jr. Hand Crank Assembly/ Seat Reversing Drum Brake Back Chain Rear Wheel Parking Brake Cable Shifter Footrest Location NOTE: Parking brake located on left side of seat frame. Top End XLT PRO Brake Cable Hand Crank Assembly Back Fork Mounted Shifters and Brakes Rear Wheel Chain Footrest...
- Page 25 SECTION 4—INITIAL SETUP Top End XLT Gold Rapid-Fire Hand Hand Crank Assembly Brake/Shifter Back Chain Rear Wheel Seat Footrest Top End Force Rapid-Fire Hand Hand Crank Assembly Brake/Shifter Chain Back Rear Wheel Seat Footrest FIGURE 4.2 Initial Setup Part No 1114850...
-
Page 26: Section 5-Operation
3. Ensure that the hand crank is not obstructing your view. Refer to Adjusting Hand Crank on page 34. 4. Ensure the footrest is adjusted properly. If necessary, adjust the footrest. Refer to Replacing/Adjusting the Footrest and Leg Guard on page 32. NOTE: Footrest should be adjusted so that when seated with feet in the footrests, there is a slight bend at the knee. 5. Ensure the seat is adjusted properly. If necessary, adjust the seat. Refer to Adjusting Seat Fore/Aft ‐ All Models Except XLT Gold and Top End Force on page 36 or Adjusting Seat Height ‐ All Models Except XLT Gold and Top End Force on page 38. NOTE: Seat should be adjusted so that when seated with feet in the footrests, there is a slight bend at the knee and a slight bend at the elbow when the hand crank is furthest away. 6. If installed, release the parking brake. Refer to Using Parking Brake on page 30. At least one hand MUST be on the hand crank assembly at all times. Otherwise, injury or damage may occur. -
Page 27: Shifting Gears
8. Rotate (pedal) the hand crank forward (toward the front) to propel the handcycle forward. 9. Top End XLT and XLT Jr. Models Only ‐ Rotate (pedal) the hand crank backward (toward the rear) to apply the brake and slow down or stop. NOTE: Top End XLT shown for clarity. Hand Crank (STEPS 3, 6, 8 and 9) Seat (STEP 5) Rear of Handcycle FIGURE 5.1 Riding the Handcycle Shifting Gears Seven Speed Hub NOTE: For this procedure, refer to FIGURE 5.2. NOTE: This procedure applies to the Top End XLT and XLT Jr. ONLY. To shift gears while moving, hold onto the hand crank assembly with one hand, continue pedaling, but ease pressure on the pedals and select the gear required with the other hand. When the Top End XLT is stationary, simply select gear required. 1. Perform one of the following: • Upshift ‐ Push the shifting lever towards the indicator and release. ... - Page 28 DO NOT press both shifter levers down at the same time. Doing so may damage the shifter and will void the warranty. The gears WILL NOT shift when both levers are pressed simultaneously. DO NOT use excessive force. This may damage the shifter and void the warranty. Lower Derailleur (Right Side Shifter) • Shifting from Harder Gears to Easier Gears (Downshift) ‐ Push shift lever “B” and ...
-
Page 29: Backing-Up
Speeds - Hands-On Rapid Fire Shifter/Brake System: Twenty-seven Speeds Backing-Up Use the rear wheels (i.e. like a manual handcycle) to backup. When backing up, keep the front wheel straight. The weight of the hand crank may engage the reversing drum brakes (Top End XLT and XLT jr. models ONLY) while backing up. Lift the pedals up to avoid this problem. CAUTION If backing up in the XLT PRO, XLT Gold and Force models, take care not to tangle the cables. Braking Top End XLT Handcycles have either internal gearing (7 speeds) or external gearing (24 or 27 speeds). Internal geared handcycles (7 speeds) are equipped with reversing drum brakes. External geared handcycles (24 or 27 speeds) have hand brakes. Reversing Drum Brakes NOTE: Top End XLT and XLT Jr. with the seven speed hub have reversing drum brakes. -
Page 30: Hand Brakes/Hands-On Brakes
Hand Brakes/Hands-On Brakes The twenty-seven speed cassette on the Top End XLT Pro, XLT Gold and Top End Force models use the hand brake as the primary brake. Reverse pedaling WILL NOT stop the bike. Handcycles equipped with Hand Brakes - In situations where caution is advised (heavy traffic, intersections, etc.) hands should be kept in the "ready"... -
Page 31: Steering/Cornering
• To Disengage the Parking Brake ‐ Squeeze and release the ratchet button. Parking Brake Location Slots or Hook and Loop Strap (Not Shown) Handle Steering/Cornering DO NOT attempt to corner the handcycle at high speeds. This could result in a fall causing injury and/or damage to the handcycle. NOTE: For this procedure, refer to FIGURE 5.6. To steer the handcycle, use the hand crank to direct the front fork and wheel assembly in ... -
