I N S T A L L A T I O N G U I D E
for the
SB-H-RIDGLNE/10W3v3
2006 - Up Honda Ridgeline
Thank you for choosing a JL Audio Stealthbox
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
JL Audio dealer. The installation professionals employed by your dealer have the necessary
tools and experience to disassemble and reassemble your vehicle properly. Also, keep in
mind that your warranty coverage extends to 2 year if your system is installed or approved
by your authorized JL Audio dealer. If you prefer to perform your own installation,
please read this installation guide completely before beginning the process.
®
for your automotive sound system.
®
installed by your authorized
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
16-1/2"
4-3/4"
SB-H-RIDGLNE/10W3v3_ 011214
INSTALLATION
D I F F I C U L T Y :
2
S T E P 1
Remove any contents from rear seating area. Flip and lock
the rear seating in the up position.
S T E P 2
Place the supplied wax square into place.
16-1/2" from the door sill and 4-3/4" from the bulk head, as in
the picture.
S T E P 3
Thread in the supplied socket cup set screw into the
threaded insert, located on the bottom side of the
Stealthbox®. Leaving 1/4" exposed.
Continued on Next Page
OUT
OF 5
