INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
VOYAGEUR WOOD INSERT
Automatic Combustion Control (ACC)
Model(s):
VOYAGEUR-MBK
VOYAGEUR-PMH
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies recommends NFI certifi ed profession-
als, or technicians supervised by an NFI certifi ed
professional.
1
Owner's Manual
Operation & Care
7063-512F
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafi re.com
February 25, 2016
Advertisement
Table of Contents
Related Manuals for Quadra-Fire OYAGEUR-MBK
Summary of Contents for Quadra-Fire OYAGEUR-MBK
- Page 1 Owner’s Manual Operation & Care INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc- tions is not followed exactly, a fi...
-
Page 2: Congratulations
Hearth & Home Technologies welcomes you to our tradition old-fashioned when it comes to craftsmanship. Each unit of excellence! In choosing a Quadra-Fire appliance, you is meticulously fabricated and gold and nickel surfaces are have our assurance of commitment to quality, durability, and hand-fi... -
Page 3: Table Of Contents
VOYAGEUR Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury. •... -
Page 4: Warranty
VOYAGEUR C. Warranty Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 5 VOYAGEUR WARRANTY CONDITIONS: ‡ 7KLV ZDUUDQW\ RQO\ FRYHUV ++7 DSSOLDQFHV WKDW DUH SXUFKDVHG WKURXJK DQ ++7 DXWKRUL]HG GHDOHU RU GLVWULEXWRU $ OLVW RI ++7 DXWKRUL]HG GHDOHUV LV DYDLODEOH RQ WKH ++7 EUDQGHG ZHEVLWHV ‡ 7KLV ZDUUDQW\ LV RQO\ YDOLG ZKLOH WKH ++7 DSSOLDQFH UHPDLQV DW WKH VLWH RI RULJLQDO LQVWDOODWLRQ ‡...
-
Page 6: Quick Start Guide
VOYAGEUR D. Quick Start Guide Note: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR CONTROLS ADD NEWSPAPER LOAD WOOD... -
Page 7: Listing And Code Approvals
NOTE: Hearth & Home Technologies, manufacturer of instructions in this manual. this appliance, reserves the right to alter its products, their specifi cations and/or price without notice. Quadra-Fire is a registered trademark of Hearth & Home Technologies. February 25, 2016 7063-512F... -
Page 8: Operating Instructions
VOYAGEUR User Guide Operating Instructions WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • DO NOT touch glass until it is cooled • NEVER allow children to touch glass •... -
Page 9: Fire Safety
VOYAGEUR B. Fire Safety • Contact your local chimney professional and have your stove and stove pipe inspected for any damage. To provide reasonable fi re safety, the following should be given • Do not use your stove until the chimney professional serious consideration: informs you it is safe to do so. -
Page 10: Burning Process
fl ames. placed on the burning of wood for home heating. During this stage of burning: In order to improve the situation, we at Quadra-Fire have • The fl ames must be maintained and not allowed to go out developed cleaner-burning wood appliances that surpass ensure the cleanest possible fi... -
Page 11: Automatic Combustion Control (Acc)
VOYAGEUR G. Automatic Combustion Control (ACC) Typically, when you build a fi re, you open the air controls fully and monitor the fi re to prevent it from going into an overfi re situation and/or burning your wood up too quickly before you shut down the air controls to the desired burn rate. -
Page 12: Burn Rates And Operating Effi Ciency
VOYAGEUR 3. Burn Rate Air Control 4. Medium-Low Burn Rate - 10,000 to 15,000 BTU/hr* • The air supply enters at the upper front of the fi rebox, • Raise the Burn Rate Air Control up to the bottom of the near the top of the glass door. -
Page 13: Correct Baffl E & Blanket Placement
VOYAGEUR J. Correct Baffl e & Blanket Placement INCORRECT POSITIONS WARNING Fire Risk Improper baffl e placement may cause: • Overheating of fi rebox • Overheating the chimney Baffl e must be placed properly (see instructions) Replace baffl e if damaged or missing. Ceramic Blanket and Baffl... -
Page 14: Building A Fire
VOYAGEUR K. Building A Fire • Open door slowly so that ash or smoke does not exit appliance through opening. WARNING • Large logs burn slowly, holding a fi re longer. • Small logs burn fast and hot, giving quick heat. Fire Risk. -
Page 15: Wood Fuel
VOYAGEUR L. Wood Fuel WARNING Fire Risk. WARNING • Do NOT burn wet or green wood. • Store wood in dry location. Fire Risk. • Stack wood so both ends are exposed to air. • DO NOT BURN GARBAGE OR FLAMMABLE Wet, unseasoned wood can cause accumulation of creosote. -
Page 16: Operating The Blower Control Box With Snap Disc