Page 32: Section 6-Riding Position
SECTION 6—RIDING POSITION After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Replacing/Adjusting the Footrest and Leg Guard NOTE: For this procedure, refer to FIGURE 6.1. NOTE: If replacing footrest or leg guard, take note of current position. Replacing/Adjusting Footrest 1. Remove the hex bolt and locknut that secure the footrest to the fork. -
Page 33: Using/Replacing Footrest Strap
Using/Replacing Footrest Strap Footrest straps MUST be inspected before each use. Exposure to moisture (i.e.- wet weather or puddles) will damage fastening strips. Footrest strap will not hold feet securely in footrest if fastening strips are damaged. DO NOT operate handcycle if footrest straps are wet or damaged, otherwise severe injury may occur. -
Page 34: Adjusting Hand Crank
Adjusting Hand Crank DO NOT operate the handcycle if the hand crank obstructs your view. If the hand crank obstructs your view, adjust the height before using the handcycle - otherwise injury or damage may occur. Adjusting Hand Crank Height - All Models Except Top End XLT Gold NOTE: For this procedure, refer to FIGURE 6.4. -
Page 35: Adjusting Top End Xlt Gold Hand Crank
Adjusting Top End XLT Gold Hand Crank NOTE: For this procedure, refer to FIGURE 6.5. Adjusting Hand Crank Height 1. Loosen, but DO NOT remove the hex nut securing the hand crank to the fork stem. 2. Loosen, but DO NOT remove the two set screws for the upper clamp. 3. Move the hand crank assembly up or down in the fork neck until you are comfortable with the position for operational purposes. NOTE: The hand crank should be positioned so that when the hand is toward the front of the handcycle, the arm is slightly bent. The arm should NEVER be fully extended (locked) at any point while cranking. 4. Tighten the hex nut to secure the hand crank in the desired position. 5. Tighten the two set screws on the upper clamp. 6. Tighten the chain if necessary. Refer to Adjusting Seven Speed Hub Chain on page 55 or Adjusting Twenty‐Seven Speed Cassette Chain on page 56. FIGURE 6.5 Adjusting Top End XLT Gold Hand Crank Part No 1114850 Fork Neck Upper Clamp... -
Page 36: Adjusting Seat Fore/Aft - All Models Except Xlt Gold And Top End Force
7. Tighten the hex bolts and locknuts that secure the two seat angle adjustment clamps to the rear seat supports securely. Back Support Tube Seat Angle Adjustment Clamps Rear Socket Screws FIGURE 6.6 Adjusting Seat Fore/Aft - All Models Except XLT Gold and Top End Force Recumbent Handcycle Series Height Adjustment Clamp Height Adjustment Bracket Handcycle Seat Frame Frame... -
Page 37: Adjusting Seat Fore/Aft - Xlt Gold And Top End Force Only
2. Loosen, but DO NOT remove the two mounting bolts and locknuts securing the two back clamps to the seat rails. 3. Slide back clamps for (forward) or aft (rearward) along the seat rails to desired seat position. 4. Securely tighten the two mounting bolts and locknuts securing the two back clamps to the seat rails. 5. Reinstall the seat upholstery. Refer to Replacing Seat Upholstery on page 58. 6. If necessary adjust the back angle. Mounting Bolt and Locknut FIGURE 6.7 Adjusting Seat Fore/Aft - XLT Gold and Top End Force Only Part No 1114850 Recumbent Handcycle Series Seat Rails Back Clamp... -
Page 38: Adjusting Seat Height - All Models Except Xlt Gold And Top End Force
4. Install the two socket screws to secure the front of the seat frame to the handcycle frame. Back Support Tube Seat Angle Adjustment Clamps Rear Socket Screws FIGURE 6.8 Adjusting Seat Height - All Models Except XLT Gold and Top End Force Recumbent Handcycle Series Height Adjustment Clamp Height Adjustment Bracket Handcycle Seat Frame Frame... -
Page 39: Adjusting Back Angle - All Models Except Xlt Gold And Top End Force
5. Tighten the four socket screws that secure the seat frame to the handcycle frame securely. 6. Tighten the hex bolts and locknuts that secure the two seat angle adjustment clamps to the rear seat supports securely. Back Support Tube Seat Angle Adjustment Clamps FIGURE 6.9 Adjusting Back Angle - All Models Except XLT Gold and Top End Force Part No 1114850 Handcycle Frame Rear Socket Screws Recumbent Handcycle Series... -
