I N S T A L L A T I O N G U I D E
for the
SB-P-CYNNE/10W6v2/BK SB-P-CYNNE/10W6v2/BK
2003 - 2006 Porsche Cayenne 2003 - 2006
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
Porsche Cayenne
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
A
A
B
SB-P-CYNNE/10W6v2/BK_INSTR_SKU#011231 SB-P-CYNNE/10W6v2/BK_INSTR_SKU#011231
INSTALLATION
D I F F I C U L T Y :
3
ESTIMATED TIME:
2-3 HOURS
S T E P 1
Remove any contents from the cargo area.
S T E P 2
Remove the flooring.
S T E P 3
With a T-30 wrench or socket, remove the pair of hold down
cleats(A).
With an 10mm socket, remove the bolt(B) that secures the
side panel to the vehicle.
Continued on Next Page
OUT
5 OF
