Location And Clearances - Quadra-Fire VILLAGE COLLECTION Installation & Operating Instructions Manual

WARNING!
Due to high temperatures, this heater should be located
out of traffic. Keep combustible materials such as fur-
niture, pillows, bedding, papers, clothes and curtains
at least 1 ft [.31M] from the front of the heater.
Note:
Minimum and maximum clearances must be main-
tained at all times. Illustrations throughout these instructions
reflect typical installations and are for design purposes only.
Actual installation may vary slightly due to individual design
preferences.
The illustrations and diagrams used throughout these instal-
lation instructions are not drawn to scale.
To prevent contact with sagging or loose insulation, the heater must not be installed against vapor barriers or
exposed insulation. Localized overheating could occur and a fire could result.
1. Heater Locations and Space Require-
ments
Figure 1 illustrates a variety of ways the heater may
be located in a room. The QV26E heater may be
installed directly on the floor, carpet or raised on a
hearth.
2. Clearances
Figure 1 shows all clearances that must be
maintained around the heater.
CAUTION:
Wear gloves and safety glasses for protec-
tion during installation and maintenance.
VILLAGE COLLECTION ELECTRIC FIREPLACE/INSERT
4
C. LOCATION AND CLEARANCES
1445 North Highway, Colville, WA 99114-2124
Never locate this heater where it may fall into a bath-
tub or other water container.
Do not expose the heater to the elements (such as
rain, etc.).
WARNING!
Figure 1 - Heater Locations
Hearth & Home Technologies Inc.
WARNING!
CAUTION:
4038-827 Rev B