Page 40: Adjusting Back Angle - Xlt Gold
Adjusting Back Angle - XLT Gold NOTE: For this procedure, refer to FIGURE 6.10. 1. Loosen, but DO NOT remove, the two socket screws located in the seat angle adjustment clamp. 2. Perform one of the following: • Increasing Back Angle ‐ While pushing down on the back support tube, push the back down to the desired position. • Decreasing Back Angle ‐ While lifting up on the back support tube, pull the back upward to the desired position. 3. Securely tighten the two socket screws located in the seat angle adjustment clamp. Socket Screw NOTE: Wheel not shown for clarity. FIGURE 6.10 Adjusting Back Angle - XLT Gold Recumbent Handcycle Series Back Support Tube Adjustment Holes Part No 1114850... -
Page 41: Adjusting Back Height - Wide Back Option Only
Adjusting Back Height - Wide Back Option Only NOTE: For this procedure, refer to FIGURE 6.11. NOTE: This procedure applies to Top End XLT models with wide back option only. 1. Remove the back upholstery from the handcycle. Refer to Replacing Back Upholstery on page 59. Push pin MUST protrude through hole in back cane. Ensure that both back cane inserts are at the same height before reassembling the chair. 2. Press the push pin on the back cane insert tube in and adjust the back height to one of three heights depending on original back height. -
Page 42: Section 7-Wheels
SECTION 7—WHEELS After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Installing/Adjusting the Rear Wheel and Quick-Release Axles NOTE: For this procedure, refer to FIGURE 7.1. 1. Make sure that the axle receiver hex nut is securely tightened before installing the rear wheels. 2. Depress detent pin in the quick‐release axle and slide axle through the axle ... -
Page 43: Installing The Rear Wheels With Threaded Axles
Axle FIGURE 7.2 Installing the Rear Wheels with Threaded Axles Replacing Tire/Tube and Tuning/Replacement of Spokes NOTE: Invacare recommends that these procedures be performed by a qualified technician. Tire Pressure WARNING DO NOT use the handcycle unless it has the proper tire pressure (p.s.i.). DO NOT overinflate the tires. Failure to follow these suggestions may cause the tire to explode and cause bodily harm. -
Page 44: Determining/Adjusting Toe In/Toe Out
Determining/Adjusting Toe In/Toe Out NOTE: For this procedure, refer to FIGURE 7.3. Determining Toe In/Toe Out 1. Inflate all pneumatic tires to recommended tire pressures (listed on the sidewall of the tire). 2. Measure the distance between the center lines at the rear and front of the rear wheels at approximately 12 inches from the ground/floor. NOTE: For optimum accuracy, perform STEP 2 with the handcycle occupied. NOTE: Step 2 may be performed with using alignment gauge (available as an option for the handcycle). Refer to Using the Alignment Gauge on page 74. 3. Determine the difference between the two measurements. If the difference between the two measurements is greater than 1/8‐inch (for maximum rollability), one of two conditions exists: • If the back centerline measurement of the rear wheels is smaller than the front centerline measurement of the rear wheels, a toe‐out condition exists. • If the back centerline measurement of the rear wheels is LARGER than the front centerline measurement of ... -
Page 45: Adjusting Toe In/Toe Out
Adjusting Toe In/Toe Out 1. Loosen, but DO NOT remove the socket screws and clamps that secure camber inserts to the camber bar (Detail ʺAʺ). 2. Slowly rotate the camber insert until the rear wheels are approximately in a straight line. 3. Securely tighten the socket screws and clamps that secure the camber inserts to the camber bar. 4. Measure the distance between the center lines at the rear and front of the rear wheels at approximately 12 inches from the ground/floor. Refer to Determining Toe In/Toe Out on page 44. 5. Repeat STEPS 1‐4 until the toe in/toe out measurement is less than 1/8‐inch (for maximum rollability). Replacing Camber Inserts NOTE: For this procedure, refer to FIGURE 7.4. 1. Loosen, but DO NOT remove the socket screws and clamps that secure the camber inserts to the camber bar. 2. Remove the existing camber insert from the camber bar. 3. Install the new camber insert into the camber bar. 4. Adjust the toe in/toe out of the handcycle. Refer to Determining/Adjusting Toe In/Toe Out on page 44. Clamp Camber Insert Socket Screw FIGURE 7.4 - Replacing Camber Inserts Part No 1114850... -