VOYAGEUR M. Operating the Blower Control Box with Snap Disc 1. The blower will turn on/off automatically when set to AUTO. Figure 16.1. 2. When set to MANUAL, the fan will turn on/off only when you turn it on or off. This setting over-rides the internal snap disc. -
Page 17: Clear Space
VOYAGEUR Q. Opacity (Smoke) O. Clear Space Opacity is the measure of how cleanly your appliance is • Do NOT place combustible objects within 4 ft (1.2 m) of burning. the front of appliance. Figure 17.1. Opacity is measured in percent: •... -
Page 18: Maintenance And Service
VOYAGEUR Maintenance and Service When properly maintained, your fi replace will give you Creosote - Formation and Need for Removal many years of trouble-free service. Contact your dealer to • When wood is burned slowly, it produces tar and other answer questions regarding proper operation, troubleshoot- organic vapors, which combine with expelled moisture to ing and service for your appliance. -
Page 19: Glass Cleaning
VOYAGEUR E. Glass Cleaning F. Inspect Firebrick • Frequency: As desired • Frequency: After each ash removal • By: Homeowner • By: Homeowner Replace the fi rebrick if they become crumbly and/or if there • Clean glass with a non-abrasive glass cleaner. Abrasive is a 1/4 inch (6.35mm) gap between the bricks. -
Page 20: Quick Reference Maintenance Guide
VOYAGEUR G. Quick Reference Maintenance Guide Start the fi rst inspection after the fi rst 2 months of use, or if performance changes, and adjust your schedule according- CAUTION! Allow the appliance to completely cool ly. Maintenance is required for safe operation and must be down before performing any cleaning or maintenance. -
Page 21: Troubleshooting Guide
VOYAGEUR Troubleshooting Guide With proper installation, operation, and maintenance your wood stove will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken. -
Page 22: Service Parts Replacement
DO NOT OVERTIGHTEN - can cause glass to break. Replace the door on the appliance. Quadra-Fire appliances are equipped with ceramic super Figure 22.1 Snap Disc Location heat-resistant glass, which can only be broken by impact or misuse. -
Page 23: Blower Replacement
VOYAGEUR D. Blower Replacement CAUTION 1. The grille on the blower access assembly is hinged. Swing the grille downward to expose the 2 screws. Figure 23.1. Shock Risk. • Do NOT remove grounding prong from plug. 2. Remove the 2 screws from the blower access assembly •... -
Page 24: Baffl E & Ceramic Blanket Removal
VOYAGEUR E. Baffl e & Ceramic Blanket Removal F. Door Handle Assembly 1. Install washer on door handle shaft. 1. Remove all ash from the fi rebox, and extinguish all hot 2. Slide door handle through door. embers before disposal into a metal container. 3. -
Page 25: Tube Channel Assembly Replacement
VOYAGEUR G. Tube Channel Assembly Replacement NOTE: Soak the bolts with penetrating oil for at least 15 min- utes before trying to remove them. Removing Tube Channel Assembly 5. Slide the tube channel assembly all the way to left until 1. -
Page 26: Reference Materials
VOYAGEUR Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service 7063-512F February 25, 2016... -
Page 27: Service Parts & Accessories
VOYAGEUR B. Service Parts & Accessories VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Cast Iron Wood Insert Ending Manufacturing Date: Active VOYAGEUR-MBK, VOYAGEUR-PMH Part number list on following page. 02/16 February 25, 2016 7063-512F... - Page 28 VOYAGEUR VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
- Page 29 VOYAGEUR VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Ending Manufacturing Date: Active #13 Door Assembly #14 Access Assembly 13.3 14.1 13.7 13.2 13.8 13.1 14.2 13.9 13.6 14.3 13.5 13.10 13.4 13.12 14.6 14.5 13.11 14.4 IMPORTANT: THIS IS DATED INFORMATION .
- Page 30 VOYAGEUR VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
- Page 31 VOYAGEUR VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
- Page 32 VOYAGEUR VOYAGEUR Service Parts Beginning Manufacturing Date: Sept 2010 Ending Manufacturing Date: Active #27 Surround Assemblies 27.5 27.6 27.1 27.4 27.7 27.2 27.3 27.8 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 33 VOYAGEUR February 25, 2016 7063-512F...
- Page 34 VOYAGEUR 7063-512F February 25, 2016...
- Page 35 VOYAGEUR February 25, 2016 7063-512F...
-
Page 36: Contact Information
Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL...
