Always disconnect power and allow the heater to cool before performing any cleaning, maintenance or relocation of this
heater. Turn controls to "OFF" and remove the plug from the outlet or turn off the circuit breaker to the heater.
1. Access the Firebox
a. Turn the heater off and turn off the circuit breaker.
b. Allow the heater to cool before cleaning.
c. Remove the front face to access the log area.
1) Remove the screws from the switch bracket.
2) Remove by pulling out the bottom of the front and
then lifting up
d. Replace all parts after cleaning or bulb replacement has
been completed.
e. Reset the circuit breaker.
2. Clean the Firebox Compartment
Use the brush attachment and gently vacuum the
compartment.
3. Clean the Back Glass
a. The glass is cleaned in the factory during the assembly
process. During shipment, installation, handling, etc., the
glass surface may collect dust particles. These can be
removed by buffing lightly with a clean dry cloth.
b. To remove fingerprints or other marks, the glass can be
cleaned with a damp cloth using a good quality household
glass cleaner. The glass should be completely dried with
a lint free cloth or paper towel.
c. In the event of glass breakage, vacuum all remaining
glass pieces with a shop vac. DO NOT VACUUM IF
PIECES ARE HOT! Replace the glass with a Quadra-
Fire glass panel ordered direct or through your local
distributor. Never use substitute material. Only fully
tempered soda lime safety glass may be used on this
heater.
4. Replace the Light Bulbs
The light bulbs need to be replaced when the flame and/or
ember bed is dark on one side. Replace the bulbs with 75
watt halogen bulbs with mini-candelabra base. Do not
exceed 75 watts per bulb. Light bulbs can be purchased at a
local hardware or lighting store, on-line or by phone. To order
on-line, log onto www.lite-house.com or call 1-800-838-0977.
We recommend you use Sylvania model SL58884 or Satco
model S3157.
a. Light bulb access is through the ember bed. See Figure 6.
b. Locate and lift the bent tabs holding the ember tray
located at each end of the ember tray.
c. Lift out the ember tray.
d. Carefully remove the burned out bulb from the light
socket. Place the new bulb in the socket. See Figure 7.
Follow directions on the light bulb package for
handling requirements.
e. Reinstall the ember tray.
VILLAGE COLLECTION ELECTRIC FIREPLACE/INSERT
12
J. MAINTENANCE INSTRUCTIONS
1445 North Highway, Colville, WA 99114-2124
WARNING!
Figure 7 - Replacing the Bulbs
Hearth & Home Technologies Inc.
Figure 6 - Bulb Access
04/04
4038-827 Rev B