Page 46: Section 8-Service Procedures
SECTION 8—SERVICE PROCEDURES After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Replacing the Fork/Crank Assembly NOTE: For this procedure, refer to FIGURE 8.1 on page 48. NOTE: Invacare recommends that the following procedure be performed by a qualified technician. 1. Note the position of the crank handles. 2. Loosen, but DO NOT remove the two socket screws that secure the crank handles to the existing fork. 3. Slide the crank handles down towards the front wheel. - Page 47 19. Slide the bottom bearing onto the new fork. Refer to FIGURE 8.1 for correct orientation. 20. Slide the new fork into the frame. 21. Position the o‐ring and bearing on the new fork. Refer to FIGURE 8.1 for correct orientation. 22. Install the two nuts onto the new fork and tighten securely. Refer to FIGURE 8.1 for correct orientation. 23. Position the footrest clamps on the new frame. 24. Install the footrests onto the new fork to the position noted in STEP 17 and secure with the two hex bolts and locknuts. 25. Position the chain around the hub of the front wheel. 26. Install the front wheel onto the new fork. NOTE: Make sure the washer and the non‐turn washer are on the outside of the new fork. 27. Line up the projecting ends of the non‐turn washer with the slot in the new fork. 28. Repeat STEPS 27‐28 until the projecting ends of the non‐turn washer line up with the slot in the new fork. 29. Torque the two cap nuts 260‐390 in‐lbs. 30. Install the brake arm clamp onto the new fork. 31. Secure the brake arm to the brake arm clamp with the hex bolt and locknut. Torque to 22‐26 inch‐pounds. 32. Reinstall the shifting lever onto the seat frame and secure with the socket screw. 33. Install the road crown compensator or steering dampener onto the new fork. Refer to Installing Road Crown Compensator on page 50 or Installing Steering Dampener on ...
- Page 48 STEPS 1, 2, 3, 36, 37 Crank Handle Steering Dampener STEPS 10, 11, 30, 31 Locknut Brake Arm STEPS 15, 16, 23, 24 Fork Hex Bolts, Locknuts and Footrest Clamps FIGURE 8.1 Replacing the Fork/Crank Assembly Recumbent Handcycle Series Fork Socket Screws Fork...
-
Page 49: Replacing The Crank Arms - Xlt Gold, Xlt Pro And Top End Force
Replacing the Crank Arms - XLT Gold, XLT PRO and Top End Force NOTE: For this procedure, refer to FIGURE 8.2 on page 50. NOTE: Right and left determined from as if seated on the handcycle. Replacing the Left Side Crank Arms 1. Remove the two socket screws from the existing crank arm clamp. 2. Remove socket screw and cap from the spindle. 3. Remove the existing crank arm from the spindle. 4. Position the new crank arm onto the spindle so that the new crank arm is evenly aligned with the right side crank arm. 5. Re install the socket screw and cap from the spindle. DO NOT over tighten. 6. Using the two socket screws, secure the new crank arm clamp to the spindle. Securely tighten. Replacing the Right Side Crank Arms 1. -
Page 50: Installing/Removing/Adjusting The Road Crown Compensator
Crank Arm Clamp Left Crank Arm Spindle, Socket Screw and Cap Socket Screws FIGURE 8.2 Replacing the Crank Arms - XLT Gold, XLT PRO and Top End Force Installing/Removing/Adjusting the Road Crown Compensator NOTE: For this procedure, refer to FIGURE 8.3 on page 51. NOTE: The road crown compensator is designed to stabilize the handcycle during transfers and while riding and is not intended to keep the handcycle straight when pedaling but to keep the handcycle from leaning excessively to one side or another. Installing Road Crown Compensator 1. -
Page 51: Removing Road Crown Compensator
Removing Road Crown Compensator 1. Remove the locknut securing the fork end of the road crown compensator to the fork bolt. 2. Remove the fork end of the road crown compensator from the fork bolt. 3. Remove the bolt and spacer securing the frame end of the road crown compensator to the frame. Adjusting Road Crown Compensator NOTE: This adjustment is made for handcycling on crowned roads or in heavy winds. 1. Rotate the fork end of the road crown compensator to adjust the length. Clockwise ‐ shortens the road crown compensator and pulls the front wheel to the left. Counterclockwise ‐ lengthens the road crown compensator and pushes the front wheel to the right. Adjustment Road Crown Compensator Fork End Installed Fork Road Crown Compensator FIGURE 8.3 Installing/Removing/Adjusting the Road Crown Compensator Part No 1114850 Fork Bolt Frame... -
Page 52: Installing/Removing/Adjusting The Steering Dampener - For Top End Xlt Gold And Force Only
Installing/Removing/Adjusting the Steering Dampener - For Top End XLT Gold and Force Only NOTE: For this procedure, refer to FIGURE 8.4 on page 53. NOTE: The steering dampener is designed to stabilize the handcycle during transfers and while riding and is not intended to keep the handcycle straight when pedaling but to keep the handcycle from leaning excessively to one side or another. Installing Steering Dampener 1. Using a locknut, secure the upper threaded post of the steering dampener to the crank assembly tab. 2. While inserting the lower threaded post into the tab, position the dampener clamp around the handcycle frame. 3. Using two socket screws, loosely secure the dampener clamp to the handcycle frame. 4. Using a locknut, secure the steering dampener to the dampener clamp. 5. Ensuring the front wheel and dampener clamp are inline with the handcycle frame, securely tighten the two socket screws securing the dampener clamp to the handcycle frame. 6. Test drive handcycle, if handcycle pulls to the left or right adjust the steering dampener. Refer to Adjusting Steering Dampener on page 52. Removing Steering Dampener 1. -
Page 53: Installing Seven Speed Shifter Cable
(One Located on Both Sides of the Handcycle Frame) Lower Threaded Post and Clamp (Tab) Locknut Steering Dampener Dampener Clamp (Tab) and Force Only Cable FIGURE 8.5 Installing Seven Speed Shifter Socket Screws Handcycle Frame Dampener Handcycle Frame Hand Crank Assembly... -
Page 54: Adjusting/Replacing Seven Speed Shifter
Adjusting/Replacing Seven Speed Shifter Handcycles with seven speed shifters are equipped with SHIMANO hubs. If equipped with a SHIMANO hub, it MUST be serviced and adjusted by a qualified technician. NOTE: QUALIFIED TECHNICIANS ONLY ‐ Contact Invacare, 1‐800‐532‐8677 for complete SHIMANO hub instructions. It is recommended that you take your handcycle to a qualified technician for any shifter adjustment. Installing/Adjusting Seven Speed Hub Chain Seven Speed Hub Chain Installation Chain MUST be tight. If the chain is noisy, loosen. After chain is assembled, start in first gear and on straightaway. -
Page 55: Adjusting Seven Speed Hub Chain
Adjusting Seven Speed Hub Chain Chain MUST be tight. If the chain is noisy, loosen. After chain is assembled, start in first gear and on straightaway. NOTE: For this procedure, refer to FIGURE 8.7 on page 55. NOTE: This procedure applies to the Top End XLT and Top End XLT Jr. only. 1. Ensure the hand crank is adjusted to the proper height. Refer to Adjusting Hand Crank on page 34. NOTE: Repositioning of the hand crank assembly loosens or tightens the chain in an up/down position. 2. Loosen the hex screw securing the adjustable chain idler. 3. Adjust the tautness of the chain by moving the adjustable chain idler in or out as shown in FIGURE 8.7. 4. -
Page 56: Adjusting Twenty-Seven Speed Cassette Chain
5. Run the chain around the bottom of the wheel sprocket and back up towards the hand crank sprocket. 6. Attach the chain together using the master link (w/clip) provided. 7. To tension chain, refer to Refer to Replacing the Fork/Crank Assembly on page 46. Hand Crank Sprocket Assembles STEP 5 Chain Derailleur and Wheel Sprockets STEP 3 FIGURE 8.8 Installing Twenty-Seven Speed Cassette Chain Adjusting Twenty-Seven Speed Cassette Chain NOTE: For this procedure, refer to FIGURE 8.9. 1. Loosen, but DO NOT remove the clamp that secure the crank handles to the fork. 2. Slide the crank handles up and/or down until the proper tension on the chain is achieved. NOTE: The proper chain tension will be approximately ½‐inch of chain slack. -
Page 57: Adjusting/Replacing The Parking Brake
Crank Handle Clamps FIGURE 8.9 Adjusting Twenty-Seven Speed Cassette Chain Adjusting/Replacing the Parking Brake Before using your handcycle, inspect the parking brake for proper operation. NOTE: For this procedure, refer to FIGURE 8.10. Adjusting the Parking Brake Cable 1. Loosen the hex nut and turn the adjuster barrel clockwise (tighten) or counterclockwise (loosen) to adjust the cable. Retighten hex nut. Brake Pads 1. Adjust the brake pad assembly so that when the parking brake is engaged the brake pads rest solely on the rim of the wheel. Replacing the Parking Brake Brake Pads 1. -
Page 58: Replacing Seat Upholstery
Parking Brake Replacement of the parking brake MUST be performed by a qualified technician. Stop Button FIGURE 8.10 Adjusting/Replacing the Parking Brake Replacing Seat Upholstery Upholstery MUST be inspected before each use. Exposure to moisture (i.e. - wet weather or puddles) will damage fastening straps/flaps/strips. DO NOT operate handcycle if upholstery is wet or damaged, otherwise severe injury may occur. -
Page 59: Replacing Back Upholstery
Replacing Back Upholstery Upholstery MUST be inspected before each use. Exposure to moisture (i.e. - wet weather or puddles) will damage fastening straps/flaps/strips. DO NOT operate handcycle if upholstery is wet or damaged, otherwise severe injury may occur. Replacing Wide Back Upholstery NOTE: For this procedure, refer to ... -
Page 60: Section 9-Options
SECTION 9—OPTIONS SECTION 9—OPTIONS WARNING After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Installing Rear Safety Light Safety Light WARNING Operation of the handcycle is subject to Lens all traffic rules and regulations. -
Page 61: Installing The Water Bottle
Installing the Water Bottle NOTE: For this procedure, refer to FIGURE 9.2. 1. Secure the water bottle mounting tube to the seat frame using the hardware provided. NOTE: Make sure that the water bottle mounting bracket mounting holes are facing downward. 2. Attach the water bottle mounting bracket to the mounting tube using the hardware provided. 3. Push water bottle into mounting bracket until secure. Mounting Tube Seat Frame Mounting Bracket FIGURE 9.2 Installing the Water Bottle Installing/Using the Tow Bar NOTE: For this procedure, refer to FIGURE 9.3. NOTE: The tow bar will not work with wheelchairs with swingaway front riggings. Only rigid wheelchairs with a tubular style footrest can be towed using the tow bar. 1. Remove the two set screws on each mounting bracket. 2. Position the mounting brackets around the handcycle rear frame. NOTE: Make sure that the tow bar is centered on the handcycle rear frame. 3. -
Page 62: Installing The Draft Bumper
Installing the Draft Bumper DO NOT use if draft bumper extends past rear wheels. If draft bumper extends past the rear wheels, contact dealer. NOTE: For this procedure, refer to FIGURE 9.4. NOTE: The draft bumper can not be installed if the tow bar is installed. 1. Remove the four set screws on each mounting bracket. 2. Position the mounting brackets around the handcycle rear frame. NOTE: Make sure that the draft bumper is centered on the handcycle rear frame. 3. Using four set screws for each mounting bracket, secure the mounting brackets to the handcycle rear frame. Installing the Safety Flag NOTE: For this procedure, refer to FIGURE 9.5. -
Page 63: Installing Seat Positioning Strap
SECTION 9—OPTIONS Installing Seat Positioning Strap NOTE: For this procedure, refer to FIGURE 9.7. 1. Secure seat positioning strap to back canes using hardware provided. Back Canes Seat Positioning Strap FIGURE 9.7 Installing Seat Positioning Strap Installing the Computer NOTE: For this procedure, refer to FIGURE 9.8. 1. Install metal plug onto spoke of front wheel approximately 2 inches from wheel rim. 2. Align metal plug with fork assembly. 3. Secure sensor to fork using hardware provided. NOTE: Slot in sensor MUST align with metal plug for mileage, etc. to be registered on the computer. 4. Remove one of the chain guard screws and attach the computer mounting bracket. 5. Snap computer into mounting bracket. Computer Sensor Mounting Bracket Front Wheel Spoke Metal Plug... -
Page 64: Installing Hand Crank Handles
Installing Hand Crank Handles NOTE: For this procedure, refer to FIGURE 9.9. Horizontal Handles/Delrin Handles 1. Secure handle to hand crank with the screw (Detail “A”). 2. Remove the screw to remove handle from handcrank. Vertical Handles 1. Position handle onto crank (Detail “B”). 2. Tighten set screw to secure handle to crank. 3. Reverse STEPS 1‐2 to remove handle. Tri-pin Quad Handles 1. Remove/install tri‐pin quad handles. Refer to Vertical Handles on page 64 2. Loosen socket screws to adjust handle position (Detail “C”). 3. Tighten socket screws to secure handles in desired position. V or S Crank Handles Replacement/installation of V or S crank ... -
Page 65: For Models Made After 7/12/07
2. Firmly tighten the bolt. NOTE: Handle should spin freely with minimal play. If handle does not spin freely make sure the spacer is firmly in place. If handle still does not spin freely, contact Invacare. Bolt Spacer Crankarm FIGURE 9.10 Installing V/S Crankarm Handles - For Models Made Before 7/12/07 For Models Made After 7/12/07 WARNING Failure to install handle assembly properly could result in injury. It is recommended to inspect this assembly prior to and after each use. -
Page 66: Installing Gloves
Installing Gloves NOTE: For this procedure, refer to FIGURE 9.12 on page 66. 1. Wrap palm loop around horizontal handle (using top slot only) and secure to glove. 2. Run glove loop through bottom slot on palm and over back of hand until tight. Secure glove loop to back of glove. 3. Reattach glove strips to back of glove. Glove Top Slot Glove Palm Strip Loop Mountain Drive Transmission Option DO NOT shift the mountain drive transmission option under load (i.e. using a high gear to start the handcycle in motion or to climb a hill, etc.). Shifting the mountain drive transmission option under load will damage the internal workings of the mountain drive option and will void the warranty. -
Page 67: Using The Travel Ready Option
Using the Travel Ready Option NOTE: For this procedure, refer to FIGURE 9.14 on page 67. NOTE: This procedure is for Top End XLT Pro, Gold, and Top End Force models only. The travel ready option allows the handcycle to be quickly and easily disassembled for travel. NOTE: Reverse the steps below to reassemble the handcycle. 1. Remove the rear wheels. Refer to Installing/Adjusting the Rear Wheel and Quick‐Release Axles on page 42. 2. Remove the camber bar. Refer to Removing/Installing the Camber Bar on page 67. 3. Remove the footrests. Refer to Replacing/Adjusting the Footrest and Leg Guard on page 32. 4. Remove the fork and front wheel. Refer to Removing/Installing the Fork ‐ Travel Ready XLT PRO Equipped with Road Crown Compensator on page 68 or Removing/Installing the Fork ‐ XLT Gold, and Top End Force Equipped with Steering Dampener on page 69. Removing/Installing the Camber Bar NOTE: For this procedure, refer to FIGURE 9.14 on page 67. NOTE: To install the camber bar, reverse the steps below. 1. Perform one of the following • Adjustable Angle Seat on XLT Gold ‐ Seat support tube does not mount to camber ... -
Page 68: Removing/Installing The Fork - Travel Ready Xlt Pro Equipped With Road Crown Compensator
SECTION 9—OPTIONS Removing/Installing the Fork - Travel Ready XLT PRO Equipped with Road Crown Compensator NOTE: For this procedure, refer to FIGURE 9.15 on page 69. Removing the Fork 1. Remove the nut securing the road crown compensator to the fork. 2. Remove the road crown compensator from the fork bolt. 3. Remove the two socket screws from each fork clamp. 4. Remove the plate from the top of the fork. 5. Remove the fork from the frame. 6. Remove the front wheel from the fork.Refer to Removing the Front Wheel on page 70. Installing the Fork 1. Position the fork onto the frame. 2. Position the plate on to the fork. 3. -
Page 69: Removing/Installing The Fork - Xlt Gold, And Top End Force Equipped With Steering Dampener
Fork Bolt Road Crown Compensator FIGURE 9.15 Removing/Installing the Fork - Travel Ready XLT PRO Equipped with Road Removing/Installing the Fork - XLT Gold, and Top End Force Equipped with Steering Dampener NOTE: For this procedure, refer to FIGURE 9.16 on page 70. Removing the Fork 1. Remove the locknut securing the steering dampener to the dampener clamp (Detail ʺAʺ). -
Page 70: Removing/Installing The Front Wheel - Xlt Gold, Xlt Pro And Xlt With Speed Cassette Chain
52. Locknut Socket Screws Fork Clamp FIGURE 9.16 Removing/Installing the Fork - XLT Gold, and Top End Force Equipped with Removing/Installing the Front Wheel - XLT Gold, XLT Pro and XLT with Speed Cassette Chain NOTE: For this procedure, refer to FIGURE 9.17 on page 71. Removing the Front Wheel 1. -
Page 71: Installing The Front Wheel
Installing the Front Wheel NOTE: For ease of installation, secure handcycle frame approximately 6 inches from the ground or seek assistance. 1. Loop the chain over the front wheel sprocket. 2. Position the front wheel sprocket into the fork slots. 3. Tighten the knob on the opposite side of the quick‐release lever. 4. Secure the wheel to the fork with the quick‐release lever. Sprocket Chain Fork FIGURE 9.17 Removing/Installing the Front Wheel - XLT Gold, XLT Pro and XLT with Speed Assembling/Using/Adjusting the Handcycle Rack NOTE: For this procedure, refer to FIGURE 9.18 on page 72. Assembling the Handcycle Rack 1. -
Page 72: Using The Handcycle Rack
8. Using two mounting bolts and locknuts, secure the rear wheel bar to the wheel tray. 9. Install the receiver onto the trailer hitch of the vehicle, according to the vehicle manufacturerʹs instructions. Using the Handcycle Rack 1. Position the handcycle on the rack with the front wheel in the wheel tray bracket. 2. Adjust the handcycle rack so the wheel tray bracket sits against the front wheel and the rear wheel bar brackets sit against the rear wheels. Refer to Adjusting the Handcycle Rack on page 73. 3. Secure the front wheel to the wheel tray bracket using the strap provided. 4. Secure the rear wheels to the rear wheel bar using the straps provided. Receiver Small Mounting Bolts and Locknuts Bracket Wheel Stop Wheel Stop Mounting Positions Mounting Bolts and Locknuts FIGURE 9.18 Assembling/Using/Adjusting the Handcycle Rack Recumbent Handcycle Series Rear Wheel Mounting Bolts... -
Page 73: Adjusting The Handcycle Rack
Adjusting the Handcycle Rack Wheel Tray Bracket NOTE: To properly secure the handcycle, the wheel tray bracket should be adjusted to sit against the front wheel. 1. Remove the four mounting bolts and locknuts securing the wheel tray bracket to the wheel tray. 2. Position the wheel tray bracket in the desired position. 3. Secure the wheel tray bracket to the wheel tray with the four mounting bolts and locknuts. 4. If necessary, the wheel stop may be adjusted to one of three positions to sit against the front wheel. To adjust the wheel stop, perform the following steps: A. Remove the mounting bolt and locknut securing the wheel stop to the wheel tray bracket. B. Position the wheel stop in the desired mounting position. C. Secure the wheel stop to the wheel tray bracket with the mounting bolt and locknut. Rear Wheel Bar Brackets NOTE: To properly secure the handcycle, the rear wheel bar brackets should be adjusted to sit against the rear wheels. 1. Loosen the two screws securing the rear wheel bar bracket to the rear wheel bar. 2. Adjust the rear wheel bar bracket in/out until they sit against the rear wheel. 3. Secure the rear wheel bar bracket to the rear wheel bar with the two screws. 4. -
Page 74: Using The Alignment Gauge
Using the Alignment Gauge NOTE: For this procedure, refer to FIGURE 9.19. NOTE: The alignment gauge is used to determine toe in/toe out. Refer to Determining/Adjusting Toe In/Toe Out on page 44 for more information. 1. Inflate all pneumatic tires to recommended tire pressures (listed on the sidewall of the tire). 2. Place the handcycle and alignment gauge on a flat surface. 3. Position the alignment gauge near the rear of the rear tires. 4. Loosen the height adjustment screw. 5. Raise/lower the alignment bar so the bar is approximately 12 inches from the ground/floor. 6. Tighten the height adjustment screw. 7. Loosen the alignment screw. 8. Position the alignment gauge between the rear of the rear tires. 9. Adjust the alignment bar so the alignment gauge fits snugly between the rear of the rear tires. 10. Tighten the alignment screw to secure the alignment bar position. 11. Position the alignment gauge at the front of the rear tires. 12. Examine the gauge. Perform one of the following: A. Alignment Gauge Fits Snugly Between the Front of the Rear Tires ‐ Wheels are aligned. No toe in/toe out adjustment is needed. B. There is Extra Space Between the Alignment Gauge and Rear Tires ‐ The tires have a toe out condition. Refer to Adjusting Toe In/Toe Out on page 45. -
Page 75: Limited Warranty
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants the frame to be free from defects in materials and workmanship for a period of three years from date of purchase; distributed parts and components including compensators, forks, upholstery and miscellaneous bicycle components are warranted for a period of one year from the date of purchase;... - Page 76 800-668-5324 All rights reserved. Trademarks are identified by the symbols ™ and ®. All trademarks are owned by or licensed to Invacare Corporation unless otherwise noted. Shimano, Nexus, and Ultegra are registered trademarks of Shimano Inc. 3-in-1 and WD-40 are registered trademarks of the WD-40 Company.
